Zonet ZUB6111C Manual de usuario
Installation Guide
VERSION 1.1
Bluetooth USB Adapter
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
Bluetooth
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
The Bluetoothname and the Bluetoothtrademarks are owned by BluetoothSIG,Inc.
This manual may not be copied in any media or form without the written consent of original
maker.
TABLE OF CONTENTS
WELCOME ................................................................. 1
Features ............................................................... 1
System Requirements ............................................... 1
Before You Start .................................................... 1
Driver Support ........................................................ 2
1. WINDOWS NATIVE DRIVER .......................................... 3
2. INSTALL WIDCOMM DRIVER ......................................... 4
3. CHANGE BLUETOOTH DRIVER ...................................... 7
4. SELECT BLUETOOTH SERVICES ..................................... 10
5. MY BLUETOOTH PLACES ............................................ 12
APPENDIX A ............................................................... 14
FCC ........................................................................ 15
WARRANTY ............................................................... 16
WELCOME
Thank you for your purchase of the Bluetooth USB Adapter. Fea-
turing Bluetooth wireless technology, Bluetooth USB Adapter creates
cable-free connections between your PCs and other Bluetooth devices.
Bluetooth USB Adapter is following Bluetooth v1.2 specification and is
compatible with all Bluetooth v1.1 or v1.2-certified devices.
FEATURES
Compliant with Bluetooth standard version 1.2.
Support for Microsoft Windows 98SE, Me, 2000 and XP.
Easy operation and setting up.
SYSTEM REQUIREMENTS
Processor : Intel Celeron / Pentium III, IV; AMD Duron / Athlon
Operating System : Microsoft Windows 98SE / ME / 2000 / XP
System memory : 32MB at least
Hard Drive Free Space : 11.5MB
BEFORE YOU START
1). Remove any Microsoft native driver.
2). Please remove any previous version of Widcomm Bluetooth software
existing in your system. The remove procedures are as follows:
Step 1 : Click Start/Settings, then select Control Panel.
Step 2 : In the Control Panel window, double click Add/Remove programs
icon.
Step 3 : Find out the item Widcomm Bluetooth Software x.x.x.x then
remove it.
1
2
DRIVER SUPPORT
Two Bluetooth drivers are supported under Windows XP (SP2) :
1). Windows XP (SP2) native Bluetooth driver.
Windows XP (SP2) is supporting Broadcom USB Bluetooth dongle
now. The installation is simple and easy, just plug Bluetooth donge into
USB port of your PC, Windows XP will automatically find its driver for it.
Microsoft driver only supports limited Bluetooth profiles. You
can choose Widcomm driver for more advanced purposes.
2). Widcomm Bluetooth driver.
After Windows XP (SP2) native Bluetooth driver is installed, you
also can install one additional Widcomm driver for advanced features,
such as supporting more Bluetooth profiles, easy and friendly user
interface...etc.
Put Widcomm Driver CD into CD drive of your PC, then install it.
Once Widcomm driver is installed, it will automatically take over
previous Windows XP native driver. Two drivers are co-existig in your
system now, but only Widcomm driver is enabled and Windows XP driver
is disabled.
Condition 1 : Windows and Widcomm drivers co-exist in your PC.
1). Plug Bluetooth dongle to your system first, get Windows XP driver
support.
2). Put Widcomm Driver CD into CD drive of your PC, then install it.
3). Refer to “Change Bluetooth Driver” section to learn how to change
driver between them.
Condition 2 : Only Widcomm driver exists in your PC.
1). DO NOT plug Bluetooth dongle to your system first.
2). Put Widcomm Driver CD into CD drive of your PC, then install it.
During installation, it will ask you to plug in dongle, please do it to com-
plete the installation.
Now, you have only one Widcomm driver existed in your system. It is
impossible to turn on Windows native driver. Unless you remove
Widcomm driver, then follow steps 1 to 3 in Condition1 to have both
drivers supported.
WINDOWS NATIVE DRIVER
Step 1 : Remove any Widcomm Bluetooth driver.
Click START, select Control Panel, select System, select Device Manager.
In Bluetooth Radios, make sure there is no Widcomm Bluetooth driver
installed before.
If there is any, go to Control Panel
window, double click Add/Remove
programs to remove Widcomm
driver.
Step 2 : Plug the Bluetooth USB
adapter into USB port of your PC,
Windows XP (SP2) will automatically
find this adapter and activate its
native driver for it.
After driver was installed :
Click START -> Settings.
Select Control Panel.
Select System.
Select Device Manager ->Hardware.
In Bluetooth Radios, you can find a
Windows native driver :
Blutonium BCM2035 Bluetooth
2.4GHz Single Chip Transceiver.
Step 3 :
Right-click Blutonium BCM2035
Bluetooth 2.4GHz Single Chip Trans-
ceiver and then select Property,
click on Driver page.
You can see driver provider is
Microsoft.
3
4
INSTALLING WIDCOMM DRIVER
The following steps tell you how to install the Widcomm driver.
Step 1 :
Put Widcomm Driver CD into CD
drive of your PC, an AutoInstall
program will start to guide you to
complete the installation step by
step.
You also can find Setup.exe from
the given Widcomm Driver CD or
downloaded driver files, and double
click on it to install Widcomm
Bluetooth Software. It opens the
InstallShield Wizard dialog box, then
click Next.
Step 2 : Accept the software license
agreement. Click Next.
Step 3 : Select destination folder,
you can choose the default or
change to your favorite.
5
Step 4 : Click Install to start the
installation.
Step 5 : Files copying in process...
Step 6 : Click OK to ignore un-
signed driver warning.
Step 7 : If Bluetooth dongle is plugged in your PC now, this screen will
not be displayed. If NOT, then it will show up.
One reminding window will show up
to ask you to PLUG IN Bluetooth
USB adapter.
Plug in your USB adapter if it has
not been plugged in before.
Click OK to continue.
Step 8 : Installation is complete .
My Bluetooth Places should
appear on your desktop and a
similar icon also appears on the
lower right corner of your screen.
You can double click on desk-
top or right click on the lower
right corner of your screen, then
click “Explore My Bluetooth Places”
menu to start ”My Bluetooth
Places” program.
Step 9 :
Click START -> Settings.
Select Control Panel.
Select System.
Select Device Manager ->Hardware.
In Bluetooth Radios, you can find a
new Widcomm driver :
Broadcom USB Bluetooth Device.
6
7
CHANGE BLUETOOTH DRIVER
As described in page 2, condition 1, we first get Windows native driver
support, then install Widcomm driver to replace it. Now, in our system,
there are two Bluetooth drivers : 1). Widcomm driver which is enabled,
and 2). Windows XP driver which is disabled in the background.
We want to disable Widcomm driver, and enable Windows XP driver, the
steps are :
Step 1 :
Click START -> Settings.
Select Control Panel.
Select System.
Select Device Manager ->Hardware.
In Bluetooth Radios, you can find
Widcomm driver :
Broadcom USB Bluetooth Device.
Step 2 :
Right-click Broadcom USB Bluetooth
Device and then select Property,
click on Driver page.
Click Update Driver.
