UltraWAVE CDMA

Next Generation CDMA 2000 Solution

6/08 • 106330AE Next Generation CDMA 2000 Solution

www.adc.com • +1-952-938-8080 • 1-800-366-3891

UltraWAVE CDMA

Next Generation CDMA 2000 Solution

UltraWAVE CDMA, is a future proof, IP-based

CDMA 2000 solution that provides wireless

telephony and always-on data for mobile

and fixed applications.

The system provides an optimal solution for

small to medium scale networks in urban,

suburban and rural areas. Its distinctive

distributed IP architecture minimizes operators’

initial investment and expedites time-to-market.

Product Highlights

UltraWAVE CDMA is a wireless solution that

supports next generation networks (NGN) for

mobile and fixed applications, based on the

widely deployed CDMA 2000 standard. The

system provides carrier-class telephony and

always-on data for subscribers requiring fixed,

limited or full mobility connections.

Minimizing initial network costs, its IP-based

architecture, combined with a distributed

structural design, makes the UltraWAVE CDMA

an unmatched compact infrastructure solution.

A full range of carrier-class telephony services

ensures subscriber satisfaction by delivering

high-quality voice and data services. Value

added services (VAS) such as voicemail, pre-paid

and SMS are supported. Always-on packet data

up to 153 Kbps is also supported.

6/08 • 106330AE Next Generation CDMA 2000 Solution

www.adc.com • +1-952-938-8080 • 1-800-366-3891

UltraWAVE CDMA

Next Generation CDMA 2000 Solution

Key Advantages

Low Total Cost of Ownership

Reduces end-users’ deployment costs using •

standard CPEs

Lowers operating costs due to distributed •

and compact architecture

Decreases network complexity through •

voice and data payload convergence

Uses IP backhaul and off-the-shelf IP •

core network equipment

Optimal For Rural Deployments and

Network Extensions

Reduces number of cell sites due to wide •

coverage range

Enables call termination within the local cell for •

reduced satellite backhaul costs

Minimal Initial Investment

Provides a scaleable ‘pay-as-you-grow’ expansion

model due to its distributed architecture:

Grows seamlessly from a self-contained •

network in a single rack to a nationwide,

full-fledged distributed network

Scales from a single carrier, omni directional •

base station into a high-capacity multicarrier,

multi-sector cell

Deployment Flexibility

Supports connection to PSTN over a variety •

of interfaces: V5.2, ISUP SS7 and ISDN PRI

Enables rapid and optimized access for remote •

cells using both terrestrial and VSAT backhaul

Enables both long range macro cells or pico •

indoor cells

Ready For Next Generation

Networks (NGN)

UltraWAVE CDMA aligns closely with the •

development of MMD, IMS and NGN

networks. At the same time it offers seamless

integration with legacy circuit switched

networks via a Media Gateway

Grants new operators a solution establishing •

an IP-based network architecture today

Allows future migration from legacy networks •

as IP architecture enables the reuse of system

building blocks

Future Proof Solution

Supports easy migration from fixed to •

mobile services

Allows for seamless integration of future •

data services (EV-DO and WiMAX)

ADC

6/08 • 106330AE Next Generation CDMA 2000 Solution

www.adc.com • +1-952-938-8080 • 1-800-366-3891

UltraWAVE CDMA

Next Generation CDMA 2000 Solution

Applications

UltraWAVE CDMA can be configured to fit

in a variety of applications for mobile and

fixed applications.

Mobile UltraWAVE CDMA Networks

UltraWAVE CDMA can be installed as a

self-contained network for mobile operators

who are looking for a complete network solution.

This solution fully harnesses the scalability and

cost-efficiency of UltraWAVE CDMA to offer

attractive voice and 153 Kbps packet data

services at competitive rates.

The self-contained network serves a variety

of specialty markets, such as military and

government applications and disaster recovery.

In some cases the self-contained network is a

roaming network, e.g. cruise ship applications.

As a revenue generator, UltraWAVE CDMA

offers the operator a variety of value added

services; including, voicemail, prepaid and SMS.

Either ADC VAS servers or the operator’s third

party servers may be used. Also a variety of

supplementary services are available.

Reduced backhaul costs also make UltraWAVE

CDMA an excellent extension to existing mobile

CDMA2000 networks. Network extensions

can be built around self-contained networks

or by interconnecting an existing MSC with

the UltraWAVE CDMA BSC. In both cases

coverage can be provided in areas previously

considered unreachable.

Fixed UltraWAVE CDMA Networks

For ILECs who want to extend their networks

in a cost efficient manner, UltraWAVE CDMA

comes as a pure access solution. Existing local

exchanges (Class 5 switches) can provide existing

services seamlessly over a V5.2 access interface to

new remote areas. In this case, UltraWAVE CDMA

acts as a cost-efficient “pipe” that can turn

unreachable areas into new revenue generators.

The pure access solution eliminates the need for

a mobile switching center (MSC), which reduces

the system complexity, time to market and total

cost of ownership.

CLECs who are looking for a complete solution

should consider a self-contained network

featuring the UltraWAVE CDMA Softswitch and

Value Added Servers. In particular, the scalability

of UltraWAVE CDMA makes it a feasible choice

even in very sparsely populated markets.

UltraWAVE CDMA Network Conguration

6/08 • 106330AE Next Generation CDMA 2000 Solution

www.adc.com • +1-952-938-8080 • 1-800-366-3891

UltraWAVE CDMA

Next Generation CDMA 2000 Solution

BS Plus

IP Network

Softswitch

CDMA2000

BS Plus

CDMA2000

Flexible IP Architecture

for Today and Tomorrow

UltraWAVE CDMA’s distributed architecture

effectively integrates legacy BSC and the BTS into

a single compact unit. As a result, UltraWAVE

CDMA is the ideal solution for rural areas and

sparsely populated towns. This architecture also

minimizes carriers’ initial investment for larger

network roll-outs, while ensuring rapid return on

investment. Taking advantage of the attractive

economics of standard IP-based infrastructure

technologies, UltraWAVE CDMA cuts the total

cost of the network. This design approach also

enhances system flexibility in addressing various

network configurations, including V5.2, SS7 and

PRI as well as combinations of them.

Both new and established fixed carriers

and mobile operators benefit from deploying

UltraWAVE CDMA. The all-IP architecture allows

operators an easier migration path to MMD, IMS,

and NGN. While new operators can immediately

establish next generation networks (NGN),

established carriers can build upon their

legacy systems now with seamless migration

in the future.

Furthermore, the all-IP based architecture

facilitates the introduction of IP transmission

between the RAN and the CN for operators

who are planning ahead for IP-based

multimedia services.

Local Switching

A major part of any operator’s OPEX is the cost

of backhauling traffic from the radio access

network (RAN) to the core network (CN). Due

to UltraWAVE CDMA’s unique capability to

offer local switching, substantial savings can

be achieved. The key benefit is that calls that

are terminated intra cell or inter cells can be

switched locally so that the payload does not

occupy any bandwidth over the backhaul system.

Only the signalling is carried between the RAN

and the CN. The result is significant reductions

in backhaul bandwidth requirements and lower

OPEX (via satellite or leased line) and CAPEX

(via procured terrestrial backhaul).

In addition to cost savings on the backhaul,

the introduction of local switching means

less consumption of switching resources. This

translates into less investment in trunk capacity.

UltraWAVE CDMA Local Switching Conguration

6/08 • 106330AE Next Generation CDMA 2000 Solution

www.adc.com • +1-952-938-8080 • 1-800-366-3891

UltraWAVE CDMA

Next Generation CDMA 2000 Solution

System Elements

Enabling operators to build networks with a

minimal initial investment and expand in relation

to demand, UltraWAVE CDMA is comprised of

the following system elements:

Micro BS Plus - a compact and

modular rack mounted, small

footprint base station. The BS

Plus integrates the BSC and BTS

functions into a single unit and

supports local switching of intra-cell

calls. Seamlessly scaleable in both

frequency carriers and sectors per

cell, it offers maximum coverage and optimal

capacity. Eliminating the need for a central BSC

results in outstanding cost effectiveness for

deployments of small to medium networks.

Micro BS Plus is available in all standard

CDMA2000 frequency bands: 450, 850,

1900, and 2100 MHz.

Pico BS Plus - a flexible

indoor platform: Ideal for

in-building environments or

to fill-in shadowed areas.

The pico BS Plus integrates

the BSC and BTS functions

into a single unit and supports local switching of

intracell calls. Its compact form makes it suitable

for pole or wall mounting. The unit supports

voice and data over 1 or 2 carriers. Pico BS Plus

is available in all standard CDMA2000 frequency

bands: 850, 1900, and 2100 MHz.

Softswitch - an IP call

server, manages the radio

access network (RAN)

and the trunk gateways

enabling significant savings on backhaul by

providing local termination of intracell phone

calls. The call server is a small rack mounted

unit that supports full redundancy. It is centrally

located in the network regardless of the voice

traffic path and economically fits networks of

all sizes up to 100,000 subscribers. The call

server supports interconnection for both PRI and

SS7 and enables least-cost-call routing among

multiple trunk gateways.

Trunk Gateway -

a modular and scaleable,

rack mounted signaling

and media gateway that

communicates with the

PSTN and PLMN over SS7 or PRI links. Multiple

trunk gateways that are geographically distributed

can be managed by a single soft-switch, reducing

the cost of interconnection to the network.

Various trunk gateway sizes are available from 2

E1/T1s 1U compact unit up to 72 E1s/T1s.

Access Gateway - a modular

and scaleable, rack mounted

signaling and media gateway.

Located at either the class 5

switch or a remote site, the access gateway

connects to one or many base stations (BS Plus)

over an IP network. In this way, traffic for an

entire service area is efficiently aggregated from

many base station sites over a backhaul link into

one central V5.2 gateway. Two sizes of access

gateways are available: Small, supporting 2 - 12

E1s or Large, supporting 18 - 36 E1s.

PDSN - an optional

rack-mounted unit, used

as a service node for

packet data transmission

for always on data access. Centrally located, the

PSDN efficiently aggregates the data traffic from

the radio network and communicates with the

operator’s AAA server.

OMC - an easy-to-use

and comprehensive

network management

system. The OMC enables

remote monitoring,

alarm management and

configuration, which translates to savings in both

maintenance time and expenses.

6/08 • 106330AE Next Generation CDMA 2000 Solution

www.adc.com • +1-952-938-8080 • 1-800-366-3891

UltraWAVE CDMA

Next Generation CDMA 2000 Solution

Specifications

TELEPHONY SERVICES

Voice coding: EVRC or QCELP

Extended services: Full transparency over V5.2 for: TAX Metering (12/16KHz), Reverse Polarity,

CLASS 5 supplementary services

Always-On Data Services: 153.6kbps packet Data

MICRO BS PLUS

Frequency bands: 450, 850, 1900, 2100MHz

Air protocol: CDMA-1X RTT 3GPP2 Release 0, IS-95

Sectors: 1 to 3

Carriers per sector: 1 carrier

Transmit power: 20 Watt at Antenna port per carrier per sector

IP network interface: 100BaseT

Environmental: 0 to +50°C, indoor

Rack Dimensions (WxHxD): 42cm x 62.5cm x 36cm

Compliance: FCC Part 15 and 22; UL 60950

PICO BS PLUS

Frequency bands: 850, 1900, 2100MHz

Air protocol: CDMA-1X RTT 3GPP2 Release 0, IS-95

Sectors: 1

Carriers per sector: 1-2 carriers

Transmit power: 100mW at Antenna port per carrier per sector

IP network interface: 100BaseT

Environmental: 0 to +50°C, indoor

Rack Dimensions (WxHxD): 32cm x 30.5cm x 13cm

Compliance: FCC Part 15 and 22; UL 60950

SOFTSWITCH

Management Interface: SNMP MIBs Web browser

IP network interface: 100BaseT

Capacity: Call Processing 150,000 BHCA

Capacity: Traffic 2,500 Erlangs

Capacity: VLR 100,000 subscribers

Capacity: HLR 100,000 subscribers

ACCESS GATEWAY

PSTN: Interface V5.2

Capacity: 2 to 36 E1

IP network interface: 100BaseT

TRUNK GATEWAY

PSTN interface: ISUP SS7 / ISDN PRI

Capacity: 2 to 72 E1/T1

IP network interface: 100BaseT

Value Added Service: VMS, SMS, PPS, AC

OPERATION, MAINTENANCE & CONTROL (OMC)

Platform: Linux/SUN based (Window PC optional)

Protocols: SNMP, Web based

Next GeNeratioN CDMa 2000 SolutioN

Website: www.adc.com

From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080

Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our website.

ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101

Specifications published here are current as of the date of publication of this document. Because we are continuously

improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may

verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.

views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features

contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Hardware de red de ADC

ADC

ADC Digivance Manual de usuario

ADC

ADC Cross-Connect Family FlexDSX Manual de usuario

ADC

ADC Fiber Optic Panel FL2000 Series Manual de usuario

ADC

ADC H2TU-C-388 HiGain Instrucciones de funcionamiento originales

ADC

ADC HiGain H2TU-C-319 List 4E Instrucciones de funcionamiento originales

ADC

ADC ComProtect Building Entrance Terminals (BET) Manual de usuario

ADC

ADC PG-FlexPlus PG-CAB001 Manual de usuario

ADC

ADC ETP-64 Manual de usuario

ADC

ADC H2TU-C-388 HiGain Manual de usuario

ADC

ADC UniPatch GigE Series Manual de usuario

ADC

ADC Campus-RS Remote Manual de usuario

ADC

ADC HiGain H2TU-C-319 List 4E Instrucciones de funcionamiento originales

ADC

ADC FPL Series Manual de usuario

ADC

ADC HIGAIN H4TU-C-388 Instrucciones de funcionamiento originales

ADC

ADC HiGain Wideband 3190 Manual de instalación y operación

ADC

ADC H2TU-C-231 List 2F Instrucciones de funcionamiento originales

ADC

ADC HiGain H2TU-C-231 Instrucciones de funcionamiento originales

ADC

ADC H2TU-C-388 HiGain Instrucciones de funcionamiento originales

ADC

ADC H2TU-C-202 Instrucciones de funcionamiento originales

ADC

ADC HiGain HDSL2 Manual de usuario

ADC

ADC HRE-602 List 1 Manual de usuario

ADC

ADC FlexWave WMX 100/105 Manual de usuario

ADC

ADC H2TU-C-388 HiGain Instrucciones de funcionamiento originales

ADC

ADC H2TU-C-202 Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario

Lanner

Lanner NCA-1525 Manual de usuario
