MODEL NUMBERS

WD20EURS WD10EURS WD7500AVDS WD2500AVVS

WD20EVDS WD10EVDS WD5000AVDS WD1600AVVS

WD15EURS WD10EVVS WD5000AVVS

WD15EVDS WD7500AURS WD3200AVVS

Note: Not all products may

be available in all regions of

the world.

WD AV-GP

Power-saving Hard Drives

Power-conserving WD AV-GP SATA hard drives take

advantage of WD GreenPower Technology™to meet the

24x7 requirements of demanding audio and video

environments. With power reduction of up to 40 percent,

they deliver cool and quiet operation and reliability perfect

for audio video applications such as PVRs, DVRs, set-top

boxes (STBs) as well as surveillance video recording.

INTERFACE

SATA 3 Gb/s

WIDTH/HEIGHT

3.5-inch/1-inch

ROTATIONAL SPEED

IntelliPower

CAPACITIES

160 GB to 2 TB

24x7 reliability

These drives are designed to last in

always-on, streaming digital audio/

video environments such as

PVR/DVR, DVR recorders, and

surveillance video recorders.

Reduced power

consumption

With the combination of WD’s

IntelliSeek, IntelliPark, and

IntelliPower technologies, WD has

reduced power consumption by up

to 40 percent compared to

competitors’ drives. Lower power

means less heat and better

reliability.

Quiet

Noise levels have been minimized to

less than one sone* – virtually below

the threshold of human hearing.

SilkStream™

Optimized for smooth, continuous

digital video playback of up to

twelve simultaneous HD streams.

SilkStream is compatible with the

ATA streaming command set so CE

customers can use standard

streaming management and error

recovery options.

IntelliSeek™

Calculates optimum seek speeds to

lower power consumption, noise,

and vibration.

IntelliPower™

A fine-tuned balance of spin speed,

transfer rate, and caching

algorithms designed to deliver both

significant power savings and solid

performance.

IntelliPark™

Parks the recording heads off the

disk surface during spin up, spin

down, and when the drive is off.

This ensures the recording head

never touches the disk surface

resulting in improved long term

reliability due to less head wear, and

improved non-operational shock

tolerance.

Preemptive Wear Leveling

(PWL)

The drive arm frequently sweeps

across the disk to reduce uneven

wear on the drive surface common

to audio video streaming

applications.

Advanced Format (AF)

Technology being adopted by WD

and other drive manufacturers as

one of multiple ways to continue

growing hard drive capacities. AF is

a more efficient media format that

enables increased areal densities.

(EURS/AURS models only)

1 million hours MTBF

Best-in-class reliability for

mainstream 3.5-inch form-factor AV

storage.**

* A sone is a subjective unit of loudness as perceived by a

person with normal hearing.

** Based upon dual tuner system operating in typical 30°C air

ambient environment.

Product Features

WD AV-GP

-2-

1As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment. As used for buffer or cache, one megabyte (MB) = 1,048,576

bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second, and gigabit per second (Gb/s) = one billion bits per second. Effective maximum SATA 3 Gb/s transfer rate calculated according to the Serial ATA specification published by the SATA-

IO organization as of the date of this specification sheet. Visit www.sata-io.org for details.

2Controlled unload at ambient condition.

3The term of the limited warranty may vary by region. Visit http://support.wdc.com/warranty for details.

4No non-recoverable errors during operating tests or after non-operating tests.

5Sound power level.

Specifications12 TB 2 TB 1.5 TB 1.5 TB 1 TB 1 TB

Model numbers WD20EURS WD20EVDS WD15EURS WD15EVDS WD10EURS WD10EVDS

WD10EVVS

Formatted capacity 2,000,398 MB 2,000,398 MB 1,500,301 MB 1,500,301 MB 1,000,204 MB 1,000,204 MB

User sectors per drive 3,907,029,168 3,907,029,168 2,930,277,168 2,930,277,168 1,953,525,168 1,953,525,168

Advanced Format (AF) Yes No Yes No Yes No

Native command queuing Yes Yes Yes Yes Yes Yes

SATA latching connector Yes Yes Yes Yes Yes Yes

Form factor 3.5-inch 3.5-inch 3.5-inch 3.5-inch 3.5-inch 3.5-inch

Performance

Data transfer rate (max)

Buffer to host (SATA)

Host to/from drive (sustained)

3 Gb/s

130 MB/s

3 Gb/s

110 MB/s

3 Gb/s

130 MB/s

3 Gb/s

110 MB/s

3 Gb/s

110 MB/s

3 Gb/s

111 MB/s

Cache (MB) 64 32 64 32 64 32 (WD10EVDS)

8 (WD10EVVS)

Average latency (ms) 4.24.24.24.24.24.2

Rotational speed (RPM) IntelliPower IntelliPower IntelliPower IntelliPower IntelliPower IntelliPower

Average drive ready time (sec) 14.5 14.5 14.5 14.5 14.3 14.3

Reliability/Data Integrity

Load/unload cycles2300,000 300,000 300,000 300,000 300,000 300,000

Non-recoverable read errors

per bits read

<1 in 1014 <1 in 1014 <1 in 1014 <1 in 1014 <1 in 1014 <1 in 1014

Limited warranty (years)3333333

Power Management

12VDC (A, max) 1.725 1.603 1.725 1.603 1.464 1.671

Average power requirements (W)

Read/Write

Idle

Standby

Sleep

5.3

4.8

0.9

5.9

4.9

0.7

5.3

4.8

0.9

5.9

4.9

0.7

4.9

4.2

0.4

4.9

4.2

0.4

Environmental Specifications4

Temperature (°C)

Base casting (max)

Operating

Non-operating

0 to 60

-40 to 70

0 to 60

-40 to 70

0 to 60

-40 to 70

0 to 60

-40 to 70

0 to 60

-40 to 70

0 to 60

-40 to 70

Shock (Gs)

Operating (2 ms, read/write)

Operating (2 ms, read)

Non-operating (2 ms)

250

300

Average acoustics (dBA)5

Idle mode

Quiet seek mode

Physical Dimensions

Height (in./mm, max) 1.028/26.1 1.028/26.1 1.028/26.1 1.028/26.1 1.028/26.1 1.028/26.1

Length (in./mm, max) 5.787/147 5.787/147 5.787/147 5.787/147 5.787/147 5.787/147

Width (in./mm, ± .01 in.) 4/101.6 4/101.6 4/101.6 4/101.6 4/101.6 4/101.6

Weight (lb./kg, ± 10%) 1.40/0.64 1.61/0.73 1.40/0.64 1.61/0.73 1.32/0.60 1.32/0.60

WD AV-GP

-3-

Western Digital, WD, the WD logo, and Put

Your Life On It are registered trademarks in

the U.S. and other countries; and

WD GreenPower Technology, SilkStream,

IntelliSeek, IntelliPower, IntelliPark, and

FIT Lab are trademarks of Western Digital

Technologies, Inc. Other marks may be

mentioned herein that belong to other

companies. Product specifications subject to

change without notice.

Western Digital

3355 Michelson Drive, Suite 100

Irvine, California 92612

U.S.A.

2879-701250-A11 Jan 2011

For service and literature:

http://support.wdc.com

www.westerndigital.com

800.ASK.4WDC North America

800.832.4778 Spanish

+800.6008.6008 Asia Pacific

00800.27549338 Europe

(toll free where available)

+31.880062100 Europe/Middle East/Africa

IO organization as of the date of this specification sheet. Visit www.sata-io.org for details.

2Controlled unload at ambient condition.

3The term of the limited warranty may vary by region. Visit http://support.wdc.com/warranty for details.

4No non-recoverable errors during operating tests or after non-operating tests.

5Sound power level.

Specifications1750 GB 750 GB 500 GB 320 GB 250 GB 160 GB

Model numbers WD7500AVDS WD7500AURS WD5000AVDS

WD5000AVVS

WD3200AVVS WD2500AVVS WD1600AVVS

Formatted capacity 750,156 MB 750,156 MB 500,107 MB 320,072 MB 251,059 MB 160,041 MB

User sectors per drive 1,465,149,168 1,465,149,168 976,773,168 625,142,448 490,350,672 312,581,808

Advanced Format (AF) NoYesNo NoNoNo

Native command queuing Yes Yes Yes Yes Yes Yes

SATA latching connector Yes Yes Yes Yes Yes Yes

Form factor 3.5-inch 3.5-inch 3.5-inch 3.5-inch 3.5-inch 3.5-inch

Performance

Data transfer rate (max)

Buffer to host (SATA)

Host to/from drive (sustained)

3 Gb/s

110 MB/s

3 Gb/s

110 MB/s

3 Gb/s

110 MB/s

3 Gb/s

80 MB/s

3 Gb/s

80 MB/s

3 Gb/s

80 MB/s

Cache (MB) 32 64 32 (WD5000AVDS)

8 (WD5000AVVS)

888

Average latency (ms) 4.2 4.2 4.2 4.2 4.2 4.2

Rotational speed (RPM) IntelliPower IntelliPower IntelliPower IntelliPower IntelliPower IntelliPower

Average drive ready time (sec) 14.3 14.3 14.3 8 8 8

Reliability/Data Integrity

Load/unload cycles2300,000 300,000 300,000 300,000 300,000 300,000

Non-recoverable read errors

per bits read

<1 in 1014 <1 in 1014 <1 in 1014 <1 in 1014 <1 in 1014 <1 in 1014

Limited warranty (years)333 3 333

Power Management

12VDC (A, max) 1.671 1.464 1.392 1.350 1.350 1.350

Average power requirements (W)

Read/Write

Idle

Standby

Sleep

4.9

4.2

0.4

4.9

4.2

0.4

4.1

3.7

0.8

4.7

2.3

0.8

4.7

2.3

0.8

4.7

2.3

0.8

Environmental Specifications4

Temperature (°C)

Base casting (max)

Operating

Non-operating

0 to 60

-40 to 70

0 to 60

-40 to 70

0 to 60

-40 to 70

0 to 60

-40 to 70

0 to 60

-40 to 70

0 to 60

-40 to 70

Shock (Gs)

Operating (2 ms, read/write)

Operating (2 ms, read)

Non-operating (2 ms)

300

350

Average acoustics (dBA)5

Idle mode

Quiet seek mode

Physical Dimensions

Height (in./mm, max) 1.028/26.1 1.028/26.1 1.028/26.1 1.028/26.1 1.028/26.1 1.028/26.1

Length (in./mm, max) 5.787/147 5.787/147 5.787/147 5.787/147 5.787/147 5.787/147

Width (in./mm, ± .01 in.) 4/101.6 4/101.6 4/101.6 4/101.6 4/101.6 4/101.6

Weight (lb./kg, ± 10%) 1.32/0.60 1.32/0.60 0.97/0.44 0.99/0.45 0.99/0.45 0.99/0.45

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Almacenamiento de Western Digital

Western Digital

Western Digital WD15NPVT Instrucciones de instalación

Western Digital

Western Digital WD1500HLFS - VelociRaptor 150 GB Hard Drive Manual de usuario

Western Digital

Western Digital My Passport Ultra Manual de usuario

Western Digital

Western Digital WDBAAH0015HCH - My Book Elite Manual de usuario

Western Digital

Western Digital WD800AAJB - Caviar 80 GB Hard Drive Manual de operación

Western Digital

Western Digital My Book WDH1B10000 Manual de usuario

Western Digital

Western Digital WD1003FBYX - RE4 Instrucciones de instalación

Western Digital

Western Digital My Cloud DL2100 Manual de usuario

Western Digital

Western Digital WD AV-GP Manual de usuario

Western Digital

Western Digital WDBAAP0000NBK - TV Live Media Player Manual de usuario

Western Digital

Western Digital WD SATA Hard Drives Manual de usuario

Western Digital

Western Digital WDBAAF0010HBK - My Book Essential 1 TB External Hard... Manual de usuario

Western Digital

Western Digital WDBAAB2500ASL - My Passport For Mac Manual de usuario

Western Digital

Western Digital My Book WDH1U10000 Manual de usuario

Western Digital

Western Digital WDBAAA3200ABK - My Passport Essential 320 GB External Hard... Manual de usuario

Western Digital

Western Digital WD1000FYPS - RE2-GP Manual de usuario

Western Digital

Western Digital WD SATA Hard Drives Manual de usuario

Western Digital

Western Digital HPBAAC3200ABK-NHSN - HP SimpleSave Portable Hard Drive 320 GB... Instrucciones de instalación

Western Digital

Western Digital Caviar WD7500AAKS Manual

Western Digital

Western Digital WD RE3 Manual de usuario

Western Digital

Western Digital WDBFKT0040BGY Manual de usuario

Western Digital

Western Digital Caviar Green WD7500AZRX Manual de operación

Western Digital

Western Digital WDG2NC10000 - My Book World Edition II Manual de usuario

Western Digital

Western Digital WDE1MS1200BN - Elements Portable 120 GB External Hard... Manual de usuario

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Dell

Dell PowerVault MD3600f Series Manual de usuario
