K4254V3 6/01

Table of Contents

– 2 –

ABOUT THE UNIVERSAL VOICE SYSTEM

(UVS)............................................................3

USER OPERATION SUMMARY..................4

2-WAY VOICE OPERATION (CENTRAL

STATION) ....................................................6

2-WAY VOICE OPERATION (USER)..........7

Modes.......................................................7

Starting Voice Session .............................8

Telephone Key Commands......................9

Setting Listen Mode Volume...................11

Ending Voice Session.............................11

Programming User Access Code...........12

INTERCOM OPERATION..........................13

Push-to-Talk/Release-to-Listen..............13

Private, Hands-Free Conversations .......14

Monitor Mode..........................................14

Muting.....................................................14

SPEAKERPHONE INTERFACE................15

Phone Flash ...........................................15

Paging ....................................................15

ALARM ANNUNCIATION ..........................16

VOICE STATUS MESSAGES....................16

MUSIC BROADCAST ................................16

FEATURE PRIORITY ................................17

System Overview

– 3 –

About the Universal Voice System (UVS)

Congratulations on your ownership of an ADEMCO Universal Voice

System (UVS). The ADEMCO UVS is comprised of a Universal Voice

Control Module (UVCM or UVCM–EU/A) and Universal Voice Station

(UVST).

The the UVCM or UVCM–EU/A, along with stations, comprise an

audio system that offers central station 2-way voice, user 2-way voice,

intercom, speakerphone, and alarm annunciation features. The

UVCM or UVCM–EU/A serves as a central audio controller. It

establishes audio signal pathways between the incoming telephone

line and stations, or between individual stations, based on the feature

being used.

The stations serve as the user interface. Each has a built-in

microphone and speaker that send audio signals to and receive audio

signals from the system. Each station has three keys, two LEDs, and

a volume control dial for controlling system operation and for

annunciating system status.

Depending on your specific installation, your Universal Voice System

may have up to 7 stations installed. These stations will have been

installed at various locations inside your premises; however, up to

two stations may have been installed outside your premises near the

front and/or back door. Stations that are installed inside your

premises are referred to as inside stations, and support all features.

Stations that are installed outside your premises are referred to as

outside stations. These stations support limited intercom, central

station, and user 2-way voice features.

Operation Summary

– 4 –

User Operation Summary

The following tables summarize the user operations for the intercom,

speakerphone, and 2-way voice features. No user operations are

required for the other features.

Intercom and Speakerphone Operations

Feature Operation Station Key Action

Broadcast inside,

then listen. IN Hold to broadcast,

release to listen.

Hold private

conversation inside. IN Press momentarily after

being paged.

Broadcast outside,

then listen. OUT Hold to broadcast,

release to listen.

End intercom

session. END Press momentarily.

Mute on. END Hold for 4 seconds.

Mute off. END Press momentarily.

Monitor on. IN & END Press simultaneously.

Intercom

Monitor off. END Press momentarily.

Pick up phone call or

flash. END & OUT Press simultaneously.

Put caller on hold,

then page person

being called.

IN or OUT Hold to broadcast page,

release to listen for

responses to page.

Pick up held call. END & OUT Press simultaneously.

Transfer call to

another station. END & OUT Press simultaneously

on other station.

Speakerphone

Hang up call. END Press momentarily on

station to which call is

connected.

Operation Summary (cont’d)

– 5 –

User 2-Way Voice Operations

Feature Operation Telephone

Keys Action

Initiates voice session in

low-volume Listen mode. 6-Digit

Access Code Call premises and

enter code.

Selects Talk mode. 1 Press momentarily.

Selects 2-way

conversation (VOX)

mode.

2 Press momentarily.

Selects Listen mode. 3 Press momentarily.

Repeat to toggle

between low, mid and

high volume.

Selects next inside station

and disables all other

stations.

4 Press momentarily.

Repeat to select next

inside station in

sequence again.

Re-initializes 90-second

timeout. 7 Press momentarily.

Returns to low-volume

Listen mode with all

stations enabled.

0 Press momentarily.

Clears key buffer. # Press momentarily.

Ends voice session. 99 (see note) Enter both digits.

NOTE: Pressing the

“END” key on any

station can also end

voice session.

2-Way

Voice

Selects station number

“n” where “n” is 1-7;

disables all other stations.

✶8n Enter all three digits.

2-Way Voice Operation

– 6 –

2-Way Voice Operation (Central Station)

If programmed, this feature allows a central station operator to listen

and/or talk to individuals at the premises via the stations following

receipt of an alarm report from the premise’s alarm system. This

helps to prevent false alarms and in cases of an actual alarm, allows

the operator to gather information about the nature and locations of

the alarm that may be helpful to the responding fire, police, or rescue

agencies. This feature works in conjunction with the premises alarm

system and is controlled by the central station operator; it does not

require any intervention by you.

2-Way Voice Operation (cont'd)

– 7 –

2-Way Voice Operation (User)

If programmed, this feature allows an individual with a valid 6-digit

access code to listen and/or talk to individuals on the premises after

first calling the premises and then entering the access code from a

TouchTone (multi-frequency) telephone keypad.

Modes

The system provides three 2-way voice-operating modes that you can

select via telephone key presses.

2-Way Voice Operating Modes

Mode Description

Talk Allows you to talk through all inside stations simultaneously or

through one selected inside or outside station.

Listen Allows you to listen through all inside stations simultaneously or

through one selected inside or outside station.

VOX (2-way

conversation) Allows you to hold a hands-free conversation with individuals at

all inside stations simultaneously or at one selected inside or

outside station.

2-Way Voice Operation (cont’d)

– 8 –

Starting Voice Session

Start a voice session as follows:

Step Action

1 Call the premises from a key-type TouchTone (multi-frequency)

telephone.

If… then…

there IS an answering machine on the

premises wait for it to pick up the

call and complete its

greeting message.

there is NO answering machine on

premises

the system will pick up

the call after the 6th ring

and issue a continuous

command prompt beep.

Enter your 6-digit user access code.

If…

then…

the system detects a valid access code the system will go off-

hook (if an answering

machine picked up the

call) and then will start the

session in low-volume

Listen mode.

one of the following conditions is met:

• you do not press a key within 10

seconds

• you press keys but the system does

not detect a valid code within 20

seconds

• you make 3 unsuccessful attempts to

enter the access code

the system will stop

listening for the access

code and will hangup if it

has picked up the call.

2-Way Voice Operation (cont’d)

– 9 –

Telephone Key Commands

You can enter the commands listed below from a telephone keypad to

control the voice session.

Telephone Key Commands

Key

Entry Function

1 Selects high-volume Talk mode. When first pressed, you can talk

through all installed inside stations simultaneously. You may then elect

to talk through one specific station by entering the “4” or “✶8n”

command.

2 Selects 2-way conversation (VOX) mode. When first pressed, you can

hold a hands-free conversation with individuals at all installed inside

stations simultaneously. You may then elect to hold a hands-free

conversation with individuals at one specific station by entering the “4”

or “✶8n” command.

3 Selects Listen mode. When first pressed, you can listen through all

installed inside stations simultaneously using low -volume Listen mode.

Subsequent depressions of this key will cycle the volume from low

volume to mid volume to high volume and then back to low volume. You

may then elect to listen through one specific station by entering the “4”

or “✶8n” command.

4 Selects next inside station. When first pressed, the system deactivates

all inside stations except the lowest numbered one while maintaining the

previously selected Talk, Listen, or VOX mode. Subsequent

depressions of this key will activate the next inside station in numerical

sequence (or jump from the highest numbered station to the lowest

numbered one) while deactivating the previously active station. The

system will automatically skip over stations that are not installed. You

can use the “0” command to select Listen mode with all installed inside

stations re-enabled.

2-Way Voice Operation (cont’d)

– 10 –

Key

Entry Function

7 Re-initializes 90-second voice session timeout. The system

automatically ends the voice session 90 seconds after it started unless

the “7” command (or one of the other commands) is entered to re-

initialize the timeout.

0 Switches from presently active mode to Listen mode with all installed

inside stations enabled and with low volume selected.

# Used to clear an initially incorrect key press when multiple commands

such as “99” or “✶8n” are being entered so that a corrected command

can be entered. Also used to clear any incorrect access code digits that

were entered so that a correct code can be entered.

99 Ends 2-way voice session.

NOTE: Pressing the “END” key on any station can also end voice

session.

✶8n Selects station number “n” where “n” ranges from 1 to 7. When pressed,

the system deactivates all but the selected inside or outside station

while maintaining the previously selected Talk, Listen, or VOX mode.

NOTE: The system will go to the selected station even if this station is

an outside station or if this station is not installed (nothing will be heard

in Listen or VOX mode). You can use the “0” command to select Listen

mode with all inside stations enabled.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de seguridad de ADEMCO

ADEMCO

ADEMCO VISTA-20P Series Manual de usuario

ADEMCO

ADEMCO Vista Series 4120EC Manual de usuario

ADEMCO

ADEMCO Security System VISTA-10SE Instrucciones de funcionamiento

ADEMCO

ADEMCO LYNXR24 Manual de usuario

ADEMCO

ADEMCO via30+ Manual de usuario

ADEMCO

ADEMCO VISTA-128B Manual de usuario

ADEMCO

ADEMCO VISTA-15P Series Manual de usuario

ADEMCO

ADEMCO VISTA-32FB Instrucciones de montaje

ADEMCO

ADEMCO Defender II Manual de usuario

ADEMCO

ADEMCO Security System VISTA-10SE Instrucciones de funcionamiento

ADEMCO

ADEMCO VISTA-32FB Instrucciones de funcionamiento

ADEMCO

ADEMCO VISTA-50PUL Manual de usuario

ADEMCO

ADEMCO Security System VISTA-15 Instrucciones de montaje

ADEMCO

ADEMCO Vista AT 4140 Manual de usuario

ADEMCO

ADEMCO 4110DL Manual de usuario

ADEMCO

ADEMCO 4130XM Manual de usuario

ADEMCO

ADEMCO VISTA-50P Guía de instalación

ADEMCO

ADEMCO LYNXR Manual del propietario

ADEMCO

ADEMCO VISTA-32FB Manual de usuario

ADEMCO

ADEMCO VISTA-32FB Instrucciones de montaje

ADEMCO

ADEMCO Security System VISTA-10SE Manual de usuario

ADEMCO

ADEMCO 4110DL Manual de usuario

ADEMCO

ADEMCO 4286 - Ademco Phone Module Manual de usuario

ADEMCO

ADEMCO 4180 Manual de usuario

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario
