ZyWALL
USG100-PLUS
Unified Security Gateway
ZyWALL
USG100-PLUS
Unified Security Gateway
As broadband quickly becomes a necessity in the business world facing network security
threats,the breaches evolve into highly sophisticated attacks to paralyze networks and to
steal sensitive information.In response to such attacks,small businesses have to meet the
great challenge protecting their networks.
The ZyWALL USG100-PLUS is designed for small business to provide real-time inspection and
multi-layer network protection to prevent the network from threats.The USG Series embodies
Stateful Packet Inspection (SPI) Firewall,Anti-Virus (AV), Intrusion Detection and Prevention
(IDP), Content Filtering, Anti-Spam and VPN (IPSec/SSL/L2TP) features in one box. In addition,
the USG100-PLUS not only offers complete security license to fulfill your demand but also
guarantees the continuous firmware upgrades to save your cost. Incorporating
comprehensive security features in the connected devices, the USG100-PLUS safeguards your
organization’s customer and company records, intellectual properties as well as critical
resources from both external and internal threats.
Benefits
Robust security without sacrificing performance
The ZyWALL USG100-PLUS is built with a powerful Integrated High-Performance Security
architecture that provides real-time inspection to prevent networks from threats without sacrificing
performance. Corporate networks are not only flawlessly secured but also get significant
performance enhancements on productivity and efficiency since file loading,emailing and
information searching applications are processed at higher speeds.
Comprehensive IPv6 support smoothly connects future-ready
networks
The ZyWALL USG100-PLUS is IPv6-ready today and is certified with “IPv6 Ready”gold
logo.With IPv6 feature enabled, the USG100-PLUS ensures businesses with a smooth
migration path from the IPv4-based networks to the full IPv6 infrastructure. It assigns
IPv6 addresses to clients and passes the IPv6 traffics through the IPv4 environment.The
USG100-PLUS supports dual-stack and IPv4 tunneling (6rd and 6to4 transition tunnel)
implementations for Internet connectivity to access IPv6 applications.
Security on a New Level
- The Future Is Ahead. Stay Ahead with
ZyXEL USG100-PLUS
■
Robust security without
sacrificing performance
■
Comprehensive support to IPv6
■
Robust hybrid VPN
(IPSec/SSL/2TP)
- Zero-configuration remote
access with EASY VPN
- Support L2TP VPN on mobile
device (iPhone and Android
phone)
■
ICSA Firewall, IPSec certification
■
Content filter stops malware
and Web threats
■
Powerful Email security
■
Non-stop Internet access with
multiple WAN and 3G backups
2
ZyWALL USG100-PLUS
Unified Security Gateway
ZyWALL USG100-PLUS
Unified Security Gateway
EASY VPN reduces operation cost and time
Establishing a VPN tunnel is a good way to build secure connections among remote offices, branch offices and partners; however it is difficult for
non-technical employees, such as sales people, to use because of complicated configuration.The ZyWALL USG100-PLUS is equipped with the “EASY VPN”
solution to push configuration files to the VPN clients automatically; this eliminates the configuration efforts while securing the access at the same time. In
addition, the USG100-PLUS supports L2TP VPN technology on iPhones, Android phones and many other mobile devices as L2TP VPN enables employees in
remote places to connect to the headquarters with easy and free access.
Content filter for safer Web surfing
The World Wide Web has become the main target for network threats, since the Internet itself is a very effective malware delivery mechanism.With threats
hidden directly in contents such as cookies, add-ons and root kits, it makes malware exceptionally difficult to detect.
The ZyWALL USG100-PLUS content filter solution provided by Blue Coat and Commtouch, the leading providers,reduces costs and extends protection by
combining a comprehensive, integrated database featuring millions of URLs, IP addresses and domains.With the solution, the USG100-PLUS not only
enables real-time protection that deters emerging Web threats including malware and phishing, but also blocks or monitors certain sites to maintain
employee productivity.
Powerful Email security
The ZyWALL USG100-PLUS delivers industry-leading protection, powered by Commtouch, against spam, phishing and virus-laden emails.The extremely
high performance of Commtouch technology comes from the unique recurrent pattern detection (RPD) mechanism that possesses its superior capability
through analyzing millions of new patterns each day (24x7x365) to block all the associated messages real-time. In addition, the ZyWALL USG100-PLUS
applies sender-based IP reputation to remove over 80% of unwanted mails and to take advantage of the zero-hour virus outbreak protection feature,
which is capable of blocking or delaying suspicious messages hours before commercial anti-virus signatures are available.
More 3G card support
The ZyWALL USG100-PLUS not only supports multiple WAN ports but also 3G networks through USB or PC cards.With 3G connections,the USG100-PLUS
enables load sharing or failover to deliver highly reliable network connectivity; it also supports more 3G cards with generic driver to ensure excellent
interoperability. Since the customers don’t have to purchase specific 3G cards to save cost.
High performance
The ZyXEL USG100-PLUS is built with a
powerful Integrated High Performance Security
architecture. It provides real-time inspection to
prevent networks from threats without
sacrificing performance. Its excellent
performance delivers sufficient speed boost to
meet all small business needs.
Key Applications
600
500
400
300
200
100
0
40000
30000
35000
25000
20000
15000
10000
5000
0
Firewall Throughput in Mbps Sessions
USG100-PLUS USG50 FG-40C USG100 FG-50B
3
EASY VPN — zero configuration
remote access
When establishing VPN tunnels, it could
be quite difficult for non-technical
employees to use due to the
complicated configuration.
The ZyWALL USG100-PLUS is equipped
with the“EASY VPN”solution to push
configuration files to the VPN clients
automatically; this eliminates the
configuration efforts while securing the
access at the same time.
Content Filter stops malware and Web threats
The ZyWALL USG100-PLUS Content Filter enables businesses
to protect their users and networks from malware and abuse
such as spyware, phishing attacks and inappropriate P2P or IM
usage. It keeps office computers from getting infected by
dangerous malware and comprehensively protects business
network environments.
Non-stop Internet access with
multiple WAN and 3G backups
The ZyWALL USG100-PLUS supports not
only WAN traffic load balancing to
increase the overall network throughput
but also flexible 3G backup as a WAN
alternative to enhance network reliability. Network
Provider
(IP VPN)
LAN
ZyWALL
USG100-PLUS
Unified Security
Gateway
Vantage CNM
Centralized Network
Management
Remote Office
Corporate
Headquarters
BRAS
Host by SI or Customer
Operating in
Active/Passive Mode
3G
Network
WAN2 (3G)
WAN1
Primary
Backup
ADSL Fiber
Last-Mile
IPSec or GRE Tunnel for
Secure Connection
ZyWALL USG fail
over and fail back
between WAN1
(ADSL/Fiber) &
WAN2 (3G WAN)
P2P
IM
Virus
Spyware
Phishing
Si
te to S
i
te
IP
S
ec VPN
Client to Site
IPSec VPN
Internet
Branch
ZyWALLUSG 300
PWR
SYS
AUX
RESET
CARD1
CARD2
10/100/1000
1234567USB
1
2
CONSOLE
AUX
Mobile User
Branch
ZyWALLUSG 300
PWR
SYS
AUX
RESET
CARD1
CARD2
10/100/1000
1234567USB
1
2
CONSOLE
AUX
User
Server Farm
ZyWALL USG100-PLUS
Unified Security
Gateway
Network
Extend
Application Server
(Inventory, Store...)
Web-based
Application
Remote
Desktop
File
Share
OA, ERP System
CRM System
BI
System
Email
Server
Headquarters
IPSec
VPN Client
IPSec
VPN Client
I
V
Easy provisioning for ZyWALL IPSec VPN client
- USG automatically provides configuration file to the client.
ZyWALLUSG100-PLUS
ZyWALLUSG100-PLUS
Conguration
File
4
Specifications
Product Photo
Note:
*1:Testing Methodologies: Maximum performance based on RFC 2544 (UDP packets,1,518 bytes).
*2: VPN (AES) throughput measured using UDP traffic with 1,424 bytes packet size,based on RFC 2544.
*3: UTM (AV+IDP) throughput measured using industry standard IXIA IxLoad test tool against HTTP protocol with 1,460 bytes packet size.Testing done with multiple flows.
*4: Max sessions measured using industry standard IXIA IxLoad test tool.
Features
Firewall
• ICSA-certified firewall
• Routing and transparent (bridge) mode
• Zone-based access control list
• Stateful packet inspection
• User-aware policy enforcement
• SIP/H.323 NAT traversal
• ALG supports custom ports
IPv6 Support
• IPv6 Ready gold logo certified
• Dual stack
• IPv4 tunneling (6rd and 6to4 transition tunnel)
• Host/Router/Firewall
Virtual Private Network (VPN)
• ICSA-certified IPSec VPN
• Algorithm: AES/3DES/DES
• Authentication: SHA-1/MD5
• Key management: Manual key/IKE
• Perfect forward secrecy (DH groups)
support 1, 2, 5
• IPSec NAT traversal
• Dead peer detection/relay detection
• PKI (X.509) certificate support
• Centralize VPN support
• Simple wizard support
• Auto reconnect VPN
• VPN HA (redundant remote VPN gateways)
SSL VPN
• Clientless secure remote access
• Support reverse proxy mode and full tunnel
mode
• Unified policy enforcement
• Supports two-factor authentication
• Customizable user portal
Intrusion Detection and Prevention
(IDP)
• Routing and transparent (bridge) mode
• Zone-based IDP inspection
• Customizable protection profile
• Protect over 2000 attack
Hardware Specifications
10/100/1000 Interfaces (Copper) 4 x LAN/DMZ, 2 x WAN
USB Ports 2
System Capacity & Performance
SPI Firewall Throughput*1 (Mbps) 600
VPN Throughput (AES)*2 (Mbps) 150
UTM Throughput (AV+IDP)*3 (Mbps) 30
Unlimited User Licenses Yes
Max. Sessions*4 40,000
New Session Rate 1,000
Max. Concurrent IPSec VPN Tunnels 50
Max. Concurrent SSL VPN Users 25
Included SSL VPN Users 2
Customizable Zone Yes
IPv6 Support Yes
Power Requirement
Input Voltage 100 - 240 V AC, 50/60 Hz,1.2 A
Power Rating 17 W Max
Physical Specifications
Item Dimensions
(WxDxH)(mm/in.) 242 x 167 x 35.5/9.53 x 6.57 x 1.40
Weight (kg/lb.) 1.2/2.65
Packing Dimensions (WxDxH)(mm/in.) 375 x 238 x 108/14.76 x 9.37 x 4.25
Weight (kg/lb.) 2.4/5.29
Environmental Specifications
Operating Environment Temperature 0°C to 40°C/32°F to 104°F
Humidity 5% to 90% (Non-condensing)
Storage Environment Temperature -30°C to 60°C/-22°F to 140°F
Model ZyWALL USG100-PLUS
5-100-00811007 03/12
For more product information, visit us on the web at www.ZyXEL.com
Copyright © 2012 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of
ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the property of their
respective owners. All specifications are subject to change without notice.
ZyWALL USG100-PLUS
Unified Security Gateway
ZyWALL USG100-PLUS
Unified Security Gateway
Features
Intrusion Detection and Prevention
(IDP)
• Automatic signature updates
• Custom signatures
• Protocol anomaly detection and protection
• Traffic anomaly detection and protection
• Flooding detection and protection
• DoS/DDoS protection
Anti-Virus
• Support Kaspersky and ZyXEL Anti-Virus
• Stream-based Anti-Virus engine
• Zone base AV protection
• HTTP/FTP/SMTP/POP3/IMAP4 protocol support
• Automatic signature updates
• No file size limitation
• Blacklist/whitelist support
Application Patrol
• Application, IM/P2P, stream base media, VoIP
granular access control
• Detail access control of IM (chat, file transfer,
video)
• Application and IM/P2P bandwidth control
• User authentication support
• IM/P2P signature auto update
• Support more than 15 catalogs IM and P2P
• Real-Time statistical reports
• Maximum/guaranteed bandwidth
Anti-Spam
• Zone to zone protection
• Transparently intercept mail via SMTP/POP3
protocols
• POP3/SMTP port configurable
• Sender-based IP Reputation Filter
• Commtouch RPD Query
• Zero-hour Virus Outbreak Protection
• X-Header Support
• Blacklist/whitelist support
• Support DNSBL checking
• Spam tag support
• Statistics report
Content Filtering
(BlueCoat and Commtouch)
• Social networking control
• Web security—Security threat category
(powered by BlueCoat)
• URL blocking, keyword blocking
• Profile base setting
• Exempt list (blacklist and whitelist)
• Blocks java applet,cookies and active X
• Dynamic URL filtering database (powered by
BlueCoat and Commtouch)
• Unlimited user licenses support
• Customize warning messages and redirect URL
Networking
• Routing mode/bridge mode/mixed mode
• Layer 2 port grouping
• Ethernet/PPPoE
• NAT/PAT
• Tagged VLAN (802.1Q)
• Virtual interface (alias interface)
• Policy-based routing (user-aware)
• Policy-based NAT (SNAT)
• Dynamic routing (RIP v1/v2, OSPF)
• DHCP client/server/relay
• Dynamic DNS support
• WAN Trunk more than 2 port
• Per host session limit
• Guaranteed bandwidth
• Maximum bandwidth
• Priority-bandwidth utilization
Authentication
• Local user database
• Microsoft Windows active directory integrate
• External LDAP/RADIUS user database
• Xauth over RADIUS for IPSec VPN
• Forced user authentication (transparent
authentication)
• IP/MAC address binding
System Management
• Role-Based administration
• Multiple administrator login
• Multi-Lingual web GUI (HTTPS/HTTP)
• Object-based configuration
• Command line interface (console/web
console/SSH/TELNET)
• SNMP v2c (MIB-II)
• System configuration rollback
• Firmware upgrade via FTP/FTP-TLS/web GUI
Logging/Monitoring
• Comprehensive local logging
• Syslog (send to up to 4 servers)
• E-mail alert (send to up to 2 servers)
• Real-Time traffic monitoring
• Built-in daily report
• Advanced reporting (Vantage Report)
Security Featured License (Optional)
• ZyXEL Anti-Virus
• Kaspersky Anti-Virus
• Intrusion Detection and Prevention (IDP)
• Blue Coat Content Filter
• Commtouch Content Filter
• Commtouch Anti-Spam
• SSL VPN tunnels upgrade
Certification
• Emission (EMC)
■
FCC Part15 (Class B)
■
CE EMC (Class B)
3G Card Support
Please visit
http://www.zyxel.com/products_services/smb
_security_appliances_and_services.shtml
and find the following path:
ZyWALL Unified Security Gateways USG
product pages to see the 3G Card Compatibility
List for supported USB devices.
Otros manuales para ZyWALL USG100-Plus
1
Tabla de contenidos
Otros manuales de Puerta de ZyXEL Communications
ZyXEL Communications
ZyXEL Communications NSG50 Manual de usuario
ZyXEL Communications
ZyXEL Communications P-661HNU Series Manual de usuario
ZyXEL Communications
ZyXEL Communications P-660HW-DX Manual de usuario
ZyXEL Communications
ZyXEL Communications P-873HNU-51B Manual de usuario
ZyXEL Communications
ZyXEL Communications LTE6101 Manual de usuario
ZyXEL Communications
ZyXEL Communications PRESTIGE 660 HW Series Manual de usuario
ZyXEL Communications
ZyXEL Communications NSG50 Manual de usuario
ZyXEL Communications
ZyXEL Communications P-661HNU-FX Manual de usuario
ZyXEL Communications
ZyXEL Communications VSG-1200 V2 Guía de referencia
ZyXEL Communications
ZyXEL Communications P-660HNT1 Manual de usuario
ZyXEL Communications
ZyXEL Communications VMG1312-T20A Manual de usuario
ZyXEL Communications
ZyXEL Communications ZYWALL USG 20W Manual de usuario
ZyXEL Communications
ZyXEL Communications P-870HW-51A V2 Manual de usuario
ZyXEL Communications
ZyXEL Communications P-660HWP-D1 Guía de referencia
ZyXEL Communications
ZyXEL Communications PRESTIGE 660 HW Series Manual de usuario
ZyXEL Communications
ZyXEL Communications P-792H Manual de usuario
ZyXEL Communications
ZyXEL Communications P-660HW-T - V2 Manual de usuario
ZyXEL Communications
ZyXEL Communications Internet Security Gateway ZyWALL 100 Manual de usuario
ZyXEL Communications
ZyXEL Communications ZyXEL ZyWALL USG-1000 Manual de usuario
ZyXEL Communications
ZyXEL Communications VMG9823-B10A Manual de usuario
Manuales populares de Puerta de otras marcas
LST
LST M500RFE-AS Manual de usuario
Kinnex
Kinnex Media Gateway Manual de usuario
2N Telekomunikace
2N Telekomunikace 2N StarGate Manual de usuario
Mitsubishi Heavy Industries
Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario
Telsey
Telsey CPVA 500 - SIP Manual de usuario
RTA
RTA 460A-NNA4 Hoja de especificaciones
