ACME FARANDOLE AM-BAR Manual de usuario

CONTENTS

1. Safety Instructions..........................................................................................2

2. Technical Specifications..................................................................................3

3. Description.....................................................................................................5

3.1 Control Panel............................................................................................5

4. How To Set The Unit.......................................................................................5

4.1 Main Function ..........................................................................................5

4.2 Error Information .....................................................................................9

5. Control By Universal DMX Controller ...........................................................10

5.1 Connection.............................................................................................10

5.2 Address Setting.......................................................................................11

5.3 DMX 512 Configuration..........................................................................11

6. Troubleshooting ...........................................................................................13

7. Cleaning .......................................................................................................14

1. Safety Instructions

WARNING

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that

they also receive this instruction manual.

Important:

Damages caused by the disregard of this user manual are not subject to warranty. The dealer

will not accept liability for any resulting defects or problems.

Unpack and check carefully that there is no transportation damage before using the unit.

The unit is for indoor use only. Use only in a dry location.

DO install and operate by qualified operator.

DO NOT allow children to operate the fixture.

Use safety chain when fixing the unit. Handle the unit by carrying its base instead of head only.

The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces.

Be sure that no ventilation slots are blocked, otherwise the unit will be overheated.

Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

Maximum ambient temperature TA: 40℃，maximum ambient temperature TA: 0℃.

DO NOT connect the device to any dimmer pack.

During initial start-up some smoke or smell may arise. This is a normal process and does not

necessarily mean that the device is defective, and it will decrease gradually within 15 minutes.

Make sure there are no flammable materials close to the unit while operating to avoid fire hazard.

Examine the power wires carefully; replace them immediately if there is any damage.

Unit’s surface temperature may reach up to 56℃. DO NOT touch the housing bare-handed during

its operation, and allow about 15 minutes for cooling the unit down before replacing bulb or

maintenance as it could be very hot.

Avoid any inflammable liquids, water or metal objects entering the unit. Once it happens, cut off

Please read the instruction carefully which includes important information about

the installation, usage and maintenance.

the mains power immediately.

DO NOT operate in dirty or dusty environment, do clean fixtures regularly.

DO NOT touch any wire during operation as there might be a hazard of electric shock.

Avoid power wires together twist other cables.

The minimum distance between light output and the illuminated surface must be more than 12

meters.

Disconnect mains power before fuse replacement or servicing.

Replace fuse only with the same type.

In the event of serious operating problem, stop using the unit immediately.

Never turn on and off the unit time after time.

The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

DO NOT open the unit as there are no user serviceable parts inside.

Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage

or malfunction. Please contact the nearest authorized technical assistance center if needed.

Disconnect the mains power if the fixture is has not been used for a long time.

DO use the original packing materials before transporting it again.

Cautions:

To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

DO replace the bulb once it is damaged, deformed or life-expired.

DO NOT look directly at the light while the bulb is on.

Never touch bulb with bare fingers, as it is very hot after using.

DO NOT start on the unit when housing is damaged.

2. Technical Specifications

Power supply

AC 100~240V, 50/60Hz

Power Consumption

140W

Light Source

18x8W RGBW LED

Beam Angle

16°

Protocols

DMX Channel: 6/9 channels

Control Mode: DMX512, RDM

Firmware Upgrade: Update via DMX link

Construction

Display: LED display

Data In/Out: 3-pin XLR

Power In/Out: Power Connector in/out

Protection Rating: IP20

Features

Efficient LED lens, uniform color mixing, which makes the light effect better;

0~100% smooth dimming;

Adjustable electronic strobe effect;

Suitable for fixed installation or mobile performance;

The fixture can be adjusted to180° backward and forward by double mounting brackets.

Dimension/Weight

990 x 144 x 150mm, 4.9kgs

39" x 5.7" x 5.9"in, 10.8lbs

Photometrics

3. Description

3.1 Control Panel

1. Display: To show the various menus and the selected function

2. Button:

MENU To enter into move backward or leave the menu

DOWN To go to move down in the menu

UP To go backward to move up in the menu

ENTER To perform the desired functions

3. Power In: Used to connect to supply power

4. Power Out: Used to connect to the next fixture

5. DMX In:For DMX 512 operation, use 3-pin XLR plug cable to link the units together

6. DMX Out: For DMX 512 operation, use 3-pin XLR plug cable to link the units together

4. How To Set The Unit

4.1 Main Function

Turn on the unit, press the MENU button into menu mode, and press the UP/DOWN button until the

required function is shown on the monitor. Select the function by the ENTER button. Use the

UP/DOWN button to choose the submenu, press the ENTER button to store and automatically return

to the last menu. Press the MENU button or let the unit idle one minute to exit menu mode.

In the event of disconnecting with mains power, press the UP button for one minute to enter into

menu mode. Press MENU button or let the unit idle one minute to exit.

The main functions are shown below（the grayed boxes are preset settings）:

DMX Address

Select the , press the ENTER button and the display will blink. Use the DOWN and UP button to

change the DMX 512 address(001-507/504). Once the address has been selected, press the ENTER

button to setup or exit menu mode without any change after 1 minute automatically. Back to the

previous functions without any change, press the MENU button.

Channel Mode

Select the , press the ENTER button. Use the DOWN and UP button to select the channel mode

(6 Channel Mode) or (9 Channel Mode). Once selected, press the ENTER button to

setup or exit menu mode without any change after 1 minute automatically. To go back to the functions

without any change, press the MENU button.

DMX State

Select the , press the ENTER button. Use the DOWN and UP button to select (Blackout)

or (Hold). Once selected, press the ENTER button to setup or exit menu mode without any

change after 1 minute. Back to the functions without any change, press the MENU button.

Dimmer Curve

Select the , press the ENTER button. Use the DOWN and UP button to select (Dimmer

Curve 1) … (Dimmer Curve 4). Once selected, press the ENTER button to setup or exit menu

mode without any change after 1 minutes. Back to the functions without any change, press the

MENU button.

Dimmer curve 1 Dimmer curve 2 Dimmer curve 3 Dimmer curve 4

Optically Linear Square Law Inverse-Square Law S-Curve

Mode 1(Optically Linear): The increase in light intensity appears to be linear as DMX value is increased.

Mode 2(Square Law): Light intensity control is finer at low levels and coarser at high levels.

Mode 3(Inverse Square Law): Light intensity control is coarser at low levels and finger at high levels.

Mode 4(S-curve): Light intensity control is finger at low levels and high levels and coarser at medium

levels.

Dimmer Speed

Select the , press the ENTER button. Use the DOWN and UP button to select (Fast)

or (Smooth). Once selected, press the ENTER button to setup or exit menu mode without

any change after 1 minute. Back to the functions without any change, press the MENU button.

Display Inverse

Select the , press the ENTER button. Use the DOWN and UP button to select or

. Once selected, press the ENTER button to setup or exit menu mode without any change after

1 minute automatically. Back to the functions without any change, press the MENU button.

White Balance

Select the , press the ENTER button. Use the DOWN and UP button to select ,

or . Once selected, press the ENTER button to setup, use the DOWN and UP button to adjust

the value from 125 to 255, press the ENTER button to setup or exit menu mode without any change

after 1 minute automatically. Back to the functions without any change, press the MENU button.

Manual Test

Select the , press the ENTER button. Use the DOWN and UP button to select , ,

, , , , , or . Once selected, press the ENTER button to

setup, use the DOWN and UP button to adjust the value from 0 to 255, press the ENTER button to

setup or exit menu mode without any change after 1 minute automatically. Back to the functions

without any change, press the MENU button.

Auto Test

Select the , press the ENTER button and the unit will run self-test by built-in program. To go

back to the functions, press the MENU button.

Temperature

Select the , press the ENTER button and the display will show the temperature of each unit. To

go back to the functions, press the MENU button.

Fixture Hours

Select the , press the ENTER button and the display will show the working hours of the unit. To

go back to the functions, press the MENU button.

Software Version

Select the , press the ENTER button and the display will show the software version of the unit.

To go back to the functions, press the MENU button.

Defaults

Select the , press the ENTER button. Use the DOWN and UP button to select or

. Once selected, press the ENTER button to setup or exit menu mode without any change after

1 minute automatically. Back to the functions without any change, press the MENU button.

4.2 Error Information

Temperature Sense Error

It appears when temperature check board is damaged.

Memory Initial Fail

It appears when the memory IC is damaged.

CPU-B Error, CPU-C Error, CPU-D Error

They appear when board P.C or some wires are damaged.

Pan Reset Error, Pan Encode Error, Tilt Reset Error, Tilt Encode Error, Shutter Reset Fail, Dimmer

Reset Fail, Color Reset Fail, Cyan Reset Fail, Magenta Reset Fail, Yellow Reset Fail, Gobo1 Reset Fail,

R-Gobo1 Reset Fail, Gobo2 Reset Fail, Iris Reset Fail, Effect Reset Fail, R-Effect Reset Fail, Frost Reset

Fail, Flat Reset Fail, Focus Reset Fail, Zoom Reset Fail

They may appear when turning on or resetting the unit, for some parts such as board P.C are damaged.

Please contact the qualified maintenance.
