ZyXEL Communications VSG1435-B101 Manual de usuario

el.com www.zyxel.com

802.11n Wireless VDSL2 4-port

Gateway with HPNA

Firmware v1.10

Edition 1, 9/2010

VSG1435-B101 Series

DEFAULT LOGIN DETAILS

IP Address: http://192.168.1.1

User Name: admin

Password: 1234

ZyXEL Communications Corporation

Device Panels

POWER

ETHERNET 1-4

USB

WLAN/WPS

ETHERNET WAN

INTERNET

DSL WAN

HPNA

POWER

ETHERNET 1-4

USB

DSL WAN

ETHERNET WAN

HPNA

RESET

VSG1435-B101 Series

Overview

The VSG1435-B101 is a VDSL2 router and Gigabit Ethernet gateway

with Home Phoneline Networking Alliance (HPNA) capability, a four-port

built-in Ethernet switch and IEEE 802.11n wireless. The VSG1435-B101

allows wired and wireless clients to safely access the Internet. The built-

in firewall blocks unauthorized access to your network. The USB port

allows you to connect USB memory stick or USB hard drive for storing or

sharing files through the network. Other helpful features include Quality

of Service (QoS) which allows time-sensitive services and applications to

flow more smoothly.

Hardware Setup

Place the VSG1435-B101 flat on a desk or table or on the stand for a

vertical installation.

Remove the VSG1435-B101’s clear plastic covers before

using it.

To connect the stand, line up the arrow on the stand with the arrow on

the bottom of the device as shown.

VSG1435-B101 Series

To connect your VSG1435-B101:

1. Attach the antenna and point it up.

2. Do one of the following for your Internet connection:

a. DSL WAN: Use a telephone cable to connect your VSG1435-

B101’s DSL port to a telephone jack (or the DSL or modem jack on

a splitter if you have one).

b. ETHERNET WAN: If you already have a broadband router or

modem, use an Ethernet cable to connect the ETHERNET WAN

port to it for Internet access.

3. HPNA: Use a coaxial cable to connect to a coaxial outlet and relay

Internet traffic throughout your house through coaxial cabling.

4. LAN: Use an Ethernet cable to connect a computer to a LAN port for

initial configuration and/or Internet access.

5. USB: Connect a USB (version 2.0 or lower) memory stick or a USB

hard drive for file sharing. Use a USB extension cable if the stick is

too big to fit.

6. POWER: Use the provided power adaptor to connect the POWER

socket to an appropriate power source. Make sure the power at the

outlet is on. After connecting the power adaptor, look at the lights on

the front panel.

• The POWER light blinks while your VSG1435-B101 starts up and

then stays on once it is ready.

• Each LAN light stays on if the corresponding LAN port is properly

connected and blinks when there is traffic.

• The ETHERNET WAN light stays on if the ETHERNET WAN port is

properly connected and blinks when there is traffic.

• The USB light turns on when your VSG1435-B101 detects a

connected USB device.

VSG1435-B101 Series

• The HPNA light stays on if the HPNA port is properly connected

and blinks when there is traffic.

• The DSL WAN light turns on when your VSG1435-B101 has a DSL

connection.

• The WLAN / WPS light flashes green and orange while WPS is in

process. It stays on green when the wireless LAN is ready and

blinks when there is traffic.

• The INTERNET light turns on when the gateway is able to access

the Internet and will blink when your VSG1435-B101 is sending or

receiving data.

If the lights do not come on, check your connections and inspect your

cables for damage. If the lights are still off, contact technical support.

Set Up a Wireless Network

You can set up a wireless network using the following methods:

Using Wireless Protected Setup (WPS)

Press the WPS button on the VSG1435-B101’s front panel for more than

5 seconds to turn the WPS function on.

Follow these steps to add a WPS-enabled device to the wireless network

using the WPS/WLAN button.

Place the devices you want to connect near

one another.

Press the WPS button on the VSG1435-

B101.

The WPS light blinks green and orange.

Press the WPS button on a compatible

device within 2 minutes of pressing the

button on the VSG1435-B101.

The WPS light on the VSG1435-B101

shines steadily when connected.

VSG1435-B101 Series

Set Up a Wireless Network Manually

The wireless LAN on your VSG1435-B101 is enabled by default. To add

a wireless client to the network, use the settings found on the bottom

panel of your VSG1435-B101, which will look similar to the following

example:

Configure wireless devices that you want to connect to the wireless

network to use the same wireless settings as the VSG1435-B101.

The default wireless settings vary for each VSG1435-B101. Refer to the

bottom panel of your device and use the provided information.

Log into the Web Configurator

Your device may already be set up for Internet access. However, you

may want or need to log on to the VSG1435-B101 Web Configurator to

perform tasks:

• Configure your Internet access settings manually

• Customize the Quality of Service (QoS) and routing features

• Create firewall and web filter rules

• Edit remote management, as well as other features

SSID: ZyXEL00561

Security Mode: WPA-PSK

Pre-Shared Key: FB373BD356

1. In your browser, if the VSG1435-B101 does not automatically re-

direct you to the login screen, go to http://192.168.1.1.

2. Enter the default user name admin and password 1234. Click Login.

 If the login screen does not open, make sure you allow web

browser pop-up windows, JavaScripts and Java

permissions. Your computer should be also set to get an IP

address automatically from a DHCP server. See the

appendices in your User’s Guide for more information.

3. A welcome screen appears with details about your last login. Select

Show this page next time to see the welcome screen on your next
