AMW 528

www.whirlpool.com

INSTALLATION

PRIOR TO CONNECTING

Check that the voltage on the rating plate

corresponds to the voltage in your home.

AFTER CONNECTING

Do not remove the microwave inlet

protection plates located on the side of

the oven cavity wall. They prevent grease &

food particles from entering the microwave

inlet channels.

Ensure that the appliance is not

damaged. Check that the oven door closes

ﬁrmly against the door support and that the

internal door seal is not damaged. Empty

the oven and clean the interior with a soft,

damp cloth.

The manufacturers are not liable for any

problems caused by the user’s failure to

observe these instructions.

The earthing of this appliance is

compulsory. The manufacturer will accept

no responsibility for injury to persons,

animals or damage to objects arising from

the non-observance of this requirement.

In the case of a permanent connection,

the appliance should be installed by a

qualiﬁed technician.

Ensure the oven cavity is empty before

mounting.

Do not operate this appliance if it has

a damaged mains cord or plug, if it is not

working properly, or if it has been damaged

or dropped. Do not immerse the mains cord

or plug in water. Keep the cord away from

hot surfaces. Electrical shock, ﬁre or other

hazards may result.

Follow the supplied separate mounting

instructions when installing the appliance.

The oven can be operated only if the oven

door is ﬁrmly closed.

WARNING!

Only allow children to use the oven with

adult supervision after adequate instructions

have been given so that the child is able to

use the oven in a safe way and understands

the hazards of improper use.

The appliance is not intended for use by

young children or inﬁrm persons without

supervision. Young children should be

supervised to ensure that they do not play

with the appliance.

If your oven have a combination mode,

children should only use the oven under

adult supervision due to the temperatures

generated.

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

Do not heat, or use ﬂammable materials

in or near the oven. Fumes can create a ﬁre

hazard or explosion.

Do not use corrosive chemicals or vapors

in this appliance. This type of oven is

speciﬁcally designed to heat or cook food.

It is not designed for industrial or laboratory

use.

Do not use your microwave oven for

drying textiles, paper, spices, herbs, wood,

ﬂowers, fruit or other combustible materials.

Fire could result.

If material inside / outside the oven

should ignite, keep oven door closed and

turn the oven off. Disconnect the power

cord or shut off power at the fuse or circuit

breaker panel.

Do not over-cook food. Fire could result.

Do not leave the oven unattended,

especially when using paper, plastic or

other combustible materials in the cooking

process. Paper can char or burn and some

plastics can melt if used when heating food.

WARNING!

Do not use your microwave oven for

heating anything in airtight

sealed containers. The pressure

increases and may cause

damage when opening or

may explode.

WARNING!

The door seals and the door seal areas

must be regularly inspected for damage.

If these areas are damaged the appliance

should not be operated until it has been

repaired by a trained service technician.

EGGS

Do not use your microwave

oven for cooking or reheating

whole eggs with or without

shell since they may explode

even after microwave heating has ended.

PRECAUTIONS

GENERAL

This appliance is designed for domestic

use only!

LIQUIDS

E.g. beverages or water

in your microwave oven,

overheating the liquid beyond

boiling point can occur

without evidence of bubbling. This could

result in a sudden boil over of the hot liquid.

To prevent this possibility the following steps

should be taken:

1. Avoid using straight-sided containers

with narrow necks.

2. Stir the liquid before placing the

container in the oven and let the

teaspoon remain in the container.

3. After heating, allow standing for a short

time, stirring again before carefully

removing the container from the oven.

The appliance should not be operated

without food in the oven when using

microwaves. Operation in this manner is

likely to damage the appliance.

If you practice operating the oven, put a

glass of water inside. The water will absorb

the microwave energy and the oven will not

be damaged.

Remove wire twist-ties from

paper or plastic bags before

placing bag in the oven.

DEEP-FRYING

Do not use your microwave

oven for deep-frying,

because the oil temperature

cannot be controlled.

Use hot pads or oven mitts to prevent

burns, when touching containers, oven

parts, and pan after cooking.

CAREFUL

Always refer to a microwave cookbook (not

included) for details. Especially, if cooking or

reheating food that contains alcohol.

After heating baby food or

liquids in a baby bottle or in

a baby food jar, always stir

and check the temperature

before serving. This will ensure that the

heat is evenly distributed and the risk of

scalding or burns can be avoided.

Ensure the Lid and the Teat are removed

before heating!

Do not use the cavity for any storage

purposes.

Do not remove the microwave inlet

protection plates located on the side of

the oven cavity wall. They prevent grease &

food particles from entering the microwave

inlet channels.

PUSH - PUSH KNOBS

The knobs of this oven are aligned with the

buttons on the panel, at delivery. The

knobs will slide out if pushed and their

various functions can be accessed.

It is not necessary to have them

petruding from the panel during

operation. Simply push them back

into the panel when you

are done with the setting

and continue to operate the oven.

GLASS TURNTABLE

Use the Glass turntable with

all cooking methods. It collects

the dripping juices and food

particles that otherwise would

stain and soil the interior of the oven.

* Place the Glass turntable on the turntable

support.

ACCESSORIES

GENERAL

There are a number of accessories

available on the market. Before you buy,

ensure they are suitable for microwave use.

When you put food and accessories in

the microwave oven, ensure that they do

not come in contact with the interior of the

oven. This is especially important with

accessories made of metal or metal

parts.

If accessories containing metal comes in

contact with the oven interior, while the oven

is in operation, sparking can occur and the

oven could be damaged.

Always ensure that the turntable is able to

turn freely before starting the oven.

Ensure that the utensils you use are oven

proof and allow microwaves to pass through

them before cooking.

TURNTABLE SUPPORT

Use the turntable support under

the Glass turntable. Never put

any other utensils on the turntable

support.

* Fit the turntable support in the oven.

CRISP-PLATE

Place the food directly on the Crisp-

plate. Always use the Glass

turntable as support when

using the Crisp-plate.

Do not place any utensils on

the Crisp-plate since it will quickly

become very hot and is likely to cause

damage to the utensil.

The Crisp-plate may be preheated before

use (max. 3 min). Always use the Crisp

function when preheating the crisp-plate.

WIRE RACK

Use the Wire rack when

cooking and baking with

Forced air, Grill, Forced air &

microwaves, Auto Forced Air Combi or

Turbo grill Combi.

When grilling without

microwaves, place the wire

rack on the baking plate in

order to elevate the food closer to the

grill element in the ceiling.

Ensure that the utensils you use are oven

proof and allow microwaves to pass through

them before cooking.

BAKING PLATE

Use the bakingplate when

cooking in forced air only or

when grilling. Never use it in

combination with microwaves.

CRISP HANDLE

Use the supplied special

Crisp handle to remove the hot

Crisp plate from the oven.

CLOCK

Keep the door open while setting

the Clock. This gives you 10 minutes

to complete the setting of the Clock.

Otherwise, each step must be

accomplished within 60 seconds.

1(a). Turn the multifunction knob to the zero

position.

2(b). Press the Select button (3 seconds)

until the left-hand digit (hour’s) ﬂicker.

3. Turn the +/- knob to set the hours.

4. Press the Select button again. (The two

right hand digits (minutes) ﬂicker).

5. Turn the +/- knob to set the minutes.

6. Press the Select button again.

The Clock is set and in operation.

Note: When the appliance is ﬁrst plugged in

or after a power failure, the display is blank.

If the clock is not set, the display will remain

blank until the cooking time is set.

START PROTECTION / CHILD LOCK

This automatic safety function is

activated one minute after the oven has

returned to “stand by mode“.

PAUSE OR STOP COOKING

To pause cooking:

The cooking can be paused to check, turn

or stir the food by opening the door. The

setting will be maintained for 10 minutes.

To continue cooking:

Close the door and press the Start

button ONCE. The cooking is

resumed from where it was paused.

Pressing the Start button TWICE will

increase the time by 30 seconds.

If you don’t want to continue

cooking:

Remove the food, close the door

and press the STOP button.

A beep will signal once a minute

for 10 minutes when the cooking is

ﬁnished. Press the STOP button or open the

door to cancel the signal.

Note: The oven will only hold the settings

for 60 seconds if the door is opened and

then closed after the cooking is ﬁnished.

The door must be opened and closed e.g.

putting food into it, before the safety lock is

released. Else the display will show “door“.

1(a) 352 4

If you wish to remove the clock from the

display once it has been set,

follow steps (a) & (b) and press the Stop

button (c).

(c)

To reinstate the clock, follow the above

procedure.

(b)

1. Turn the multifunction knob to the zero

position.

2. Turn the +/- knob to set the time to

measure.

KITCHEN TIMER

Use this function when you need a

kitchen timer to measure exact time for

various purposes such as cooking eggs,

pasta or letting the dough rise before

baking etc.

The timer autostarts the countdown after

1 second.

1. Turn the multifunction knob to the

microwave position.

2. Turn the +/- knob to set the cooking time.

3. Press the Select button to select power

level.

4. Turn the +/- knob to set the preferred

power level.

5. Press the Start button.

COOK & REHEAT WITH MICROWAVES

Use this function for normal cooking

and reheating, such as vegetables, ﬁsh,

potatoes and meat.

Once the cooking process has been

started:

The time can easily be increased in 30-

second steps by pressing the Start button.

Each press increases the time with 30

seconds. You may also alter the time by

turning the +/- knob to increase or decrease

the time.

By pressing the Select button you may

switch between cooking time and power

level. Both can be altered during cooking by

turning the +/- knob after selection.

245

An acoustic signal will be heard when the

timer has ﬁnished to count down.

GRILL

Use this function to quickly give a

pleasant brown surface to the food.

1. Turn the multifunction knob to the grill

position.

2. Turn the +/- knob to set the cooking time.

3. Press the Start button.

Do not leave the oven door open for long

periods when the Grill is in operation, as this

will cause a drop in temperature.

123

JET START

This function is used for quick

reheating of food with a high water

content such as; clear soups, coffee or

tea.

This function automatically starts with full

microwave power level and the cooking time

set to 30 seconds. Each additional press

increases the time with 30 seconds. You

may also alter the time by turning the +/-

knob to increase or decrease the time after

the function has started.

1. Turn the multifunction knob to the

microwave position.

2. Press the Start button.

IMPORTANT!

Ensure that the utensils used are heat

resistant and ovenproof before grilling with

them.

Do not use plastic utensils when grilling.

They will melt. Items of wood or paper are

not suitable either.

Do not use with this function.

For food like cheese, toast, steaks and

sausages, place the wire grid on top of the

baking plate.

Note: If the cooking time is set to more than

90 minutes, the display will show ”CONT”,

I.E. the oven will run continuously without

any timelimit until you turn the oven off.

TURBO GRILL COMBI

1. Turn the multifunction knob to the Turbo

Grill position.

2. Turn the +/- knob to set the power level.

3. Press the Select button to select cooking

time.

4. Turn the +/- knob to set the cooking time.

5. Press the Start button.

The Max. possible microwave power level

when using the Turbo Grill is limited to a

factory-preset level.

Use this function to cook such food as

Gratin’s, Lasagne, Poultry and Baked

potatoes.

345

Do not use with this function.

Place food on the wire rack or on the glass

turntable when cooking with this function.

CRISP

Use this function to reheat and cook

pizzas and other dough based food. It

is also good for frying bacon and eggs,

sausages, hamburgers etc.

1. Turn the multifunction knob to the crisp

position.

2. Turn the +/- knob to set the cooking time.

3. Press the Start button.

The oven automatically works with

Microwaves and Grill in order to heat the

Crisp-plate. This way the Crisp-plate will

rapidly reach its working temperature and

begin to brown and crisp the food.

IMPORTANT!

123

Do not use with this function.

It is not possible to change or switch, the

Power level or Grill, on/off, when using the

Crisp function.

Ensure that the Crisp-plate is correctly

placed in the middle of the Glass turntable.

The oven and the crisp-plate become very

hot when using this function.

Do not place the hot crisp-plate on any

surface susceptible to heat.

Be careful, not to touch the ceiling

beneath the Grill element.

Use oven mittens or the special

Crisp handle supplied when

removing the hot Crisp-plate.

Only use the supplied Crisp

plate with this function.

Other available Crisp plate

on the market will not give

the correct result when

using this function.

Tabla de contenidos

Otros manuales de Horno de Whirlpool

Whirlpool

Whirlpool AKP 755 IX Manual de usuario

Whirlpool

Whirlpool OMR35HR0B Manual de usuario

Whirlpool

Whirlpool AKZ 6240 IX Instrucciones de funcionamiento

Whirlpool

Whirlpool AKZM 6560 Instrucciones de funcionamiento

Whirlpool

Whirlpool AKG 65901 IX Manual de usuario

Whirlpool

Whirlpool 830 Instrucciones de funcionamiento

Whirlpool

Whirlpool BMZH 5900 IN Manual de instrucciones

Whirlpool

Whirlpool BIK11 FH8TS2 PT CH Manual de usuario

Whirlpool

Whirlpool 8303648A Manual de usuario

Whirlpool

Whirlpool AKZ 478/01 Instrucciones de funcionamiento

Whirlpool

Whirlpool AKZM 755 Manual de usuario

Whirlpool

Whirlpool 8205977 Manual de usuario

Whirlpool

Whirlpool 1100PRA-K Manual de usuario

Whirlpool

Whirlpool W9 OM2M2PBLAUS Manual de usuario

Whirlpool

Whirlpool OMK58HU1X Manual de usuario

Whirlpool

Whirlpool GBD279PV Instrucciones de uso

Whirlpool

Whirlpool AKZM775IX Instrucciones de funcionamiento

Whirlpool

Whirlpool W10777365B Manual de usuario

Whirlpool

Whirlpool GBD307PRB03 Manual de usuario

Whirlpool

Whirlpool AKZM 655 Manual de usuario

Whirlpool

Whirlpool W9 OS2 4S1 P Manual de usuario

Whirlpool

Whirlpool AKZM 8380 Instrucciones de funcionamiento

Whirlpool

Whirlpool AKZ 238 Instrucciones de funcionamiento

Whirlpool

Whirlpool AKPM 777 Instrucciones de funcionamiento

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
