Advantech PCLD-8751 Manual de usuario

PCLD-8751

48-Channel Opto-isolated D/I

Board

PCLD-8761

24-Channel Opto-isolated D/I

and 24-Channel Relay Board

User Manual

PCLD-8751 & PCLD-8761 User Manual ii

The documentation and the software included with this product are copy-

righted 2004 by Advantech Co., Ltd. All rights are reserved. Advantech

Co., Ltd. reserves the right to make improvements in the products

described in this manual at any time without notice. No part of this man-

ual may be reproduced, copied, translated or transmitted in any form or

by any means without the prior written permission of Advantech Co., Ltd.

Information provided in this manual is intended to be accurate and reli-

able. However, Advantech Co., Ltd. assumes no responsibility for its use,

nor for any infringements of the rights of third parties, which may result

from its use.

Acknowledgements

All product names or trademarks are properties of their respective own-

ers.

Part No. 2003875100 1st Edition

Printed in Taiwan November 2004

iii

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its prod-

ucts will be free from defects in materials and workmanship for two years

from the date of purchase.

This warranty does not apply to any products which have been repaired or

altered by persons other than repair personnel authorized by Advantech,

or which have been subject to misuse, abuse, accident or improper instal-

lation. Advantech assumes no liability under the terms of this warranty as

a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous test-

ing, most of our customers never need to use our repair service. If an

Advantech product is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will

be billed according to the cost of replacement materials, service time and

freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For

example, CPU speed, Advantech products used, other hardware

and software used, etc.) Note anything abnormal and list any

onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your man-

ual, product, and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return

merchandize authorization) number from your dealer. This allows

us to process your return more quickly.

4. Carefully pack the defective product, a fully-completed Repair and

Replacement Order Card and a photocopy proof of purchase date

(such as your sales receipt) in a shippable container. A product

returned without proof of the purchase date is not eligible for war-

ranty service.

5. Write the RMA number visibly on the outside of the package and

ship it prepaid to your dealer.

PCLD-8751 & PCLD-8761 User Manual iv

Technical Support and Assistance

Step 1. Visit the Advantech web site at www.advantech.com/support

where you can find the latest information about the product.

Step 2. Contact your distributor, sales representative, or Advantech's cus-

tomer service center for technical support if you need additional

assistance. Please have the following information ready before

you call:

- Product name and serial number

- Description of your peripheral attachments

- Description of your software (operating system, version, appli-

cation software, etc.)

- A complete description of the problem

- The exact wording of any error messages

Packing List

Before setting up the system, check that the items listed below are

included and in good condition. If any item does not accord with the

table, please contact your dealer immediately.

1 x PCLD-8751 48-Channel Isolated Digital Input Board

1 x User Manual

1 x PCLD-8761 24-Channel Opto-isolated D/I and 24-Channel Relay

Board

1 x User Manual

Contents

Chapter 1 Introduction ..................................................... 2

1.1 General Information .......................................................... 2

1.2 Applications ...................................................................... 2

1.3 Features ............................................................................. 2

1.4 Specifications .................................................................... 3

1.4.1 Isolated Digital Inputs .................................................... 3

1.4.2 Relay .............................................................................. 3

1.4.3 General ........................................................................... 4

Chapter 2 Installation ....................................................... 6

2.1 Initial Inspection................................................................ 6

2.2 Connectors and Jumpers.................................................... 7

2.2.1 PCLD-8751 ................................................................... 7

2.2.2 PCLD-8761 .................................................................. 10

Chapter 3 Operations...................................................... 16

3.1 Power Source Selection................................................... 16

3.2 Control Logic .................................................................. 16

3.3 Wiring.............................................................................. 17

3.3.1 Isolated DI .................................................................... 17

PCLD-8751 & PCLD-8761 User Manual vi

CHAPTER

Introduction

This chapter introduces PCLD-8751

and PCLD-8761.

Sections include:

• General Information

• Applications

• Features

• Specifications

PCLD-8751 & PCLD-8761 User Manual 2

Chapter 1 Introduction

1.1 General Information

PCLD-8751 and PCLD-8761 are daughter boards that feature 48 isolated

digital I/O channels. PCLD-8751 is equipped with 48 opto-isolated digi-

tal input channels, while PCLD-8761 provides 24 isolated DI and 24

relay channels, which can be used by all Advantech TTL DI/O cards with

a 68-pin SCSI connector, like the PCI-1751 and PCI-1753 series.

In addition to on-board screw terminals for easy wiring, each channel is

equipped with an LED to indicate the status. If the input voltage level is

high or the output channel is activated, the LED will be lit, otherwise the

LED is off. You may configure the channels to work in either positive

logic mode or negative logic mode by setting the on-board jumpers.

1.2 Applications

• Digital signal sensing

• Switch status monitoring

• Limit switch monitoring

• Signal switching

• ON/OFF control

• Valve/solenoid control

• External high-power relay control

• Test automation

1.3 Features

• Works with Advantech TTL DIO cards equipped with 48 D/IO chan-

nels on SCSI 68-pin cable connectors

• 48 opto-Isolated digital input channels

• Detachable screw terminal for easy wiring

• LEDs indicate input logic status

• Inputs buffered with voltage comparators

3 Chapter1

1.4 Specifications

1.4.1 Isolated Digital Inputs

• Isolation Voltage: 3500 Vrms

• Channels: 48 IDI with LEDs

• Contact Modes: Wet contact

Dry contact (set by switch)

• Logic Mode: Positive Logic

Negative Logic (set by jumper)

• Digital Input Activation Voltage:

Wet contact mode, Vin = 0 ~ 30 V

activated: Vin (MIN) 4 V

deactivated: Vin (Max) 1 V

Dry contact mode, external power = DC +5 ~ 30 V

activated: short

deactivated: open

1.4.2 Relay

• Type: Form C (SPDT)

• Contact Resistance: < 100 ohm

• Operation Time: 5 ms max.

• Release Time: 6 ms max.

• Contact Rating: DC 30 V @ 1 A

AC [email protected]

• Power Selection: PCI Bus or External power(7~30 V) by jumper

• Mechanical Endurance: 108times

• Electrical Endurance: 5*107times at 12 V / 10 mA

PCLD-8751 & PCLD-8761 User Manual 4

1.4.3 General

PCLD-8751

• Dimensions: 255 x 121mm

• Power Consumption: Max. +5 V @ < 0.6 A

• Screw Terminals: Accepts #14 to #24 AWG wires

PCLD-8761

• Dimensions: 285 x 121mm

• Power Consumption: Max. +5 V @ < 1.6 A

• Screw Terminals: Accepts #14 to #24 AWG wires
