E SERIES OVEN

USE AND CARE GUIDE

CLEANING, MAINTENANCE, AND MORE

Wolf Customer Care 800.222.7820

Contents

4Safety Precautions

6E Series Oven Features

7Oven Operation

13 Care Recommendations

14 Troubleshooting

15 Wolf Warranty

E SERIES OVEN

wolfappliance.com

Customer Care

The model and serial number are printed on the enclosed

product registration card. Both numbers are also listed on

the product rating plate. Refer to page 6 for rating plate

location. For warranty purposes, you will also need the date

of installation and name of your authorized Wolf dealer.

Record this information below for future reference.

SERVICE INFORMATION

Model Number

Serial Number

Date of Installation

Certied Service Name

Certied Service Number

Authorized Dealer

Dealer Number

If your product ever needs attention, be sure to use a Wolf

Factory Certied Service provider recommended by our

customer care center, or select one from our list of providers

available at wolfappliance.com/locator. All Factory Certi-

ed Service providers are carefully selected and thoroughly

trained by us.

E SERIES OVEN

Important Note

To ensure this product is installed and operated as safely

and efciently as possible, take note of the following types

of highlighted information throughout this guide:

IMPORTANT NOTE highlights information that is especially

important.

CAUTION indicates a situation where minor injury or product

damage may occur if instructions are not followed.

WARNING states a hazard that may cause serious injury or

death if precautions are not followed.

IMPORTANT NOTE: Throughout this guide, dimensions in

parentheses are millimeters unless otherwise specied.

Wolf Customer Care 800.222.7820

SAFETY PRECAUTIONS

•Always use dry pot holders when removing pans

from this appliance. Wet or damp pot holders can

cause steam burns. Do not use a towel or bulky

cloth in place of pot holders.

•Exercise caution when opening the oven door. Let

hot air or steam escape before looking or reaching

into the oven.

•Be sure the oven cool air intake (located above the

door) and oven exhaust vent (located below the

door) are unobstructed at all times.

•Position oven racks in desired locations when oven

is cool. If a rack must be repositioned after the

oven is already hot, be sure pot holder does not

contact a hot heating element in the oven.

CAUTION

Before using self-clean, remove broiler pan, oven

racks, oven rack guides and any other utensils.

IMPORTANT INSTRUCTIONS

GENERAL SAFETY PRECAUTIONS

•Read this guide carefully before using this appli-

ance to reduce risk of re, electric shock or injury.

•This appliance must be properly installed and ser-

viced by a qualied installer or service agency and

grounded by a qualied technician.

•Clean only those parts listed in this guide.

•Do not use oven cleaners. No commercial oven

cleaner or oven liner protective coating of any kind

should be used in or around any part of the oven.

•Do not touch heating elements or interior surfaces

of oven. Heating elements may be hot even though

they are dark in color. Interior surfaces become hot

enough to cause burns. During and after use, do

not touch, or let clothing or other ammable mate-

rials contact heating elements or interior surfaces

of oven until they have had sufcient time to cool.

wolfappliance.com

SAFETY PRECAUTIONS

IMPORTANT INSTRUCTIONS

GENERAL SAFETY PRECAUTIONS

•Do not repair or replace any part of this appli-

ance unless specically recommended in literature

accompanying this appliance.

•Do not use aluminum foil to line any part of this

appliance.

•Never use this appliance to warm or heat the room.

•Do not leave children alone or unattended in the

area where this appliance is in use. Never allow

children to sit or stand on the appliance.

•Do not use water on grease res. Smother

the ame or use a dry chemical or foam-type

extinguisher.

•Do not heat unopened food containers, such as

baby food jars and cans. Pressure build-up may

cause the container to burst and cause injury.

•Do not store or use gasoline or other ammable

vapors and liquids in the vicinity of this or any other

appliance.

•Do not store items of interest to children above or

at the back of this appliance, as they could climb

on the appliance to reach items and be injured.

•Do not clean oven gasket; rubbing or moving the

gasket may compromise the door seal.

•Wear proper apparel. Loose-tting or hanging

garments should never be worn while using this

appliance.

WARNING

PROPOSITION 65 FOR CALIFORNIA RESIDENTS

Cancer and Reproductive Harm—

www.P65Warnings.ca.gov

Wolf Customer Care 800.222.7820

E SERIES OVEN FEATURES

E Series Oven Features

FEATURES

1Product Rating Plate

2Adjustable Oven Racks

3Control Panel and Display

4Convection Fans

5Temperature Probe Receptacle

6Halogen Lighting

Getting Started

We know you are eager to start cooking, but before you

do, please take some time to read this use & care guide.

Whether you are an occasional cook or an expert chef, it

will be to your benet to familiarize yourself with the safety

practices, features, operation and care recommendations of

your Wolf E series oven.

•Clean the oven thoroughly with hot water and mild

detergent. Rinse and dry with a soft cloth to remove

any residual oil and grease left from the manufacturing

process. Refer to care recommendations on page 13.

•To ensure the best results, review cooking modes and

special features on page 10.

CAUTION

Do not place cookware on the oven oor or use

aluminum foil or other material to line the oven oor or

side walls. Failure to adhere to this notice will damage

the porcelain interior and will void your warranty.

E series single oven

wolfappliance.com

Oven Racks

OVEN RACK GUIDES

To insert the rack guides in the oven, locate the mounting

screws on the oven side walls. Place the rack guide

mounting tabs over the screws and slide down until fully

seated. Refer to the illustration below.

OVEN RACKS

To insert a standard rack in the oven, place the rack anti-tip

lock under the side rack guide rails. Slide the rack back and

lift up to clear the rack stops. Continue to slide the rack

back until completely inside the oven. Refer to the illustra-

tion below.

OVEN OPERATION

MOUNTING

TAB

MOUNTING

SCREW

ANTI-TIP

LOCK

RACK STOP

Oven rack guides

Oven rack anti-tip lock

The bottom oven rack has a full-extension capability which

is supported by the oven door. With the rack in the lowest

rack guide position, slide it onto the door guides for greater

stability and accessibility. Refer to the illustration below.

To insert a full-extension easy glide rack, place the two rear

tabs onto the rack guide (one tab above and one below).

Refer to the illustration below. Angle the rack slightly and

slide back until the front rack notch engages the front rack

guide.

REAR TABS

NOTCH

Bottom rack

Full-extension rack

Wolf Customer Care 800.222.7820

OVEN OPERATION

Oven Operation

CONTROL PANEL

The electronic control panel features touch pads for cooking

modes and other functions. Refer to the illustration below.

1Touch desired cooking mode on the control panel. For

double ovens, touch UPPER/LOWER to select oven.

2Touch ENTER to select preset temperature or use

number pads to change temperature.

3Touch ENTER.

CONTROL PANEL LOCK

The control lock feature prevents unwanted oven operation.

Touch and hold LOCK for 3 seconds to lock and unlock the

control panel.

OVEN LIGHT

The oven light turns on automatically when the door is open

and off when closed. To turn the light on while the door is

closed, touch OVEN LIGHT on the control panel.

PRIOR TO USE

To ensure all residual oil from the manufacturing process

has been removed, each oven must go through the fol-

lowing procedure:

1Clean oven thoroughly with hot water and mild deter-

gent. Rinse and dry with a soft cloth.

2Turn on ventilation. Some smoke and odor is normal.

3Touch ROAST (ROAST for lower oven) and set

temperature to 550°F (290°C) for one hour.

4Touch OFF and allow oven to cool with the door closed.

PREHEAT

During preheat, the oven is heated as quickly and evenly

as possible and is not ideal for cooking. Preheat should be

utilized for all cooking modes except broil and convection

broil. Once preheat is complete, an audible chime indicates

the oven has reached set temperature.

Control panel (single oven shown)

wolfappliance.com

OVEN OPERATION

Oven Operation

CLOCK

The clock is visible on the control panel during all cooking

modes, except when the timer is in use. It is very important

the clock is set to the correct time if a timed cook feature is

used. The clock must be reset after a power outage.

Setting clock:

1Touch SET CLOCK on the control panel.

2Touch number pads to set time of day.

3Touch ENTER, then touch 1 for AM or 2 for PM.

4Touch ENTER.

TIMER

The timer can be set for a maximum of 9 hours, 59 minutes.

Once a time is set, the countdown is illuminated on the con-

trol panel display. The last minute counts down in seconds.

When complete, the oven will chime and time will ash. The

timer will continue to chime every 10 seconds until CLEAR

is touched. The timer is independent from the oven. Setting

the timer does not affect cook time or stop time. For infor-

mation regarding auto program features, refer to page 12.

Setting timer:

1Touch SET TIMER on the control panel.

2Touch number pads to set time in hours and minutes.

3Touch ENTER.

EXTENDED OPTIONS

The extended options feature allows the user to select pref-

erences for language, temperature unit, temperature offset,

12/24 hour clock, backlight brightness, contrast adjustment

and beeper (chime) tone.

Setting extended options:

1To enter extended options mode, touch and hold SET

CLOCK for 5 seconds.

2Touch ENTER to scroll through options, then follow

instructions on the control panel display.

3To exit, touch CLEAR.

Wolf Customer Care 800.222.7820

OVEN OPERATION

Cooking Modes

MODE TOUCH PAD PRESET RANGE PROBE USES

Convection CONV 325°F

(165°C)

170– 550°F

(75– 290°C)

•Uniform air movement makes it possible to multi-level rack

cook with even browning.

Convection Bake BAKE 375°F

(190°C)

170– 550°F

(75– 290°C)

•Ideal for pie baking.

Convection Roast ROAST 325°F

(165°C)

170– 550°F

(75– 290°C)

•Perfect for roasting tender cuts of beef, lamb, pork and

poultry.

Convection Broil BROIL 1

550°F (290°C)

450°F (230°C)

350°F (175°C)

Shortens broiling times for thicker cuts of meat, sh and

poultry. Utilize two-piece broiler pan and always broil with

oven door closed.

Bake BAKE 350°F

(175°C)

170– 550°F

(75– 290°C)

•Best for single-rack cooking, primarily baked foods. Use

for standard recipes.

Roast ROAST 350°F

(175°C)

170– 550°F

(75– 290°C)

•Best for roasting less tender cuts of meat, such as chuck

roasts and stew meat that should be covered.

Broil BROIL 1

550°F (290°C)

450°F (230°C)

350°F (175°C)

Best for broiling meats, sh and poultry pieces up to 1"

thick. Utilize two-piece broiler pan and always broil with

oven door closed.

Bake Stone STONE 400°F

(205°C)

170– 550°F

(75– 290°C)

•Baking on a ceramic stone. Great for pizza and bread.

Bake stone accessory required. Additional instructions

included with accessory.

Proof PROOF 85°F

(30°C)

85– 110°F

(30– 45°C)

•Ideal for proong, or rising bread dough.

Dehydration DEHYD 135°F

(60°C)

110– 160°F

(45– 70°C)

Dry a variety of fruits, vegetables and meats. Accessory

racks and door stop required. Additional instructions

included with accessory.

Self-Clean CLEAN Oven heats to an extremely high temperature to allow food

soil to burn off. Refer to page 12.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Horno de Wolf

Wolf

Wolf E Series SO30-2F/S Instrucciones de uso

Wolf

Wolf L Series SO30U Guía

Wolf

Wolf SPO30M Manual de usuario

Wolf

Wolf Wall Ovens Manual de funcionamiento

Wolf

Wolf ICBSO30-2U/S-TH Guía

Wolf

Wolf Convection Steam Oven Manual de usuario

Wolf

Wolf E Series DO30-2F/S Instrucciones de uso

Wolf

Wolf SPO24TE/S/TH Guía

Wolf

Wolf SO30CM/B Manual de usuario

Wolf

Wolf E Series SO30-2F/S Manual de usuario

Wolf

Wolf M Series Manual de usuario

Wolf

Wolf SO36U Manual de usuario

Wolf

Wolf E Series DO30-2F/S Manual de usuario

Wolf

Wolf M Series Guía

Wolf

Wolf CSO Series Manual de usuario

Wolf

Wolf 24 E Series Manual de usuario

Wolf

Wolf L Series SO30F Manual del propietario

Wolf

Wolf L Series SO30U Instrucciones de uso

Wolf

Wolf e Series Manual de usuario

Wolf

Wolf E Series SO30-2F/S Manual de usuario

Wolf

Wolf SO24 E Series Manual de usuario

Wolf

Wolf SO30TH Manual de usuario

Wolf

Wolf L Series SO30F Manual de usuario

Wolf

Wolf E Series Manual de usuario

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
