ZyXEL Communications NBG-420N Manual de usuario

Extreme Wireless Performance and

Dead Spot-Free Coverage

Benefits

802.11n Technology

ZyXEL NBG420N 802.11n Wireless Broadband Router featuring 802.11n

Draft 2.0 Technology provides the ultimate solution for speed and coverage.

With data rate up to 300 Mbps,6x faster than 802.11g standard,the

NBG420N provides stable and reliable wireless connections for high-speed

data and multimedia delivery.The NBG420N eliminates dead zones and

extends 5x coverage by using the upcoming IEEE 802.11n technology, and it

is backward compatible with any IEEE 802.11b/g Wi-Fi certified device.

Media Bandwidth Management

With ZyXEL’s exclusive Media Bandwidth Management v2 (MBM v2™), the

NBG420N provides the most comprehensive way to smartly manage your

limited bandwidth for multimedia applications.

Enhanced Security with WPA2 and Firewall

To protect your wireless data transmissions, the NBG420N provides Wi-Fi

Protected Access and WPA2 featuring AES standard.The NBG420N has

Stateful Packet Inspection (SPI) firewall and VPN pass-through creating a

secure connection at any remote location.Policies can be defined on the

NBG420N providing customized filters.

VPN (Virtual Private Network) Connection

The NBG420N supports IPSec VPN suitable for deployment from remote

sites to the central server. Data encryption over the Internet ensures secure

transmission between two sites, which eliminates the need for expensive

leased lines and enables global interconnectivity at a minimal expense.

ˍġ

Best-of-breed 802.11n Draft 2.0 Wireless Technology

for Extreme 6x Performance and 5x Coverage

ˍġ

2 IPSec VPN Tunnels for Secure Data Transfers from

Remote Sites to the Central Server

ˍġ

Secure Wireless Connection with WPA and WPA2

ˍġ

Built-in MBM v2 Technology for Traffic Shaping

ˍġ

Wi-Fi Protected Setup (WPS) for Easy Wireless

Security Setup

Wireless N Router

NBG420N

ATEWAY

Wireless N Router

NBG420N

System Specifications

• 802.11n Draft 2.0 Wireless

• MBM v2 for QoS

• SPI Firewall

• DMZ

• WPA/WPA2

• DHCP Server/Client

• SIP ALG

• UPnP

• VPN pass-through

• Dynamic DNS (4 Services)

• Connection Type: PPPoE, PPTP, DHCP, Static IP

• Log and Statistics

• 2 IPSec VPN

• Wi-Fi Protected Setup (WPS)

Hardware Specifications

• LAN: Four 10/100Base-T Ethernet,full duplex

RJ-45 connector with auto MDI/MDIX suppor

• WAN:One 10/100Base-T Ethernet, full duplex

RJ-45 connector with auto MDI/MDIX support

• Power: 12 VDC 1.0 A

• Two 1.8 dBi external detachable dipole antennas

Physical Specifications

• Dimensions: 162 (W) x115 (D) x 33 (H) mm

• Weight: 230 g

Environmental Specifications

• Operating temperature: 0ºC ~ 40ºC

• Operating humidity: 20% ~ 85%

• Storage temperature: -20ºC ~ 60ºC

• Storage humidity: 20% ~ 90%

Certification

• Safety: CSA international

• EMI: CE, FCC part 15B

Specifications

Application Diagram

NSA220

Network

Attached

Storage

NWD210N

Wireless USB Adapter

NWD310N

Wireless N PCI Adapter

Laptop

iPOD Touch

Game Console

Desktop

erne

Desktop

NBG420N

Wireless N Router

65-100-420002B 03/08

For more product information, visit us on the web at www.ZyXEL.com

brands, product names,or trademarks mentioned are the property of their respective owners.All specifications are subject to change without notice.
