Zte MF971V Manual de usuario

MF971V

Quick Start Guide

Getting to Know Your Device

Appearance

The following gure is for your reference only.

1. Power key

2. FUNC key

3. External antenna connector

4. LCD screen

5. External antenna connector

6. Charging/micro-USB jack

7. micro-SIM card slot and reset hole

2

Getting to Know Your Device

Indicators

When the device is powered on, the following icons

may be displayed on the LCD screen. For a de-

scription of the icons, refer to the following table.

Icon Description

Network signal strength

4G/3G/2G Network type

The user is in roaming status.

Connected to the Internet.

Connected to the Internet in the

Internet Wi-Fi mode.

New message(s)

Wi-Fi status and the number of

connected users

Battery level

3

Getting to Know Your Device

Connection Scenarios

The device allows multiple clients to surf on the

Internet at the same time. The following gures are

for your reference only.

A micro-SIM card can be used to access the

Internet.

4

1. Open the micro-SIM card slot cover, and install

a micro-SIM card to the micro-SIM card slot.

NOTE:

Do not remove the cover rudely, because it is con-

nected with the device.

WARNING!

To avoid damage to the device, do not use any oth-

er kind of SIM cards, or any non-standard micro-

SIM card cut from a SIM card. You can get a stan-

dard micro-SIM card from your service provider.

2. Close the micro-SIM card slot cover.

Installing the micro-SIM Card

5

Connecting to Your Device

Using Wi-Fi

1. Power on your device.

2. Ensure that your computer or other client de-

vices have enabled Wi-Fi, and search for avail-

able wireless networks.

NOTE:

Refer to your Wi-Fi-enabled client device manual

for further details on how to search for wireless net-

works. If you use a computer, you need to set your

computer to obtain an IP address automatically.

3. Select the Wi-Fi name (SSID) of your device,

and click Connect.

4. Enter the Wi-Fi password if necessary, and

click OK.

NOTE:

Refer to the chapter Getting to Know the Wi-Fi

SSID and Password to get the default Wi-Fi SSID

and password.

5. Wait until the client device is connected to your

device successfully.

6

Connecting to Your Device

Using a USB Cable

1. Connect a computer to your device with a USB

cable.

2. Power on your device. The operating system

detects and identies new hardware, and auto-

matically installs the software.

NOTE:

If the system does not automatically launch instal-

lation, you can Double-click the device installation

icon in My Computer to install the software.

3. Wait until the computer is connected to your

device successfully.

7

Getting to Know the Wi-Fi SSID and

Password

You can use the following methods to get the de-

fault Wi-Fi SSID and password.

• View the label on the device.

• Press the FUNC key to access the options

menu. Select Device Info and the Wi-Fi SSID

and password are displayed on the screen.

Logging in to the 4G Mobile Hotspot

Conguration Page

1. Ensure that the connection between your de-

vice and the client device is correct.

2. Launch the Internet browser and enter

http://192.168.0.1 or http://u.ztedevice.com

in the address bar.

3. Enter the password to log in to the 4G Mobile

Hotspot conguration page.

NOTE:

The default password is admin.

8

Changing the Wi-Fi SSID or Password

1. Log in to the 4G Mobile Hotspot conguration

page.

2. Select Settings below Wi-Fi and then click

Main SSID.

3. Change the Network Name (SSID) or the

Password in the Main SSID area.

4. Click Apply.

Accessing the Internet

After a client device is successfully connected to

your device, you can access the Internet in Auto-

matic or Manual mode. The default mode is Auto-

matic.

Mode Operation

Automatic

Your device is automatically connect-

ed to the Internet, and you can surf

on the Internet through the client.

9

Manual

1. Log in to the 4G Mobile Hotspot

conguration page.

2. Select Settings > Connection

Mode > Manual, and then click

Apply.

3. Click to back to the home

page, and click or .

You can also press the FUNC

key and select Network Connec-

tion. Select Yes or No.

NOTE:

To modify the parameters of your device, log in to

the 4G Mobile Hotspot conguration page.

10

Accessing the Internet
