Whispbar K447 Guía de instalación

FittingKit

K447

Fitting Instruction for Accessory

x 1

x 6

x 2

x 4

x 2

x 4

Revision No:

FittingKit

K447

MAX kgs

W/P

WHD

W/P

WHD

Volkswagen

Caddy Maxi, 5dr Van 08-+

100

Caddy Maxi, 5dr Van 08-+

100

Caddy Maxi, 5dr Van 08-+

100

Caddy Maxi, 5dr Van 08-+

100

FittingKit

K447

First Time Installation

Remove parts from inside the package and

check. Contact your dealer if any parts are

missing or damaged.

This kit fits type A, B, C and D.

These instructions show type A crossbar

fitted. They also apply to type B, C and D.

Use keys to remove covers.

FittingKit

K447

Use hex screwdriver to reverse adjusting

screw 10 turns.

Press adjusting screw and pull crossbar legs

out. Refer to the crossbar instructions for

crossbar adjustment.

Ensure each end of the crossbar is adjusted

equally.

Adjust crossbar in or out to suit vehicle.

Refer to the crossbar instructions for

crossbar adjustment.

Please check the rear of this manual for

information relating specifically to your

vehicle.

FittingKit

K447

Tighten adjusting screw to 5 Nm (3.7 ft lb).

Remove plastic clamp block by gripping bar

leg with fingers and push firmly with thumbs

until clamp block drops out behind leg.

Select plastic internal block (from fitting kit)

and insert into foot.

Repeat for all legs.

FittingKit

K447

Refer to the underside of the pad for the part

number.

It is important to put the pads in the correct

position on the vehicle.

Letters refer to the pad part numbers and

position.

Pad Part Number:

A = 11-04-218

B = 11-04-220

Fit rubber pads (supplied with fitting kit) to

foot. Pad may vary in shape to that shown.

Make sure the pad fits into the holes

underneath the foot.

FittingKit

K447

Fitment

Remove fixed-point cover screws with 5mm

(1/4") Hex Key.

Fit the adaptor (A) to grubscrew (B).

Use the following grubscrew lengths for each

position:

A = M6 x 35mm (1 3/8")

B = M6 x 50mm (2")

FittingKit

K447

Screw adaptor with grubscrew assembly into

roof. Tighten firmly.

Repeat for all four positions.

Place crossbar foot over clamp.

Tighten the red plastic knob.

In the fully tightened position, the knobs

should be parallel with the vehicle.

Repeat for all four positions.

FittingKit

K447

Check crossbar is securely attached to the

vehicle.

Use keys to fit and lock covers

CAUTION:

Recheck all fasteners immediately after a load is

applied to the crossbars.

Regularly check screws are tight.

FittingKit

K447

Clean the car roof and surfaces of the

product that will be in contact with the car

roof.

Follow the fitting instructions for fitting the

product to your vehicle. Make sure all steps

are carried out in order.

Set crossbars a minimum distance of 700mm

(27 1/2") apart where no other distance is

specified in the fitting instructions. This is

especially important when carrying long

loads.

Check unit is securely attached whenever

you refit it to the vehicle. If the unit feels

loose, refer to the fitting instructions and

readjust.

Some glass/panoramic roofs and radio

antennae may not be able to be used when

the product is fitted.

Do not modify this product.

Refer to the maximum permitted load

capacity specified in the fitting instructions.

Do not exceed the vehicle manufacturers

roof load rating if it is lower than the

maximum load capacity specified in the fitting

instructions.

Loads should not overhang the sides of the

product and be evenly distributed with the

lowest possible centre of gravity.

Long loads should be secured with non-

elastic straps to the front and rear of the

vehicle.

Objects with pointed ends (e.g. ski poles)

should be carried with the pointed ends to

the rear of the vehicle.

Remove all loose or removable objects from

the load prior to loading.

Make sure all loads are securely fastened

with non-elastic straps. Check regularly

during longer journeys.
