AAXA Technologies OEM-250 Micro Projector Manual de usuario
OEM-250 Micro Projector
User Manual
Table of Contents 1
Warnings 2
Package Contents 3
Product Overview 4
Keypad & Remote Control Functions 5
General Operation 6
External Inputs 8
PMP Menu System 10
Videos 12
Pictures 14
Music 16
eBooks 19
Games 21
Settings 25
Troubleshooting 27
Specications 28
Table of Contents
1
Warnings
*Do not operate the Projector in direct sun-
light or near heat sources such as heaters,
res, and stoves as this may cause a re
hazard.
*Do not operate the projector close to
sources of steam or oil such as a humidi-
erasthismaycauseelectricshock.
*Do not operate the projector near water such as by the sink or bathtub
as this may cause electric shock.
*Donotblockorrestrictairowfromventilationholesasthismaycause
the projector to overheat.
*Do not place inammable materials beside the projector as this may
causearehazard.
*Do not drop the projector or allow heavy impacts or shock as this will
damage the projector.
2
Package Contents
Projector Remote Control Tripod
Composite A/V Cable USB Cable
Power Cord VGA Cable
3
Product Overview
Projection Lens
Focus Adjustment
Keypad Controls
Power Button
4
VGA Input
HDMI Input
AV Input
USB Input
Audio Output
SD-HC Card Slot
Power Input
Keypad & Remote Control Functions
5
Mute Audio
Menu
Volume Controls
Navigation Controls
Menu
Playback Controls
Power
Keystone Adjustment
Escape
Menu
Playback Controls
Power
Volume Controls Back
Sources
General Operation
Turning on the projector
To turn on the projector rst plug the power supply into a suitable wall outlet
and to the rear of the projector. Then power the projector on by holding the
power button for 3 seconds until the optical engine turns on.
Shutting down the projector
To shut down the projector, press and hold the power button for 3 sec. The
optical engine should shut off and the fan should stop spinning.
Adjusting focus
To adjust the focus, spin the focus wheel up or down
until the image becomes clear. The recommended
focus distance for this projector is 10” to innity.
Projection lens
The projection lens emits the image from the projector. Make sure there is
nothing obstructing the lens to obtain a clear image.
Keypad Controls
Use the keypad control buttons to navigate through
each menu. The control panel behaves differently in
each submenu. Controls for submenus are explained
later in this manual.
6
General Operation
Accessing the Onboard Memory
The OEM-250 Micro Projector includes
1GB of onboard memory. To access this
memory, connect a USB cable from your
computer to the back of the projector in
the slot that reads “USB”. A folder will
appear on your computer screen after
the projector is detected. You can store any type of supported photos, video
and/or les in this folder to view.
Note: If your computer fails to detect the projector, check to make sure the
cable is securely inserted on both sides. If you’re still unable to view the
folder, please consult with your operating system’s owner manual.
Accessing a SD Memory Card
Multimedia le can also be accessed via
an SD memory card. To access your SD
card, insert it into the back of the projector
in the slot that reads “SD”. Once your SD
card has been inserted, you can navigate
through the main menu to select what you
want to view under each submenu.
*Review the Specications section of this manual to read about supported le
formats.
7
External Inputs
The OEM-250 micro projector can be toggled to accept different types of
inputs. This includes VGA (Mini VGA), HDMI and Composite Video (3.5mm
jack). To toggle through the sources, press the far right button on touch-
pad or the input button on the remote control to select the appropriate
source.
To Connect to a VGA Source
The projector can accept a VGA input signal.
Connect the VGA cable to your source and
the other end should be inserted in the slot
on the side of the projector that reads ‘VGA’.
Toggle through the input sources and once
you select VGA input, your display should
appear.
Important: Be sure to setup the computer to enable a video signal output.
On some laptops this is done by pressing and holding Function F5 Key. If
using the OEM-250 as an external monitor on Windows based systems, this
can be done by selecting “extend my desktop to this monitor”. The native
resolution of the OEM-250 projector is SVGA (800x600) and it accepts up to
a 1280x800 signal. Depending on the video driver different resolutions many
need to be selected for proper output.
Note: Each computer system is different - please check with your owner’s
manual for how to properly output video signals. Some Apple computers may
requre a DVI to VGA adapter.
8
External Inputs
To Connect to a Composite Video Source
The projector can accept a compositive video
signal. This signal is comes through the 3.5mm
composite A/V cable. Connect the composite
A/V able to the projector and the other end into
the video source. Toggle through the input
sources and once you select AV input, your
display should appear.
To Connect to an HDMI Source
The projector can accept a digital HDMI input
signal. This is done by connecting the HDMI
cable to the HDMI input port of the projector.
Toggle through the input sources and once you
select HDMI input, your display should appear.
The OEM-250 accepts up to a HDMI 1.2 signal.
9
