AAXA Technologies M1 Ultimate Manual de usuario

Table of Contents 1

Warnings 2

Overview 3

Remote Control Functions 4

Packing List 5

General Operation 6

Startup and control

Shutdown

Positioning / Throw Distance / Focus 7

Connecting to A/V Source 8

Connecting to Computer (USB – VGA Input) 8-9

Using Onboard Media Player 10

Accessing SD Card 10

Accessing Flash Memory 10

Loading les onto ash memory 11

Listening to music / viewing pictures 11

Watching ideos / viewing les 12

USB On-The-Go & Data Transfer 13

Settings 14

Trouble Shooting 15

Specications 16-17

Table of Contents

*Do not operate the Projector in direct sunlight

or near heat sources such as heaters, res, and

stoves as this may cause a re hazard.

*Do not operate the projector close to sources

of steam or oil such as a humidier as this

may cause electric shock.

*Do not operate the projector near water such as by the sink or bathtub as

this may cause electric shock.

*Do not block or restrict airow from ventilation holes as this may cause the

projector to overheat.

*Do not place inammable materials beside the projector as this may cause a

re hazard.

*Do not drop the projector or allow heavy impacts or shock as this will

damage the projector.

Warnings

Overview

Remote Control & Keypad Functions

Keypad

Remote Control

Packing List

Projector Remote Control

A/V Cable USB Cable

Power Cord Tripod

Startup and Shutdown – To startup, connect

the power supply or external battery to the

rear power receptacle. Press and hold the

power button for 3 seconds until the welcome

logo appears. To shutdown hold the power

button for 3 seconds until optical engine

turns o.

Positioning – Position the projector at an even

plane and a right angle to the desired image.

If the projector is not at a right angle or on an

even plane the projected image will appear

distorted.

General Operation

Focus Adjustment / Throw Distance – The

focus can be adjusted by turning the wheel

located at the front of the projector. The

projector is capable of the following throw

and focus distances:

General Operation

Diagonal

size

Diagonal

size

VerƟcal

size

Horizontal

size

Throw

distance

(inch) (mm) (mm) (mm) (mm)

30 762 457 610 1250

40 1016 610 813 1666

50 1270 762 1016 2083

60 1524 914 1219 2499

70 1778 1067 1422 2916

80 2032 1219 1626 3332

90 2286 1372 1829 3749

100 2540 1524 2032 4166

Connecting to a VGA / Computer input

The projector can accept a 15-pin RGB input

source from a laptop’s external monitor port

or graphics card. This source is connected

through the 15-pin “VGA” port on the back

of the projector.

To connect a VGA cable, plug the VGA cable into

the back of the projector. Then select the “VGA PC” option in the Main Menu.

This will enable the projector to receive VGA signals.

Important: Be sure to setup the computer to enable video signal output. If

using the M1 as an external monitor on Windows based systems, this can be

done by selecting “extend my desktop to this monitor.” Note: Each computer

system is dierent – please check with your owner’s manual for how to

properly output video signals. Some Apple computers may require a DVI to

VGA adapter.

Accepted Display Resolutions:

800x600 (native / optimal)

1024x720

1280x800

Connecting an Audio/Video input source - The Projector can accept dier-

ent A/V (Audio/Video) sources through the A/V port. These sources are

connected through a 3.5mm A/V cable.

Max Supported Resolutions:

NTSC: 720x480

PAL: 720x576

General Operation

To connect an A/V cable insert the 3.5mm portion into the A/V

port of the projector. Then click on either the “A/V input” icon

in the main menu, or press “source” on the remote control and

select “A/V input”. A blue screen will appear and the Projector

will be ready to accept an A/V signal.

Possible A/V sources: Composite (included), Iphone / Ipod (optional), Zune

(optional), Playstation Portable (optional), and others. Please check

www.aaxatech.com or your AAXA dealer for optional A/V cables.

USB Data Access and Transfers

The M1 projector includes 1GB of onboard memory for

storage and can function as a USB Host device. For

instructions on how to access the onboard memory and

connect USB devices to the projector, please refer to the

USB On-The-Go & Data Transfer instructions on page 13.

General Operation
