VIPA System SLIO FM 050
050-1BA00_000_FM050,3,GB - © 2015
VIPA GmbH
Ohmstr. 4
91074 Herzogenaurach
Telephone: 09132-744-0
Fax: 09132-744-1864
Email: [email protected]
Internet: www.vipa.com
Table of contents
1 General...................................................................................... 4
1.1 Copyright © VIPA GmbH ................................................... 4
1.2 About this manual.............................................................. 5
1.3 Safety information.............................................................. 6
2 Basics and Assembly.............................................................. 8
2.1 Safety information for users............................................... 8
2.2 System conception............................................................. 9
2.3 Dimensions...................................................................... 13
2.4 Installation........................................................................ 15
2.5 Demounting and module exchange................................. 19
2.6 Wiring............................................................................... 23
2.7 Trouble shooting - LEDs.................................................. 27
2.8 Installation guidelines....................................................... 27
2.9 General data.................................................................... 30
3 Hardware description............................................................ 32
3.1 Properties......................................................................... 32
3.2 Structure........................................................................... 33
3.3 Technical data.................................................................. 35
4 Deployment............................................................................ 39
4.1 Fast introduction............................................................... 39
4.2 In-/Output area................................................................. 42
4.2.1 Input area 12byte.......................................................... 42
4.2.2 Output area 10byte....................................................... 43
4.3 Parameter data................................................................ 44
4.4 Counter - Functions.......................................................... 48
4.5 Counter additional functions............................................. 53
4.6 Diagnostic and interrupt................................................... 60
VIPA System SLIO FM 050 Table of contents
HB300 | FM | 050-1BA00 | GB | 15-11 3
1 General
1.1 Copyright © VIPA GmbH
This document contains proprietary information of VIPA and is not to
be disclosed or used except in accordance with applicable agree-
ments.
This material is protected by the copyright laws. It may not be repro-
duced, distributed, or altered in any fashion by any entity (either
internal or external to VIPA), except in accordance with applicable
agreements, contracts or licensing, without the express written con-
sent of VIPA and the business management owner of the material.
For permission to reproduce or distribute, please contact: VIPA,
Gesellschaft für Visualisierung und Prozessautomatisierung mbH
Ohmstraße 4, D-91074 Herzogenaurach, Germany
Tel.: +49 9132 744 -0
Fax.: +49 9132 744-1864
EMail: [email protected]
http://www.vipa.com
Every effort has been made to ensure that the information
contained in this document was complete and accurate at
the time of publishing. Nevertheless, the authors retain the
right to modify the information.
This customer document describes all the hardware units
and functions known at the present time. Descriptions may
be included for units which are not present at the customer
site. The exact scope of delivery is described in the
respective purchase contract.
Hereby, VIPA GmbH declares that the products and systems are in
compliance with the essential requirements and other relevant provi-
sions. Conformity is indicated by the CE marking affixed to the
product.
For more information regarding CE marking and Declaration of Con-
formity (DoC), please contact your local VIPA customer service
organization.
All Rights Reserved
CE Conformity Declara-
tion
Conformity Information
VIPA System SLIO FM 050General
Copyright © VIPA GmbH
HB300 | FM | 050-1BA00 | GB | 15-11 4
VIPA, SLIO, System 100V, System 200V, System 300V, System
300S, System 400V, System 500S and Commander Compact are
registered trademarks of VIPA Gesellschaft für Visualisierung und
Prozessautomatisierung mbH.
SPEED7 is a registered trademark of profichip GmbH.
SIMATIC, STEP, SINEC, TIA Portal, S7-300 and S7-400 are regis-
tered trademarks of Siemens AG.
Microsoft and Windows are registered trademarks of Microsoft Inc.,
USA.
Portable Document Format (PDF) and Postscript are registered trade-
marks of Adobe Systems, Inc.
All other trademarks, logos and service or product marks specified
herein are owned by their respective companies.
Contact your local VIPA Customer Service Organization representa-
tive if you wish to report errors or questions regarding the contents of
this document. If you are unable to locate a customer service centre,
contact VIPA as follows:
VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany
Telefax: +49 9132 744-1204
EMail: [email protected]
Contact your local VIPA Customer Service Organization representa-
tive if you encounter problems with the product or have questions
regarding the product. If you are unable to locate a customer service
centre, contact VIPA as follows:
VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany
Tel.: +49 9132 744-1150 (Hotline)
EMail: [email protected]
1.2 About this manual
This manual describes the FM 050-1BA00 of the System SLIO from
VIPA. It contains a description of the structure, project engineering
and deployment.
This manual is part of the documentation package with order number
VIPA HB300E_FM and relevant for:
Product Order number as of state:
HW
FM 050 050-1BA00 01
The manual is targeted at users who have a background in automa-
tion technology.
The manual consists of chapters. Every chapter provides a self-con-
tained description of a specific topic.
Trademarks
Information product
support
Technical support
Objective and contents
Target audience
Structure of the manual
VIPA System SLIO FM 050 General
About this manual
HB300 | FM | 050-1BA00 | GB | 15-11 5
The following guides are available in the manual:
nAn overall table of contents at the beginning of the manual
nReferences with page numbers
The manual is available in:
nprinted form, on paper
nin electronic form as PDF-file (Adobe Acrobat Reader)
Important passages in the text are highlighted by following icons and
headings:
DANGER!
Immediate or likely danger. Personal injury is possible.
CAUTION!
Damages to property is likely if these warnings are not
heeded.
Supplementary information and useful tips.
1.3 Safety information
The system is constructed and produced for:
ncommunication and process control
nindustrial applications
noperation within the environmental conditions specified in the
technical data
ninstallation into a cubicle
DANGER!
This device is not certified for applications in
–in explosive environments (EX-zone)
The manual must be available to all personnel in the
nproject design department
ninstallation department
ncommissioning
noperation
Guide to the document
Availability
Icons Headings
Applications con-
forming with specifica-
tions
Documentation
VIPA System SLIO FM 050General
Safety information
HB300 | FM | 050-1BA00 | GB | 15-11 6
CAUTION!
The following conditions must be met before using or
commissioning the components described in this
manual:
– Hardware modifications to the process control system
should only be carried out when the system has been
disconnected from power!
–Installation and hardware modifications only by prop-
erly trained personnel.
– The national rules and regulations of the respective
country must be satisfied (installation, safety, EMC ...)
National rules and regulations apply to the disposal of the unit!Disposal
VIPA System SLIO FM 050 General
Safety information
HB300 | FM | 050-1BA00 | GB | 15-11 7
2 Basics and Assembly
2.1 Safety information for users
VIPA modules make use of highly integrated components in MOS-
Technology. These components are extremely sensitive to over-vol-
tages that can occur during electrostatic discharges. The following
symbol is attached to modules that can be destroyed by electrostatic
discharges.
The Symbol is located on the module, the module rack or on packing
material and it indicates the presence of electrostatic sensitive equip-
ment. It is possible that electrostatic sensitive equipment is destroyed
by energies and voltages that are far less than the human threshold
of perception. These voltages can occur where persons do not dis-
charge themselves before handling electrostatic sensitive modules
and they can damage components thereby, causing the module to
become inoperable or unusable. Modules that have been damaged
by electrostatic discharges can fail after a temperature change,
mechanical shock or changes in the electrical load. Only the conse-
quent implementation of protection devices and meticulous attention
to the applicable rules and regulations for handling the respective
equipment can prevent failures of electrostatic sensitive modules.
Modules must be shipped in the original packing material.
When you are conducting measurements on electrostatic sensitive
modules you should take the following precautions:
nFloating instruments must be discharged before use.
nInstruments must be grounded.
Modifying electrostatic sensitive modules you should only use sol-
dering irons with grounded tips.
CAUTION!
Personnel and instruments should be grounded when
working on electrostatic sensitive modules.
Handling of electro-
static sensitive modules
Shipping of modules
Measurements and
alterations on electro-
static sensitive modules
VIPA System SLIO FM 050Basics and Assembly
Safety information for users
HB300 | FM | 050-1BA00 | GB | 15-11 8
2.2 System conception
System SLIO is a modular automation system for assembly on a
35mm mounting rail. By means of the peripheral modules with 2, 4 or
8 channels this system may properly be adapted matching to your
automation tasks. The wiring complexity is low, because the supply of
the DC 24V power section is integrated to the backplane bus and
defective modules may be replaced with standing wiring. By deploy-
ment of the power modules in contrasting colours within the system,
further isolated areas may be defined for the DC 24V power section
supply, respectively the electronic power supply may be extended
with 2A.
nCPU (head module)
nBus coupler (head module)
nPeriphery modules
nPower modules
nAccessories
CAUTION!
Only modules of VIPA may be combined. A mixed opera-
tion with third-party modules is not allowed!
Overview
Components
VIPA System SLIO FM 050 Basics and Assembly
System conception
HB300 | FM | 050-1BA00 | GB | 15-11 9
With a CPU, CPU electronic and power module are integrated to one
casing. As head module via the integrated power module for power
supply the CPU electronic is supplied as well as the electronic of the
connected periphery modules. The DC 24 power section supply for
the linked periphery modules is established via a further connection at
the power module. By installing of up to 64 periphery modules at the
CPU, these are electrically connected, this means these are assigned
to the backplane bus, the electronic modules are power supplied and
each periphery module is connected to the DC 24V power section
supply.
CAUTION!
CPU part and power module of a CPU may not be sepa-
rated! Here you may only exchange the electronic module!
With a bus coupler bus interface and power module are integrated to
one casing. With the bus interface you get access to a subordinated
bus system. As head module via the integrated power module for
power supply the bus interface is supplied as well as the electronic of
the connected periphery modules. The DC 24 power section supply
for the linked periphery modules is established via a further connec-
tion at the power module. By installing of up to 64 periphery modules
at the bus coupler, these are electrically connected, this means these
are assigned to the backplane bus, the electronic modules are power
supplied and each periphery module is connected to the DC 24V
power section supply.
CAUTION!
Bus interface and power module of the bus coupler may
not be separated! Here you may only exchange the elec-
tronic module!
Each periphery module consists of a terminal and an electronic
module.
1 Terminal module
2 Electronic module
CPU
Bus coupler
Periphery modules
VIPA System SLIO FM 050Basics and Assembly
System conception
HB300 | FM | 050-1BA00 | GB | 15-11 10
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Controladores de YASKAWA
YASKAWA
YASKAWA A1000 Series Manual de usuario
YASKAWA
YASKAWA MP920 Manual de usuario
YASKAWA
YASKAWA CIPR-GA50C series Manual de usuario
YASKAWA
YASKAWA motoman NX100 Manual de usuario
YASKAWA
YASKAWA A1000 Series Manual de usuario
YASKAWA
YASKAWA iQpump Guía de configuración
YASKAWA
YASKAWA VS-626MT Series Manual de usuario
YASKAWA
YASKAWA JEPMC-PSA3012-E Manual de usuario
YASKAWA
YASKAWA YRC1000 Manual de usuario
YASKAWA
YASKAWA Motoman DX200 Manual de usuario
YASKAWA
YASKAWA U1000 iQpump Drive Manual de usuario
YASKAWA
YASKAWA YRC1000 Manual de usuario
YASKAWA
YASKAWA PROFINET V1000 Manual de usuario
YASKAWA
YASKAWA motoman NX100 Manual de usuario
YASKAWA
YASKAWA MP23 Series Manual de usuario
YASKAWA
YASKAWA OYMC V1000 Manual del propietario
YASKAWA
YASKAWA SI-ES3 Manual de usuario
YASKAWA
YASKAWA J1000 CIMR-JC series Manual de usuario
YASKAWA
YASKAWA motoman NX100 Manual de usuario
YASKAWA
YASKAWA V1000 Series Manual de instalación y operación
