ZyXEL Communications WAH3004 Manual de usuario

Quick Start Guide

WAH3004

LED Information

Wi-Fi LED

Green on: Wi-Fi enabled

Green blink: Data transmitting

Signal LED

Red on: SIM error/No service

Green on: 2G/3G network

Green blink: Data transmitting

USB 3G Modem Router

1Slide open the cover (B) from back of the USB dongle.

Hardware Installation

1Insert a SIM card and a micro SD card (optional). Slide close the

back cover (B).

1Remove the cap (A) from the USB dongle and insert it into the USB

port of your computer.

1Check the Windows taskbar or the Mac pop-up window to see if the

USB dongle is installed properly.

Insert the SIM card (and SD card) with the slanted side matching the

card holder and the metal contact area facing downwards into the

slot, and then push the SIM card (and SD card) as far as possible.

For Windows:

The driver will be automatically installed on your computer. To see the device,

navigate to the Device Manager window (Start > Control Panel > Device

Manager) and click Network adapters. You will find a “Remote NDIS based

Internet Sharing Device” as shown in the below screen

If the driver failed to install, remove and plug in the WAH3004 again. Then go

and find a removable disk named Network Connection RNDIS on your

computer instead. Double-click Install to install the driver.

Driver Installation

For Mac:

The driver will be automatically installed on your computer.

EU Importer: ZyXEL Communication A/S∣Generatorvej 8D, 2860 Søborg, Denmark∣http://www.zyxel.dk

US Importer: ZyXEL Communications, Inc∣1130 North Miller Street Anaheim, CA 92806-2001∣http://www.us.zyxel.com

注意 !

依據低功率電波輻射性電機管理辦法

第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均

不得擅自變更頻率、加大功率或變更原設計之特性及功能。

第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有

干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依

電信規定作業之無線電信。低功率射頻電機須忍受合法通信或工業、科學及醫療用

電波輻射性電機設備之干擾。

在5.25-5.35 (GHz)頻帶內操作之無線資訊傳輸設備，限於室內使用。

安全警告

為了您的安全，請先閱讀以下警告及指示:

• 請勿將此產品接近水、火焰或放置在高溫的環境。

• 避免設備接觸

• 任何液體 - 切勿讓設備接觸水、雨水、高濕度、污水腐蝕性的液體或其他水份。

• 灰塵及污物 - 切勿接觸灰塵、污物、沙土、食物或其他不合適的材料。

• 切勿重摔或撞擊設備，並勿使用不正確的電源變壓器。

若接上不正確的電源變壓器會有爆炸的風險。

• 請勿隨意更換產品內的電池。

• 如果更換不正確之電池型式，會有爆炸的風險，請依製造商說明書處理使用過之電

池。

• 請將廢電池丟棄在適當的電器或電子設備回收處。

• 請勿將設備解體。

• 請勿阻礙設備的散熱孔，空氣對流不足將會造成設備損害。

• 請插在正確的電壓供給插座(如:北美/台灣電壓110V AC，歐洲是230V AC)。

• 假若電源變壓器或電源變壓器的纜線損壞，請從插座拔除，若您還繼續插電使用，會

有觸電死亡的風險。

• 請勿試圖修理電源變壓器或電源變壓器的纜線，若有毀損，請直接聯絡您購買的店家

，購買一個新的電源變壓器。

• 請勿將此設備安裝於室外，此設備僅適合放置於室內。

• 請勿隨一般垃圾丟棄。

• 請參閱產品背貼上的設備額定功率。

• 請參考產品型錄或是彩盒上標示的作業溫度。

“INFORMAZIONI AGLI UTENTI”

Ai sensi della Direttiva 2012/19/UE del Parlamento europeo e del Consiglio, del 4

luglio 2012, sui rifiuti di apparecchiature elettriche ed elettroniche (RAEE)

Il simbolo del cassonetto barrato riportato sull’apparecchiatura o sulla sua

confezione indica che il prodotto alla fine della propria vita utile deve essere raccolto

separatamente dagli altri rifiuti.

La raccolta differenziata della presente apparecchiatura giunta a fine vita è

organizzata e gestita dal produttore. L’utente che vorrà disfarsi della presente

apparecchiatura dovrà quindi contattare il produttore e seguire il sistema che questo

ha adottato per consentire la raccolta separata dell’apparecchiatura giunta a fine vita.

L’adeguata raccolta differenziata per l’avvio successivo dell’apparecchiatura

dismessa al riciclaggio, al trattamento e allo smaltimento ambientalmente

compatibile contribuisce ad evitare possibili effetti negativi sull’ambiente e sulla

salute e favorisce il reimpiego e/o riciclo dei materiali di cui è composta

l’apparecchiatura.

Lo smaltimento abusivo del prodotto da parte del detentore comporta l’applicazione

delle sanzioni amministrative previste dalla normativa vigente.”

Declarations

www.zyxel.com

Declaration of Conformity

We herewith declare that this declaration is issued under our sole responsibility：

Product

：

USB 3G Modem Router

Model

：

WAH3004

MANUFACTURED

BY AND TCF FILE LOCATED AT

：

Company

：

ZyXEL Communications Corporation

Address

：

1.No. 2, Gongye E. 9th Road, Hsinchu Science Park, Hsinchu, Taiwan, R.O.C.

2.No. 6, Innovation Road II, Hsinchu Science Park, Hsinchu, Taiwan, R.O.C.

Generatorvej 8D, 2860 Søborg, Denmark

complies with essential requirements of the following EU harmonization legislation and

in conformity with the following presumption of conformity：

Essential requirements Presumption of conformity

Directive 2006/95/EC

(LVD)

EN 60950-1:2006+A11:2009+A1:2010+A12:2011

Directive 2004/108/EC

(EMC)

EN 61000-3-2:2006+A1:2009+A2:2009

EN 61000-3-3:2008

EN 301 489-1 V1.9.2

EN 301 489-7 V1.3.1

EN 301 489-24 V1.5.1

EN 301 489-17 V2.2.1

Directive 1999/5/EC

(R&TTE)

EN 301 511 V 9.0.2

EN 301 908-1 V 6.2.1

EN 301 908-2 V 6.2.1

EN 300 328 V1.8.1

Directive 2011/65/EU

(RoHS)

EN 50581:2012

Recommendation 1999/519/EC

(EMF)

EN 62209-2:2010

EN 62311:2008

EN 50566:2013/AC:2014

ZyXEL Communications Corporation

2015-03-10

Date of issue

Richard Hsu

Senior Manager

Quality

Management

Division

Initial Configuration

1Open the web browser from your computer and enter the default

management IP address (192.168.0.254).

1Enter the user name admin and password admin, then click

1The Status screen appears. If PIN authentication is enabled on the

inserted SIM card and the status is PIN blocked, click WAN > SIM

and enter the PIN code. Check with your ISP for the correct PIN

code.

1If your service provider gave you the APN or you want to connect

with a different APN, click WAN > Connection > User Profile.

Click +and enter the APN, user name and password to create a new

profile. Click Apply to save your changes.

User Name: admin

Password: admin

192.168.0.254

For more information, please refer to the User's Guide at

www.zyxel.com.
