Zte WP755 Manual de usuario

ZTE WP755

WCDMA Wireless Phone

User Guide

Feature list

Support WCDMA850/2100 MHz, GSM 850/900/1800/1900 MHz

Phone book function

Hand-free function

Volume adjust of handset and speaker

10 group of incoming ring selected,

6 group of SMS ring and silent selectable

Received and send SMS, which can save 500 item SMS.

LCD display date, time, signal, battery capacity.

Call Log 250 groups

Size:145*52*19mm

Working voltage:AC220V,50Hz;DC 5V 500mA

Additional battery: recharger battery

Standby time: more than 48 hours

Talk time: around 4 hours.

Noted: the standby time and talk time is affected by network preference.

Know Your Phone

Key Instruction

Key

Description

1. Message

•To edit message

2. Profiles

•Set profiles of your phone.

3. OK

•Enter main menu.

•Performs the function indicated at the left bottom of the screen.

4. CALL

•Make a call or answer an incoming call.

•In standby mode, press this key to enter Dialed calls list.

5. END

•To turn ON/OFF the unite

Key

Description

6.Scrolling

•Press these keys to scroll cursor to the left, right, up or down

when inputting characters or selecting items.

•Default functions in standby mode are set in Settings menu.

7. Number

•Use these keys to enter numbers and characters.

8. # , *

•Perform different functions under different conditions.

Installation

1. {tc "Handset" \f A}{tc "Handset" \f B}{tc " Handset" \f E}Battery

Install the battery as below diagram,

2. {tc "SIM card" \f A}{tc "SIM card" \f B}{tc " SIM card" \f E}SIM card

Always switch the phone off before removing or inserting SIM card.

Open the bottom cover of the battery. Remove the battery, slide the SIM card into the SIM card slot.

Make sure that the contact area of the card is facing down, and the beveled corner matches with the

SIM card slot. Put in the battery and install the bottom cover.

How to Power on/off

To power on the phone, well installed the battery and then hold the END key till the phone is

powered on.

To power off the phone, at standby mode, hold the END key till the phone is powered off.

Notes:

The phone will charge the internal battery automatically when it is connected to external

power outlet.

How to Make a Call

Enter the number or select recipient’s number from Phonebook, or press CALL key to select a number

from the Dialed calls list, then press CALL key to make the call.

Notes:

Add the international prefix, country code and area code (without the leading 0) before the

number when making an international call.

Message

Select Message in Menu,

•Select Write message to choose New SMS or New New MMS, Press Options select Send, Insert

template, Add contact info, Add phiz or Save as draft.

•Select Inbox to view messages received.

•Select Outbox to view the failure messages.

•Select Drafts to view the draft messages.

•Select Sentbox to view the successfully sent messages.

•Select Templates to View the template messages.

•Select Voice mail service to enter Voice mail,

•Select Broadcast message to review the broadcast message list.

•Press Options to enter Settings and Message capacity, to View the message of saved entries and

maximum number of entries capacity in phone and SIM.

Security setting

Security setting could prevent your phone from unauthorized use. The default phone code is 1234.

Change it to your own as soon as possible.

If you change the default phone code to a new one, remember it or place it at secure place.

PIN Code and PUK Code

•PIN code: PIN code could prevent your SIM card from illegal use. When PIN code is enabled, you

should enter the PIN code when powering on the phone again. Change the default PIN code to your

own as soon as possible.

•PUK code: The SIM card will be locked if you enter a wrong PIN code consecutively for three times. To

unlock, you need PUK code.

Notes:

PIN code and PUK code may be offered together with the SIM card. If not, contact your

service provider.

Text Input

Operation

Method

Input digits

“123”, press the Number keys to input the digits you want

directly.

Input letters

“abc”, “ABC”, “PO”, ”Po”, ”po”, press corresponding letter key

till the letter appears.

Input words

“En”, “en”, “EN”to enter English, “sPo”, ”sPO”, ”spo”to enter

Portuguese, press the Number keys to input the characters of

the word. Then press OK key to confirm.

Input symbol

Press *key, and then select corresponding symbol by using

Scrolling keys.

Input space

Apart from Numbers input mode, press “0”key to add space.

Erase character

Press Clear key. Hold Clear key until the cursor before the

character be erased.

Move the cursor

Press Scrolling keys.

Change input mode

Press # key to change text input mode.

Menu Function

Hereinafter are brief instructions for menu functions of the phone.

Function

Description

Selection

Create message

Create SMS and MMS send to

others.

Menu→ Message→ Write message→

New SMS/New MMS

Read message

Read message in Inbox, Outbox,

Drafts, Sentbox.

Menu→ Message→

Inbox/Outbox/Drafts/Sent messages

Message settings

Make some necessary settings.

Menu→ Message→ Options →Settings

Function

Description

Selection

Call Logs

View or dial all recent calls.

Menu→ Call logs→ Missed calls/Dialed

calls/Received calls/Delete all

Call timers

Check the Last call, Received calls,

Dialed calls or Call history duration.

Menu→ Call logs →Call timers

GPRS counter

Check the GPRS data usage status

Menu→ Call logs →GPRS counter

Contacts

View contacts

Menu→ Contacts

Add new contact

Save phonebook number

Menu→ Contact→ Options→ New

Speed dial

Set and view speed dial list.

Menu→ Contact→ Options→ Others →

Speed dial

Call divert

Specify the conditions under which

the call types should be diverted to

another number.

Menu→ Settings→ Call settings→ Call

divert

Call waiting

Put the current call on hold to

answer the other incoming call.

Menu→ Settings→ Call settings→ Call

waiting

Call barring

Restrict the dialing or receiving of

certain calls.

Menu→ Settings→ Call settings→ Call

barring

Advanced

settings

Other setting items of Call setting

Menu→Settings→Call settings →Hide

ID/Others(Call time minute

reminder/Flight mode)

Date & Time

Set the date and the time, and the

date and time format.

Menu→ Settings→ Phone settings→ Date

& Time

Language

settings

Set the display language

Menu→Settings→Phone settings →

Language settings

Dedicated keys

Short cut of the direction key

Left Key →Calculator

Right Key →Alarm

Function

Description

Selection

Down key →Calendar

Up key →Call logs

Auto keypad lock

Lock the keypad automatically.

Press Left key to unlock, Press Right

key OK to confirm.

Menu→ Settings→ Security→Auto

keypad lock

Contrast

Set the contrast of LCD display(7

Levels)

Menu→ Settings→ Display →Contrast

Backlight

Set the backlight time, when using

the phone.

Menu→ Settings→ Display →Backlight

Keypad backlight

time

Set the backlight time of keypad,

when using the phone

Menu→ Settings→ Display →Keypad

backlight time

Change PIN

Set or change the PIN code

Menu → Settings → Security settings →

SIM security →Change PIN

Change password

Set or change the phone lock code.

Menu→ Settings→ Security settings→

Modify the cellphone password

Restore factory

settings

Switch to the factory default

settings. The phone will clew input

password, the password default

1234.

Menu→ Settings→ Phone settings

→Restore factory settings

Profiles

Set profiles of your phone.

Menu→ Profiles

(Normal/Silent/Meeting/Indoor/Outdoor

)

Internet

To surf the Internet

Menu→ Internet(Input

URL/Bookmarks/History/Offline pages)

Connections

Do the settings of internet

connection

Menu →Settings →

Connections(Network type/Network

account/GPRS Service/Data

roaming/Data connection

settings/Network selection)

Function

Description

Selection

Loja Vivo

To enter Vivo’s home page

Menu → Loja Vivo

Calculator

Execute basic math calculation.

Menu→ Tools→ Calculator

Calendar

To view the date and add the new

events

Menu→ Tools→ Calendar

Alarm

Set alarm clock.

Menu→ Tools→ Alarm

World clock

To view the time in different city in

the world.

Menu →Tools→ World clock

Unit conversion

To view the conversion of different

unit

Menu →Tools→ Unit conversion

Stopwatch

To calculate the time duration

Menu →Tools→ Unit Stopwatch

FM radio

Listen to FM radio.

Menu→ FM radio.

Warning and Maintenance

• Some electronic devices are susceptible to electromagnetic interference sent by the phone if

inadequately shielded. Keep using the phone at least 20 cm or as far away as you can from TV sets,

radio and other automated office equipment so as to avoid electromagnetic interference.

•Operating the phone may interfere with medical devices like hearing aides and pacemakers, or other

medical devices in hospital. Consult a physician or the manufacturer of the medical device before

using the phone.

•Be aware of the usage limitation when using the phone at places such as oil warehouses, or chemical

factories, where there are explosive gases or explosive products being processed, because even if

your phone is in idle state, it still transmits radio frequency (RF) energy. Therefore, power off your

phone if required.

•Keep the phone out of the reach of small children. The phone may cause injury if used as a toy.

•Use original accessories or accessories that are authorized by the manufacturer. Using any

unauthorized accessories may affect your phone’s performance, and violate related national

regulations about telecom terminals, or even endanger your body.

•As your phone can produce electromagnetic field, do not place it near magnetic items such as
