ACME Dynamic 25 Spin LED?GF25 Manual de usuario



LED‐GF25



UserManual

Pleasereadtheinstructioncarefullybeforeuse



CONTENTS



1.SafetyInstructions....................................................................................................2

2.TechnicalSpecifications ............................................................................................3

3.HowToSetTheUnit .................................................................................................4

3.1RearPanel...........................................................................................................4

3.2MainFunction ....................................................................................................5

4.HowtoControltheUnit ...........................................................................................9

4.1Master/SlaveBuiltInPreprogrammedFunction ................................................9

4.2EasyController..................................................................................................10

4.3DMXController.................................................................................................10

5.DMX512Configuration ...........................................................................................11

6.DMXConnection ....................................................................................................12

7.Troubleshooting......................................................................................................13

8.FixtureCleaning......................................................................................................14





1.SafetyInstructions



WARNING

yPleasekeepthisUserManualforfutureconsultation.Ifyouselltheunittoanotheruser,be

surethattheyalsoreceivethisinstructionbooklet.

yUnpackandcheckcarefullythereisnotransportationdamagebeforeusingtheunit.

yBeforeoperating,ensurethatthevoltageandfrequencyofpowersupplymatchthepower

requirementsoftheunit.

yIt’simportanttogroundtheyellow/greenconductortoearthinordertoavoidelectricshock.

yTheunitisforindooruseonlyanduseonlyinadrylocation.

yTheunitmustbeinstalledinalocationwithadequateventilation,atleast50cmfromadjacent

surfaces.Besurethatnoventilationslotsareblocked.

yPleasedisconnectmainspowerbeforefusereplacementorservicing.

yPleasereplacefuseonlywiththesametype.

yPleasemakesuretherearenotflammablematerialsclosetotheunitwhileoperatingasitis

firehazard.

yPleaseusesafetycablewhenfixesthisunit.

yMaximumambienttemperatureisTA:40℃anddon’toperateitwherethetemperatureis

higherthanthis.

yUnitsurfacetemperaturemayreachupto60℃.DONOTtouchthehousingbare‐handduring

itsoperation.

yDONOTconnectthedevicetoanydimmerpackorpowerpack.

yDONOTlookdirectlyattheLEDlightbeamwhilethefixtureison.

yThehousingmustbereplacediftheyarevisiblydamaged.

yDONOTtouchanywireduringoperationashighvoltagemightbecausingelectricshock.



For230V50Hzpowersupply,maximumfixturesthatcanbeconnectedtogetherfromthesameoutletis13pcs;

For120V60Hzpowersupply,maximumfixturesthatcanbeconnectedtogetherfromthesameoutletis8pcs;

Pleasereadtheinstructionscarefullywhichincludesimportant

informationabouttheinstallation,operationandmaintenance.

Caution:

Therearenouserserviceablepartsinsidetheunit.DONOTopenthehousingorattemptany

repairsyourself.Intheunlikelyeventyourunitmayrequireservice,pleasecontactyournearest

dealer.

Installation:

Theunitshouldbemountedviaitsscrewholesonthebracket.Alwaysensurethattheunitis

firmlyfixedtoavoidvibrationandslippingwhileoperating.Andmakesurethatthestructureto

whichyouareattachingtheunitissecureandisabletosupportaweightof10timesoftheunit’s

weight.Alsoalwaysuseasafetycablethatcanhold12timesoftheweightoftheunitwhen

installingthefixture.

Theequipmentmustbefixedbyprofessionals.Anditmustbefixedataplacewhereisoutofthe

touchofpeopleandhasnoonepassbyorunderit.



2.TechnicalSpecifications

yLEDgoboflowerwith25WLED,deliveringpowerful,eye‐catchingeffects

y4DMXchannels:Strobe,Gobo/Color,ReflectorandDimmer

y8goboswithdichroiccolorsplusopen

ySmoothdimmingandvariousstrobeeffects

y3operationmodes:DMX,Master/Slaveoperation,SoundActivation

yGreatbuilt‐inshowsundermaster/slavemodetriggeredbymusic

yLEDdisplayforeasynavigation

yOptionaleasycontrollerCA‐8orCA‐9forinstantlightingshows

yLowheat,lowpowerconsumption;nodutycycle,runsallnight

yIdealforpubs,clubs,discos,MobileDJsandmore.



yPowerVoltage:AC100~240V,50/60Hz

yPowerConsumption:45.8W

yFuse:T2A

yLED:1x25WCREELEDs

yWeight:3.7kgs

yDimension:395x240x193mm



3.HowToSetTheUnit

3.1RearPanel



1.POWEROUT:Usedtoconnecttonextunit

2.POWERIN:Usedtoconnecttomainssupply



3.LED:

DMXOnDMXinputpresent

MASTEROnMasterMode

SLAVEOnSlaveMode

SOUNDFlashingSoundactivation

4.Button:

MENUToselecttheprogrammingfunctions

DOWNTogobackwardintheselectedfunctions

UPTogoforwardintheselectedfunctions

ENTERToconfirmtheselectedfunctions

5.FunctionDisplay:Usedtoshowthevariousmenusandtheselectedfunctions.

6.DMXIN:ForDMX512link,use3‐pinXLRplugcabletoconnecttotheDMXcontrollerand

inputtheDMXsignal;

7.DMXOUT:ForDMX512link,use3‐pinXLRplugcabletolinkthenextfixtureandoutputthe

DMXsignal;

8.Microphone:Usedtoreceivemusicforthesoundactivation;

9.Onlyforremotecontrol:UsedtoconnecttotheoptionalCA‐8tocontroltheunitforStand

by,FunctionandModefunction;

10.Onlyforwirelessreceiver:UsedtoconnecttotheoptionalCA‐9tocontroltheunitfor

Standby,FunctionandModefunction;

3.2MainFunction

Toselectanyfunctions,presstheMENUbuttonuntiltherequiredfunctionisshowingonthe

display.SelectthefunctionbypressingtheENTERbuttonandthedisplaywillblink.Usethe

DOWNandUPbuttontochangethemode.Oncetherequiredmodehasbeenselected,pressthe

ENTERbuttontosetuptogobacktothefunctionswithoutanychangespresstheMENUbutton

again.HoldandpresstheMENUbuttonforonesecondorwaitforoneminutetoexitthemenu

mode.

Themainfunctionsareshownbelow:



DMX512ADDRESS

Toselectthe,presstheENTERbuttontoshowtheDMXADDRESSonthedisplay.Usethe

DOWN/UPbuttontoadjusttheaddressfrom1to512.Oncetheaddresshasbeenselected,press

theENTERbuttontosetup,togobacktothefunctionswithoutanychangespresstheMENU

buttonagain.HoldandpresstheMENUbuttonforonesecondorwaitforoneminutetoexitthe

menumode.

SLAVEMODE

Toselectthe,presstheENTERbuttontoshowtheSLAVEMODEonthedisplay.Usethe

DOWN/UPbuttontoselectthe  (MASTER),  (SLAVE1,normal)or  (SLAVE2,

2lightshow)modes.Oncethemodehasbeenselected,presstheENTERbuttontosetup,togo

backtothefunctionswithoutanychangespresstheMENUbuttonagain.Holdandpressthe

MENUbuttonforonesecondorwaitforoneminutetoexitthemenumode.



SHOWMODE

Toselectthe,presstheENTERbuttontoshowtheSHOWMODEonthedisplay.Usethe

DOWN/UPbuttontoselectthe  (Randomshow),  (Show1)or…or(Show

6)mode.Oncethemodehasbeenselected,presstheENTERbuttontosetup,togobacktothe

functionswithoutanychangespresstheMENUbuttonagain.HoldandpresstheMENUbuttonfor

onesecondorwaitforoneminutetoexitthemenumode.



SOUNDMODE

Toselectthe,presstheENTERbuttontoshowtheSOUNDMODEonthedisplay.Usethe

DOWN/UPbuttontoselectthe  (soundon)or  (soundoff)mode.Oncethemode

hasbeenselected,presstheENTERbuttontosetup,togobacktothefunctionswithoutany

changespresstheMENUbuttonagain.HoldandpresstheMENUbuttonforonesecondorwait

foroneminutetoexitthemenumode.



BLACKOUTMODE

Toselectthe,presstheENTERbuttontoshowtheBALCKOUTMODEonthedisplay.Use

theDOWN/UPbuttontoselectthe  (blackout)or  (normal)mode.Oncethe

modehasbeenselected,presstheENTERbuttontosetup,togobacktothefunctionswithoutany

changespresstheMENUbuttonagain.HoldandpresstheMENUbuttonforonesecondorwait

foroneminutetoexitthemenumode.



LEDDISPLAY

Toselectthe,presstheENTERbuttontoshowtheBALCKOUTMODEonthedisplay.Use

theDOWN/UPbuttontoselectthe  (LEDdisplayon)or(LEDdisplayoff)mode.

Oncethemodehasbeenselected,presstheENTERbuttontosetup,togobacktothefunctions

withoutanychangespresstheMENUbuttonagain.HoldandpresstheMENUbuttonforone

secondorwaitforoneminutetoexitthemenumode.



DISPLAYINVERSE

Toselectthe,presstheENTERbuttontoselectthe  (normal)or  (inversion),

pressENTERbuttontosetup.BacktothefunctionswithoutanychangepressMENUbutton.



AUTOTEST

Toselectthe,presstheENTERbuttontoshowtheTESTonthedisplayandtheunitwillrun

aself‐test.TogobacktothefunctionswithoutanychangespresstheMENUbuttonagain.Hold

andpresstheMENUbuttonforonesecondorwaitforoneminutetoexitthemenumode.



TEMPERATURE

Toselectthe,presstheENTERbuttontoshowtheTEMPERATUREonthedisplayandthe

displaywillshowthetemperatureoftheunit.Togobacktothefunctionswithoutanychanges

presstheMENUbuttonagain.HoldandpresstheMENUbuttonforonesecondorwaitforone

minutetoexitthemenumode.



FIXTUREUSEHOURS

Toselectthe,presstheENTERbuttontoshowtheFIXTUREUSEHOURSonthedisplayand

thedisplaywillshowthenumberofworkinghoursoftheunit.Togobacktothefunctions

withoutanychangespresstheMENUbuttonagain.HoldandpresstheMENUbuttonforone

secondorwaitforoneminutetoexitthemenumode.



SOFTWARE VERSION

To select the , press the ENTER buon to show the SOFTWARE VERSION on the display and

the display will show the version of soware of the unit . To go back to the funcons without any

changes press the MENU buon again. Hold and press the MENUbuon for one second or wait

for one minute to exit the menu mode.

RESET

To select the , press the ENTER buon to show the RESET on the display. Press the ENTER

buon and all channels of the unit will return to their standard posion.

4. How to Control the Unit

You can operate the unit in three ways:

1. By master/slave built-in preprogram funcon

2. By easy controller

3. By DMX controller

No need to turn the unit oﬀ when you change the DMX address, as new DMX address seng will

be aﬀected at once. Each me you turn the unit on, it will show “ ” on the display. Aer that

the unit will be ready to receive DMX signal or run the built in programs.

4.1 Master/Slave Built In Preprogrammed Funcon

By linking the units in master/slave connecon, the ﬁrst unit will control the other units to give an

automac, sound acvated, synchronized light show. This funcon is good when you want an

instant show. You have to set the ﬁrst unit in master mode and select (random

show), (show 1) or …or (show 6). Its DMX input jack will have nothing plugged into

it, and its master LED will be constantly on and sound LED will ﬂash to the music. The other units

will have to select (normal) or (2 light show) mode, Their DMX cables plugged into

the DMX input jacks (daisy chain) and the slave LED lights will be constantly on.

Please Note: The Acme Dynamic range of eﬀects, including the Spin, Roller Barrel and Scan, have

been designed to operate together to provide superb synchronised coordinated lightshows. For the

best results, when using a combinaon of ﬁxtures in master/slave mode, please make the Roller

Barrels the ﬁrst ﬁxtures in the chain.
