Zeiss LSM 700 Manual de usuario



InstructionLSM7002017‐12‐07.docx2017‐12‐19



ConfocalLSM700



Tableofcontents



Introduction ......................................................................................................................................2

Hardware ..........................................................................................................................................2

Objectives......................................................................................................................................2

Filterturret ....................................................................................................................................2

Laserlines......................................................................................................................................3

LightPath ......................................................................................................................................3

Startup .............................................................................................................................................4

Samplemountingandviewing .........................................................................................................5

Software ...........................................................................................................................................5

Sampleviewing ..............................................................................................................................6

Acquisition.....................................................................................................................................8

LSMChannelmodeconfocalsetting.........................................................................................8

Configuration: ........................................................................................................................8

Acquisition&parametersetting ............................................................................................10

Singleimageacquisition........................................................................................................12

Multidimensionalacquisition.................................................................................................12

Shuttingdown .................................................................................................................................17





p.2



Introduction

TheZeissLSM700isequippedwith4laserlinesandcandetectuptofourcolorsignalsatframerates

approaching5framespersecondat512x512pixels.Efficientseparationofthefluorescencesignalsby

selectivelaserexcitationcoupledtoefficientsplittingoftheemissionusingthevariablesecondary

dichroic(VSD)beamsplitterpreventscrosstalkandenablesspectralimagingaswellaslinearunmixingof

highlyoverlappingfluorophores.AmongtheadvancedfeaturesoftheVSDbeamsplitteristhatallportions

oftheemissionspectrumareutilizedfordeterminingeachspectraldatapoint.

Hardware

Themicroscope:

TheLSM700isattachedtoanuprightmicroscope(AxioImagerZ2).

Objectives



PositionObjectivelens Magnification NA coverslip Working

distanceImmersionParfocal

length

1WPlan

ApochromatX401.0 02.5mmWaterdipping45mm

2ECPlan

Neofluarx10 0.3 0.17mm 5.2mmAir45mm

3Plan

Apochromatx20 0.8 0.17mm 0.55mmAir45mm

4LDLCIPlan‐

Apochromat x25 0.8 0‐0.170.57atcover

glass0.17

Water,

Glycerineand

Oil

45mm

5ECPlan‐

Neofluarx40 1.3 0.170.21mmOil45mm

6Plan

Apochromatx63 1.4 0.170.19mmOil 45mm



Filterturret



positionFiltersetExcitationfilterBeamsplitterEmissionfilter



Fluorophore

family



1FS38BP470/40FT495BP525/50Cy2,GFP

2FS43BP545/25FT570BP605/70Cy3,Al555

4



Fs49G365FT395BP445/50DAPI,BFP



5



DIC   





p.3



Laserlines



LaserLine

Solidstate5mW 639

Solidstate10mW555

Solidstate10mW488

Solidstate5mW405



LightPath



1. Thelaserscomealignedfromthemanufacturer,all4lasersareattachedtoanopticcableand

entertheconfocalscanhead.(1)

2. Thelaserlinesarereflectedbythemaindichroicmirror(beamsplitter).(4).

3. The2Galvanometricmirrorsscanthesample.(3).

4. Thereturnemissionwavelengthpassesthroughthemaindichroicmirror(4).

5. Theemissionpassesthroughthepinholeapertureandtheoutoffocuslightiseliminated.(5)

6. Thevariablesecondarydichroicbeamsplitter(VSD)iscoatedwithavariablecoatingthatbetween

420nm‐630nm,accordingtothepositionoflightincidencedeterminesthecutoffbelowwhich

wavelengththelightwillpasstoPMT1andabovethiswavelengthitwillbereflectedtowards

PMT2.(6)

7. BeforethedetectionanemissionfiltercanbeinsertedfromthefilterwheelbeforethePMT,only

longpass(LP)/shortpass(SP)filtersareavailable.(9)

8. ThelightisdetectedinoneofthetwoPMTdetectors‐PMT1forSPemissionwavelength,PMT1

forLPemissionwavelength.(7,8)

p.4



Startup

Turnonthesysteminthefollowingorder:

‐Inthepowerstripsturnonswitches12.



‐Turnonthestagecontroller(3)



‐Rotate(clockwise)thesilverkeyinthelaserselectronicunit(4)



‐Turnonthecomputerandlogin

Username:multilabs

Password:123456

‐Turnonthemetalhalidelamp(6)







p.5



Samplemountingandviewing

Inserttheslideordishtothestageholder.

PushintheLightswitchbetweentheocularandtheconfocal.



Viathetouchpad:

1. Choosethepreferredobjective



2. ChoosetheproperfiltersetandopentheTL\RLshutter:



Software

‐

LogintoBookitLabandactivateyourreservationtostartBlackZen2.3



‐

ToacquireimagesclickStartSystem





Filterset

p.6



Sampleviewing

IntheLocatetabchoosethepreferredobjectivefiltersetandopentheilluminationshutter

RL\TL



SettheTransmittedlight(IncasetheTLisneeded)

Clickthetransmittedlightlampicon,clickONandsetdesiredbrightness(orviathe

microscope).

SetthefilterturretpositiontoDICandthecondenserbelowthestagetoI,IIorIIIaccording

totheobjectivelens(seeobjectivelensinfoontouchpad).

IfyouareacquiringtransmittedchannelsetupKohlerillumination:

Bringthesampleintofocus.



Closethefieldstopusingthemotorizedaperturebutton(F)locatedattherightofthe

microscopeuntilyoucanseeatleastoneedge



Adjustthecondenserheightuntiltheedgesofthediaphragmimagearecrisp.



Centerthediaphragmimageusingthetwocenteringscrews.



Openthefielddiaphragm,justuntiltheimagefillsthefieldofview.



p.7





2,5

3

p.8



Acquisition

LSMChannelmodeconfocalsetting

InthesoftwaregototheAcquisitionmaintooltab

PullouttheLightswitchbetweentheocularandtheconfocal.



Configuration:

ItishighlyrecommendedtoseekBCFstaff’sadvicefornewfluorophores(exactname)ornew

combinations.



Chooseone:

LoadasavedconfigurationfromtheExperimentManager



Reusesettingsofanimage:openanimageandbelowtheimageclickReuse

Newsetup:click,choosethedesireddyesfromthelist,choosethescanning

methodandclickApply





p.9



SelectshowalltoolandopentheImagingsetuptab

Note:makesurethatthechosenconfigurationiscorrectandsuitsthefluorophores;make

changesifneededitishighlyrecommendedtocheckalldyesspectrumsinaspectra

viewer

ThermoFisher

Chroma



1. Laserlines

2. Maindichroicmirror

3. PMTs:PMT1andPMT2

4. Variablesecondarydichroicbeamsplitter(VSD).

5. EmissionFilterselection

6. EmissionspectrumwithGraphicrepresentationofthelaserline,thepositionofthe

VSDandemissionfilter.

7. TransmittedlightPMT‐atransmittedlightimage(nonconfocal)canbeaddedtothe

confocalimage(itrecommendedtoaddtothelongestwavelengthtrack).



3.2

6

3.1

p.10



Acquisition&parametersetting

Pulloutthelightpathswitchbetweentheocularandtheconfocal



Parametersetting

OpentheAcquisitionmodetab



Scanmode:frame(inmostcases);

  linescanmodecanbeusefulforphysiologyexperiments.

Framesize: 512X512

Speed: 8

Averaging:

Method:mean(inmostcases):

inlowsignalwithlownoiseSummethodmaybeuseful

Number:1

Mode:frameforfixativesample,forlivecellsandincaseofunstabledyeline

modewillbemoresuitable

BitDepth:definedthedynamicrangeoftheimage,choose8bit\12bitaccordingto

thebiologicalquestion.

Direction: ‐‐‐‐>(moreprecise)

Scanarea:slightnudge,zoomandrotation


