AAXA Technologies SLC450 Manual de usuario

aaxa

TECHNOLOGIES

User Guide

SLC450 SHORT THROW

MINI PROJECTOR

Caution!

WARNING: Please use this product as instructed. Misuse may cause

injury or death.

DO NOT use while driving

DO NOT expose to water or wet surfaces. Electric shock may occur

DO NOT expose the projected LED image to your eyes or the eyes of others

projector to overheat

Keep the projector, battery, or

charger away from any heat sources

Table of Contents

Chapter 1: SLC450 at a Glance

SLC450 Introduction

Remote & Keypad

Accessories

Chapter 2 : Getting Started

Powering On / Off

Focus Adiustment Throw Distance

Connecting to Speaker / Headphones

Loading External Content

Chapter 3 : Menu Screens

Main Menu

Brightness Menu

Wifi Menu

Mirroring Menu

Streaming Services Menu

Office Menu

Files Menu

Browser Menu

Apps Menu

Connecting to Digital Input

Chapter 4 : Settings Menu

Advanced Settings

Language

Display Settings

Keystone & Projection Direction

Keystone Correction

Bluetooth Menu

Backup/Reset Menu

About Menu

Chapter 5 : Technical Details

Troubleshooting

Specifications

Notes

SLC450 at a Glance

Chapter 1

Main Unit

Power Button

19V D/C Power

Focus Adjustment

Working indicator light

(power on: green;

power off: red)

Headphone Out

Digital AV

(HDMI Compatible)

Navigation Pad

TF Card

Standard USB 2.0

Compatible

Enter

Remote & Keypad

Menu Exit/Back

Direction Pad

Both the keypad and remote can be used to navigate through the menus. The Main Menu

Navigation on the remote functions exactly the same as the directional pad on the SLC450 unit.

Right

Volume Up

keystone +

Short press:OSD

Long press:

Homepage

Play

／Pause

Power On／Off

Left

Down

Volume Down

keystone -

Return

Simulate Mouse

Accessories

Power Adapter

Remote Control

Mini Tripod

*Under various circumstances, the actual accessories may be different from those shown in the pictures above.

Additional accessories are available for purchase at www.aaxatech.com

Getting Started

Chapter 2

Powering ON the projector

1. Connect the power cord to the SLC450.

2. Connect the other end of the power cord into the wall power source.

3. Press the switch on the back of the projector and the projector will turn on automatically.Standby Mode

1. To transition to “STANDBY” mode, press the power button on the remote control.

2. The optical engine should power off and the fan should stop spinning. The projector is now

in “STANDBY” mode and can be turned on using the remote control.

*Note: Standby mode will still consume a small amount of power.

Powering OFF the projector

1. To turn off the projector, press the

"Power Switch" twice. This will turn off

the projector completely.

Focus Adjusment / Throw Distance

• Spin the focus wheel up or down until the image becomes

clear.

Focus Adjustment

DIAGONALSCREEN SIZE

16:9 Aspect Ratio

Throw Distance

Units: Inches

100

Diagonal Size

Units: Inches

112

128

144

160

Throw Distance Chart

Throw Ratio 0.7:1

*minimum throw distance: 10 inches

Connecting Speakers / Headphones

Connect your speakers/headphones to

the projector’s audio port.

Step 1:

Step 2:

*CAUTION: Prolonged use of headphones at a high

volume may impair hearing.

Ensure that the projector and/or the

headphones are powered on.

Step 3: Place the headphones on and enjoy!

Loading External Content

(up to 64 GB)

The SLC450 can read files directly from

both a TF Card and USB drive.

Supported file types include:MP3 / WMA

/ OGG / WAV / AVI / MP4/JPG /

GIF/PDF / DOC/XLS / PPT

(up to 64 GB)
