CONVECTION STEAM OVEN
USE AND CARE GUIDE
CLEANING, MAINTENANCE, AND MORE
2
|
Wolf Customer Care 800.222.7820
CONVECTION STEAM OVEN
Customer Care
The model and serial number are printed on the enclosed
product registration card. Both numbers are also listed on
the product rating plate. Refer to page 5 for rating plate
location. For warranty purposes, you will also need the date
of installation and name of your authorized Wolf dealer.
Record this information below for future reference.
SERVICE INFORMATION
Model Number
Serial Number
Date of Installation
Certied Service Name
Certied Service Number
Authorized Dealer
Dealer Number
If your product ever needs attention, be sure to use a
Wolf Factory Certied Service provider recommended
by our Customer Care Center, or select one from our list
of providers available at wolfappliance.com/locator. All
Factory Certied Service providers are carefully selected
and thoroughly trained by us.
Important Note
To ensure this product is installed and operated as safely
and efciently as possible, take note of the following types
of highlighted information throughout this guide:
IMPORTANT NOTE highlights information that is especially
important.
CAUTION indicates a situation where minor injury or product
damage may occur if instructions are not followed.
WARNING states a hazard that may cause serious injury or
death if precautions are not followed.
IMPORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specied.
Contents
4Safety Precautions
6Convection Steam Oven Features
7Convection Steam Oven Operation
16 Care Recommendations
17 Troubleshooting
19 Wolf Warranty
wolfappliance.com
|
3
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
This oven was built to achieve recognized standards
in technology and safety regulations and is designed
for use in the home for preparing food. It is not
intended for use by persons with reduced physical,
sensory, or mental capabilities or lack of experience
and knowledge, unless supervised or unless they
have been given instruction concerning the use of
the appliance by a person responsible for their safety.
Proper use is essential to avoid damage or accidents.
Installation and connection to power supply must be
performed by a qualied electrician in accordance
with provided installation instructions.
Before rst use, ll the water tank and perform related
duties as outlined in the Prior to Use section.
Please retain this guide for future reference. If you
sell the appliance or pass it on to a third party, ensure
these instructions accompany the appliance with the
instructions on installation.
WARNING
PROPOSITION 65 FOR CALIFORNIA RESIDENTS
Cancer and Reproductive Harm—
www.P65Warnings.ca.gov
4
|
Wolf Customer Care 800.222.7820
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed including the
following:
•Read all instructions.
•Do not touch hot surfaces. Use handles or knobs.
•To protect against electrical shock, do not immerse
cord or plug in water or other liquid.
•Close supervision is necessary when any appliance
is used by or near children.
•Unplug the appliance from outlet when not in use
and before cleaning. Allow the appliance to cool
before putting on or taking off parts.
•Do not operate any appliance with a damaged cord
or plug or after the appliance malfunctions or has
been damaged in any manner. Return appliance
to the nearest Factory Certied Service facility for
examination, repair, or adjustment.
SAFETY PRECAUTIONS
•The use of accessory attachments not recom-
mended by the appliance manufacturer may cause
injuries.
•Do not use outdoors.
•Do not let the cord hang over the edge of the table
or counter or touch hot surfaces.
•Do not place on or near a hot gas or electric burner
or in a heated oven.
•Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
•Always attach plug to appliance rst, then plug
the cord into the wall outlet. To disconnect, turn all
controls off and then remove the plug from the wall
outlet.
•Do not use the appliance for other than intended
use.
•Save these instructions.
wolfappliance.com
|
5
Getting Started
We know you are eager to start cooking, but before you
do, please take some time to read this use and care guide.
Whether you are an occasional cook or an expert chef, it
will be to your benet to familiarize yourself with the safety
practices, features, operation, and care recommendations of
your Wolf Convection Steam Oven.
To ensure the best results, review cooking modes and
special features on page 11.
RETRACTABLE HANDLE MODELS
For models with a retractable handle, the handle will extend
automatically when the control panel is activated and
retract when the unit is turned off and has cooled below
175°F (80°C).
CAUTION
Do not open or close the retractable handle manually.
CONVECTION STEAM OVEN FEATURES
Convection Steam Oven Features
FEATURES
1Product Rating Plate
2Control Panel
3Control Panel Display
4Adjustable Oven Racks
5Convection Fan
6Temperature Probe Receptacle
7Halogen Lighting
8Water Tank Access Door
Convection Steam Oven (CSO30TM shown)
2
5
3
8
1
4
6
7
6
|
Wolf Customer Care 800.222.7820
OVEN OPERATION
Control Panel
Use the control panel to set cooking modes and access all
the features of the convection steam oven for exceptional
results. The control panel will become inactive after 15 min-
utes of inactivity. Touch any control to activate the display.
User Settings
The user settings allow the user to select preferences as
listed in the chart below.
SETTING
Set Language
Adjust Display
Set Clock
Congure Notications
Descale Appliance
Set Water Hardness
Set Loudness
Set Assistance Functions
Congure Temperature
Set Childproof Lock
Display Appliance Info
Demo Mode
Check Connection
Restore Factory Settings
Setting user settings:
1With the oven on, touch SETTINGS.
2Use the arrows to select the desired setting.
3Touch ENTER.
4Follow the instructions on the display.
5Touch ENTER.
Control panel
wolfappliance.com
|
7
OVEN OPERATION
Oven Operation
COOKING MODES
Select Cooking Mode:
1Touch QUICK START.
2Use the arrows to select the desired cooking mode.
3Touch ENTER.
4Review the information on the display.
5Touch ENTER.
The unit will start 20 seconds after the last key touch. To
start the mode immediately, use the arrows to select Start
Operation, then touch ENTER.
OPTIONS
Set Temperature:
1Use the arrows to select the desired temperature.
2Touch ENTER.
Set Duration:
The oven heats immediately and turns off after the specied
duration. The oven light illuminates three minutes prior to
the end time.
If the temperature probe is used, the probe overrides the
switch-off time and turns the oven off when set temperature
is reached.
1Use the arrows to select the desired cooking duration.
2Touch ENTER.
Set End:
The set end feature automatically turns the oven on and off
at specied times. The oven remains idle until the desired
start time and turns off at the desired switch-off time. The
clock must be set to the correct time for delayed start to
function properly.
If the temperature probe is used, the probe overrides the
switch-off time and turns the oven off when set temperature
is reached. If the probe temperature is not reached before
the switch-off time, it will not extend operating time.
1Use the arrows to select the desired end time.
2Touch ENTER.
Set Food Probe Temp:
1Use the arrows to select the desired probe temperature.
2Touch ENTER.
8
|
Wolf Customer Care 800.222.7820
Oven Operation
Prior to use, use the test strip provided to determine the
water hardness. The oven defaults to hard water. Refer to
User Settings on page 6 to adjust water hardness.
Follow the steps below to ensure all residual oil from the
manufacturing process has been removed.
Prior to Use:
1Clean the oven thoroughly with hot water and a mild
detergent.
2Rinse and dry with a soft cloth.
3Turn on cooking ventilation. Some smoke and odor is
normal.
4Fill and install the water tank.
5Select Convection Steam and adjust the temperature to
410°F (210°C). Heat the oven (empty) for 30 minutes.
Door at-rest position
OVEN OPERATION
After Each Use:
1Touch OFF or POWER. For modes using steam, do not
remove the water tank until “WATER IS BEING PUMPED
OFF” no longer appears on the display.
2Open the door to the at-rest position and allow to cool.
Refer to the illustration below.
3Once cool, wipe the interior dry.
4Close the door.
wolfappliance.com
|
9
TIMER
The timer can be set for a maximum of 9 hours and 59 min-
utes. Once the timer is set, the countdown appears on the
display. The timer is independent from the oven. Setting the
timer does not affect operating time or switch-off time.
Setting Timer:
1Touch TIMER.
2Use the arrows to set the desired duration.
3Touch ENTER.
To adjust the timer, use the arrows to adjust the duration. To
cancel the timer, use the left arrow to decrease the duration
to 0, then touch ENTER.
OVEN OPERATION
Oven Operation
WATER TANK
Touch WATER to remove the water tank.
The water tank holds enough water for 11/2hours of con-
tinuous steam, typically enough for 4–5 cooking sessions.
Use fresh, cold tap water. Do not use demineralized, ltered,
or distilled water.
When the oven is turned off, water is pumped back into the
tank once the water temperature is below 175°F (80°C). If the
tank needs to be lled during cooking, limit the amount of
water to less than two cups to prevent overow when water
is pumped back into the tank.
10
|
Wolf Customer Care 800.222.7820
Oven Operation
TEMPERATURE PROBE
Use only the black temperature probe shipped with this
appliance. Refer to the illustration below. The temperature
probe measures the internal temperature of food while
cooking. It can be used with all cooking modes except
More Gourmet. When the temperature probe is installed, the
actual probe temperature will be displayed.
CAUTION
Use only the probe shipped with this oven. Do not use
a probe from any other appliance.
Temperature probe
OVEN OPERATION
Setting controls:
1Place the probe in the thickest part of the food.
2Place the food in the oven and insert the connector into
the receptacle. Refer to the illustration below.
3Select the desired cooking mode.
4Touch ENTER.
5Use the arrows to select Set Food Probe Temperature.
6Touch ENTER.
7Use the arrows to select the desired probe temperature.
8Touch ENTER.
The probe temperature set point appears on the display
above the icon. To adjust the probe temperature, select
Set Food Probe Temp, use the arrows to select the desired
temperature, then touch ENTER.
CAUTION
The probe and probe receptacle will be very hot.
Handle with care.
Probe receptacle
Este manual sirve para los siguientes modelos
13
Tabla de contenidos
Idiomas:
Otros manuales de Horno de Wolf
Wolf
Wolf CT15E/S Guía
Wolf
Wolf CSO24TE Manual de usuario
Wolf
Wolf IG15/S Manual de usuario
Wolf
Wolf SO30CM/B Manual de usuario
Wolf
Wolf DO30U/P Manual del propietario
Wolf
Wolf e Series Manual de usuario
Wolf
Wolf M Series Guía
Wolf
Wolf ICBCSO24TESTH Manual de usuario
Wolf
Wolf E Series DO30-2F/S Instrucciones de uso
Wolf
Wolf E Series Manual de usuario
Wolf
Wolf Drawer Microwave Oven Manual de usuario
Wolf
Wolf M Series Instrucciones de funcionamiento
Wolf
Wolf M Series Manual de usuario
Wolf
Wolf L Series Manual de usuario
Wolf
Wolf E Series Guía
Wolf
Wolf M Series Manual de usuario
Wolf
Wolf L Series SO30F Manual de usuario
Wolf
Wolf 48" (1219) Dual Fuel Ranges Instrucciones de uso
Wolf
Wolf e Series Manual de usuario
Wolf
Wolf CSO30PM/S/PH Manual de usuario
