Acrosser Technology AR-B5630 Manual de usuario

Revision: 2.01

AR-B5630 Board

Socket P Intel® Core™2 Duo EPIC SBC

with Intel® GME965 Express Chipset

, DVI/LCD, Dual LAN and PCI-104

Eexpansion

User Manual

Manual Rev.: 2.01

Book Number: AR-B5630-2010.06.30

Revision: 2.01

Revision

Version Date Author Description

2.01 2010/06/30 Roger Nan Initial release

Revision: 2.01

Manual’s first edition: June 30, 2010

For the purpose of improving reliability, design and function, the information in this document is

subject to change without prior notice and does not represent a commitment on the part of the

manufacturer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or

consequential damages arising out of the use or inability to use the product or documentation, even

if advised of the possibility of such damages.

This document contains proprietary information protected by copyright. All rights are reserved.

No part of this Manual may be reproduced by any mechanical, electronic, or other means in any

form without prior written permission of the manufacturer.

Trademarks

AR-B5630 is a registered trademarks of Acrosser; IBM PC is a registered trademark of the

International Business Machines Corporation; Pentium is a registered trademark of Intel

Technologies Inc; Award is a registered trademark of Award Software International Inc; other

product names mentioned herein are used for identification purposes only and may be trademarks

and/or registered trademarks of their respective companies.

Revision: 2.01

Table of Contents

1 Introduction ..........................................................................................5

1.1 Features .......................................................................................................... 5

1.2 Package Contents .......................................................................................... 7

1.3 Block Diagram ................................................................................................ 8

2 H/W Information....................................................................................9

2.1 Locations......................................................................................................... 9

2.2 Connector and Jumper Setting Table......................................................... 12

3 BIOS Setting .......................................................................................19

3.1 Main Setup .................................................................................................... 20

3.2 Advanced Chipset Setup .............................................................................21

3.3 Power Setup.................................................................................................. 22

3.4 PnP/PCI Setup............................................................................................... 23

3.5 Peripherals Setup......................................................................................... 24

3.6 PC Health Setup............................................................................................ 25

3.7 Boot Setup .................................................................................................... 26

3.8 Exit Setup...................................................................................................... 27

3.9 BIOS Update.................................................................................................. 29

　Watch Dog Timer Reset Sample Code (IT8712F-A/IX-L)................30

　NOTE 1:..............................................................................................32

Revision: 2.01

1 INTRODUCTION

Welcome to the AR-B5630 ECIP AT/ATX Single Board Computer. The AR-B5630 is EPIC

board with Socket P Intel Core™2 Duo or Core Duo or Core Solo and Celeron M processor and

Intel GM965 + ICH8M Chipset. The memory contents one DDR2 SO-DIMM socket which supports

up to 2GB of memory. Graphics display functionality is provided by Build-in Graphic Processor that

supports CRT display and LVDS interface with Single or Dual channel panel specifications.

Ethernet connectivity comes from the Intel WG82574L10/100/1000 M Ethernet controller.

1.1 Features

 Processor: Core 2 Duo, Core Duo and Celeron M

 Chipsets: GME965 + ICH8M

 Memory: DDR2 667MHz SO-DIMM, Maximum 2GB

 Display: VGA, DVI, LVDS, S-Video, BNC, Component video

 Storage: 1x CF, 1x SATA II, 1x IDE

 Audio: 5.1 CH Audio Realtek ALC662

 Communication: 2x Gbps Ethernet, 4x USB 2.0, 3x RS-232, 1x RS-232/422/485

 General: Watchdog timer, 8-bit GPIO, and PCI-104 expansion slot.

Specifications

Model Name  AR-B5630 V 2.0

Product

Descriptions EPIC SBC support 65nm Intel uFC-PGA 478 Core 2 Duo/Core Duo/Core

Solo/Celeron M Processors with Dual Gigabit LANs / LCD / TV out / DVI

General Note

CPU  Socket for Intel uFC-PGA 478 Core 2 Duo/Core

Duo/Core Solo/Celeron M, Coolers required.

BIOS AWARD

System Chipsets  Intel GM965 + ICH8M

System Memory  One SO-DIMM socket support 667/533 MHz DDR2

SDRAMupto 2GB

Watchdog Timer Software programmable 1~255 Seconds

Battery Lithium Battery, 3V 220mAH For RTC

Power

Requirements  AT: 12V Single Voltage Input

 ATX: Power switch pin header and pin header for

external 5V stand-by input

Pin Header

Hardware

monitoring 1. CPU voltage

2. CPU and System Temperature

3. System and CPU FAN speed

4. System Fan Speed Control same as AR-B1892

(connector color different from CPU Fan connector)

BIOS Support

ProtectU N/A

Revision: 2.01

LED 2 LEDs for Power and HDD

Power LED (Green), HDD (Orange) refer to AR-B1831

Button Reset button (use pin header) PinHeader(2.0mm)

Fan connector 1. CPU fan

2. System Fan with temperature controller

(connector color different from CPU Fan

connector)

OS Win XP/XP Embedded, WinCE, Linux, Vista

Video

Graphic Controller Intel GM965 integrated GMA X3100 graphic controller

VGA Memory: Intel DVMT 4.0 supports Max 224 MB

shared video memory

Dual Display

CRT 1 x VGA port D-Sub15

DVI 1 x DVI port Pin Header

TV Out 1 x TV Out (S-Video) Pin header

LCD 1 x Dual Channel 18/24-bits LVDS Interface

LCD inverter power connector and ON/OFF control

Support 3.3V and 5V LCD

Hirose

Audio

Audio Interface 5.1 CH Audio Realtek ALC662 Pin Header

Storage

IDE 1 x E-IDE 44-Pin Header

SSD 1 x Compact Flash Type-II Type-II Socket

FDC N/A

SATA 1 x SATAinterface

One with standard SATA connector 1xSATAConnector

Network Interface

Ethernet 1 x Intel WG82574L (10/100/1000Mbps)

1 x Intel WG82574L (10/100/1000Mbps)

Boot on LAN, WOL

RJ45

I/O 1 x RS-232 (COM1) DB9

Serial Port 2 x RS-232 (COM3/4)

1 x RS-232/422/485 (COM2) Pin Header

Touch Screen N/A

Parallel Port N/A

GPIO 8 Independent TTL level I/O PinHeader

(2x5x2.0)

USB 2 x External ports

2 x Internal ports Connector

Pin Header

(1x5x2.0)

Audio 5.1 CH Audio Pin Header

Expansion slot 1 x PCI-104 (PCI Interface) Slot

Keyboard/ Mouse 1 x PS/2 for Keyboard and Mouse Connector

Mechanical

Dimension 115mm x 165mm (4.528 x 6.496 inches)

Operating

Temperature 0~60oC (32~140oF)

Storage

Temperature -20~80oC (-4~176oF)

Relative Humidity 0 to 90% @ 40°C, non-condensing (95% @ 40°C, Non-Condensing by request)

EMC & Safety

EMC CE, FCC Class A

Safety N/A

Revision: 2.01

1.2Package Contents

In addition to this User's Manual, the AR-B5630 package includes the following items:

 AR-B5630 AT/ATX Single Board

 Quick User Guide

 Utility CD(Include driver and Manual)

 Accessory set ACC-5630 series for purchase separately

 ATX POWER cable (PWR2/ CON2) x 1

 DVI cable (DVI1) x 1

 Audio cable (AUDIO1) x 1

 USB Cable (with screws) x 1

 PS/2 to PS/2 Y-cable (KM1) x 1

 40/44-Pin IDE Cable X1

 Serial port cable (COM) x 2

 SATA HDD Cable (SATA1) x 1

 SATA POWER cable (CON3) x 1

Revision: 2.01

1.3 Block Diagram

Revision: 2.01

2 H/W INFORMATION

This chapter describes the installation of AR-B5630. At first, it shows the Function diagram and

the layout of AR-B5630. It then describes the unpacking information which you should read

carefully, as well as the jumper/switch settings for the AR-B5630 configuration.

2.1 Locations

2.1.1 Top Side

Revision: 2.01

2.1.2 Bottom Side
