Zonet ZEW2500P Manual de usuario
Copyright Statement
is the registered trademark of Zonet Technology Inc. All the
products and product names mentioned herein are the trademarks or registered
trademarks of their respective holders. Copyright of the whole product as
integration, including its accessories and software, belongs to Zonet Technology
Inc. ithout the permission of Zonet Technology Inc., any individual or party is
not allowed to copy, plagiarize, imitate or translate it into other languages.
802.11g ireless USB Adapter
1
Table of Content
Chapter 1. Introduction……………………………………………………………2
1.1 Welcome…………………………………………….…………………………2
1.2 Product Feature…………………………………………………………………2
1.3 Content of Package……………….…………………….……………………2
Chapter 2. Installation…………………………………………………………………3
Chapter 3. Configuration………………………………………………………..……
3.1 Station Mode…….………………………………………………………..……
3.1.1 Profile…….……........……………………………………………..……7
3.1.1.1 Add/Edit Profile…………………………………………......……7
3.1.2 Network.......………………………………………………………………9
3.1.3 Link Status…………………………………………………………..…...9
3.1.4 Advanced……………..……….…………………………………………10
3.1.5 Statistics……………..……….…………………………………………10
3.1. WMM….......................………........………………..………………11
3.1.7 WPS….......................………........………………..………………12
3.2 AP Mode………………..…....……………………………….…………..13
3.2.1 Configuration………..……………………………………………...….13
3.2.2 Access Control…......………..………………………...………..……15
3.2.3 MAC Table...........………..…………………………....………………1
3.2.4 Switch to Working Station Mode..………………………………1
3.3 Use Zero Configuration................................….……….…………..17
Chapter 4. How to connect with PSP………………………………………….20
4.1 Configure PSP with Ad-Hoc mode……………………………….………20
4.2 Configure XLink Kai…………………………………………………………22
Chapter 5. Product Specifications………….........................……………….23
Chapter . TroubleShooting………….........................………….............24
802.11g ireless USB Adapter
2
Chapter 1 Introduction
1.1 Welcome
Thank you for purchasing Zonet ZE 2500P-802.11g wireless USB adapter.
ZE 2500P connects you with 802.11g networks at up to an incredible 54Mbps!
And for added versatility, it can also interoperate with all the up to 11Mbps
802.11b products found in homes, businesses, and public wireless hotspots
around the country.
Soft AP supported by ZE 2500P can help you establish wireless LAN networking
with lowest cost. Besides, PS ( i-Fi Protected Setup) simplify the security
setup and management of i-Fi networks. Supports MM for Multimedia
Applications with Quality of Service in i-Fi® Networks. Especially supporting
PS3, PSP, Nintendo DS and ii connections with XLink Kai software will be your
best choice to enjoy on-line gaming.
1.2 Product Feature
Complies with IEEE 802.11g and IEEE 802.11b standards
Provides USB2.0 port
Provides up to 54Mbps transmission rate and up to 300 meters
transmission distance
Auto-detects and changes the network transmission rate
Provides two work modes: Infrastructure and Ad-Hoc
Supports Soft AP to establish your wireless LAN networking
supports PS3, PSP, ii and Nintendo DS connecting with Internet and
XLink Kai to enjoy on-line gaming
Supports 64/128-bit EP, PA, PA2 encryption methods and 802.1x
security authentication standard
Supports ireless Roaming function
PS ( i-Fi Protected Setup) simplify the security setup and management
of i-Fi networks.
Supports MM for Multimedia Applications with Quality of Service in
i-Fi® Networks
Supports indows 2000 / XP / 2003 / Vista
1.3 Contents of Package
One ZE 2500P
One Installation CD w/User Manual
One Quick Installation Guide
One USB Cable
Contact your local authorized reseller or the store purchased from for any items
damaged and/or missing.
802.11g ireless USB Adapter
3
Chapter 2 Installation
NOTE:
1.
For future driver upgrading, please visit our website at www.zonetusa.com
2.
Snap-shot screens of the following installation procedure are based on Windows
X . Installation procedures will be similar for other windows operating systems.
1. Insert ZE 2500P into a USB
slot of your computer.
2. Select Cancel when Found
New Hardware window
appears.
3.
Insert Installation CD to your
CD-ROM drive. B
r
owse CD and
double-click
Setup.exe
in
Driver folder to execute it. The
wizard will run and install all
necessary files to your
computer automatically.
802.11g ireless USB Adapter
4
4. C
lick
Next
to accept the
Agreement. Or click
Cancel
to
cancel the installation
.
5.
Select
Install driver and
Ralink W AN Utility
or
Install driver only
then click
Next
.
.
Select
Ralink
Configuration
Tool
or
Microsoft Zero
Configuration Tool
then click
Next
.
a.
It’s recommended to select
Ralink Configuration Tool,
which provides fully access to
all function of ZE 2500P.
b. If you prefer to use the
wireless configuration tool
provided by indows XP or
Vista, please select
Microsoft
Zero Configuration Tool.
802.11g ireless USB Adapter
5
7.
Click
Install
to start
installation. Or click
Cancel
to cancel the installation
.
8. Click Finish to complete the
software installation.
You will see a tray icon appear in your system tray at the bottom of the
screen after the software and hardware installation completed successfully.
802.11g ireless USB Adapter
6
Chapter 3 Configuration
3.1 Station Mode
Station Mode is the default access mode for ZE 2500P.
In this mode, ZE 2500P serves as a client to receive the wireless signals to
access the Internet.
Double-click the tray icon to launch the configuration utility.
Or right click the tray icon and select aunch Config Utility.
802.11g ireless USB Adapter
7
3.1.1 Profile
Profile can keep your favorite wireless setting among your home, office, and
other public hotspot. You may save multiple profiles and activate the one at your
preference.
Add:
to create a new profile
Edit:
to edit/modify/change parameter of an existing profile
Delete:
to delete an existing profile
Activate:
to make an existing profile become active and to connect
3.1.1.1
Add/Edit Profile
a. System Configuration
Power Save Mode:
a.
CAM
(Constantly Awake Mode) – ZE 2500P will stay power-ON as long
as the computer is connected to a power outlet.
b.
PSM
(Power Saving Mode) – ZE 2500P will hibernate when the
computer is hibernating.
802.11g ireless USB Adapter
8
Network Type:
a.
Infrastructure
– A wireless Router and/or Access Point is required.
b.
Ad-hoc
– Peer-to-Peer network, no base station required.
TX Power:
Amount of transmit power used by the radio transceiver to send out signal.
User can choose different value in the drop down menu
Preamble:
Only available under Ad-hoc mode. Value can be chose from Auto, Long, or
Short
Threshold:
Frame size when RTS/CTS handshake performs before attempt to transmit.
a.
RTS Threshold:
Default value = 2347
b.
Fragment Threshold:
Default value = 2346
b.
Authentication and Encryption
Authentication:
Open, Shared, Leap, PA, PA-PSK, PA2 and
PA2-PSK.
Encryption:
Algorithm used in BSS or IBSS, EP, TKIP, AES, and None
c. 802.1X
