Weider WEMC07730 Manual de usuario

CAUTION

Read all precautions and instruc-

tions in this manual before

using this equipment. Save this

manual for future reference.

Model No. WEMC07730

QUESTIONS?

As a manufacturer, we are com-

mitted to providing complete

customer satisfaction. If you

have questions, or if there are

missing or damaged parts, we

will guarantee complete satis-

faction through direct assis-

tance from our factory.

TO AVOID DELAYS, PLEASE

CALL DIRECT TO OUR TOLL-

FREE CUSTOMER HOT LINE.

The trained technicians on our

customer hot line will provide

immediate assistance, free of

charge.

CUSTOMER HOT LINE:

1-877-992-5999

Mon.–Fri., 6 a.m.–6 p.m. MST

Visit our website at

www.weiderplatinum.com

USER’S MANUAL

IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

WEIDER is a registered trademark of ICON Health & Fitness, Inc.

TABLE OF CONTENTS

1. Read all instructions in this manual before

using the resistance system accessory. Use

the resistance system accessory only as

described in this manual.

2. It is the responsibility of the owner to ensure

that all users of the resistance system acces-

sory are adequately informed of all precau-

tions.

3. The resistance system accessory is intended

for home use only. Do not use the resistance

system accessory in any commercial, rental,

or institutional setting.

4. Always wear athletic shoes for foot protec-

tion while exercising.

5. Make sure that all parts are properly tight-

ened each time the resistance system acces-

sory is used. Replace any worn parts imme-

diately.

6. The resistance system accessory is

designed to be used with the WEIDER PLAT-

INUM resistance system.

7. Make sure the curl knob is in place and fully

tightened each time the curl pad is used.

8. If you feel pain or dizziness while exercising,

stop immediately and begin cooling down.

WARNING: Before beginning this or any exercise program, consult your physician. This

is especially important for persons over the age of 35 or persons with pre-existing health problems.

Read all instructions before using. ICON assumes no responsibility for personal injury or property

damage sustained by or through the use of this product.

WARNING: To reduce the risk of serious injury, read the following important precautions

before using the resistance system accessory.

IMPORTANT PRECAUTIONS

Curl Pad

Curl Knob

Leg Lever

Leg

Curl Bar

BEFORE YOU BEGIN

Thank you for selecting the innovative WEIDER®

PLATINUM resistance system accessory. The resist-

ance system accessory is designed to be used with

the WEIDER®PLATINUM to develop the muscle

groups of the arms and legs.

For your benefit, read this manual carefully before

using the resistance system accessory. If you have

questions after reading this manual, please call our

Customer Service Department toll-free at

1-877-992-5999, Monday through Friday, 6 a.m. until

6 p.m. Mountain Time (excluding holidays). To help us

assist you, please note the product model number

before calling. The model number is WEMC07730.

Before reading further, please review the drawing

below and familiarize yourself with the parts that are

labeled.

Before beginning assembly, carefully read the

following information and instructions:

•Assembly requires two persons.

•Place all parts in a cleared area and remove the

packing materials. Do not dispose of the packing

materials until assembly is completed.

•Tighten all parts as you assemble them, unless

instructed to do otherwise.

•As you assemble the resistance system accesso-

ry, make sure that all parts are oriented as shown

in the drawings.

The following tools (not included) are required

for assembly:

• One adjustable wrench

• One rubber mallet

• One Phillips screwdriver

• Two Allen wrenches

(included with the

resistance system)

2. Slide the two Pad Tubes (F) removed in step 1

into the new Leg Lever (9). Slide the four Large

Foam Pads (E) onto the Pad Tubes.

1. Remove the Cotter Pin (A) from the lower Leg

Station Pin (B). Remove the Leg Station Pin from

the original Leg (C). Remove the Cable (S) from

the original Leg Lever (D).

Remove the Cotter Pin (A) from the upper Leg

Station Pin (B). Remove the Leg Station Pin from

the Leg (C) and the Leg Lever (D).

Remove the two Large Foam Pads (E) and the

Pad Tube (F) from the Leg Lever (D). Set the Leg

Lever aside.

Remove the two Large Foam Pads (E) and the

Pad Tube (F) from the Leg (C).

Make Things Easier for Yourself

This manual is designed to ensure that the resist-

ance system accessory can be assembled suc-

cessfully by most people.

ASSEMBLY

5. Remove the two Leg Outer Caps (M) from the

Leg (C).

4. Remove the two Screws (K) used to attach the

Leg Lever Bumper (L) to the Leg (C).

3. Note: If your Leg (C) has a hole for the Curl

Knob (not shown) in the indicated position,

skip to step 11.

Remove the two Bolts (G), the four Washers (H),

and the two Nylon Locknuts (I) attaching the Leg

Hole

8. Press the two Leg Outer Caps (M) removed in

step 5 onto the Leg (14).

7. Attach Pulley (R) removed in step 6 inside of the

new Leg (14) with the Bolt (N), the two Washers

(O), the two Spacers (P), and the Nylon Locknut

(Q) removed in step 6.

6. Remove the Bolt (N), the two Washers (O), the

two Spacers (P), the Nylon Locknut (Q), and the

Pulley (R) from the Leg (C).

11. Slide the Pad Tube (5) into the Leg (14). Slide the

two Large Foam Pads (7) onto the Pad Tube.

10. Attach the Leg (14) to the Rail (J) with the two

Bolts (G), the four Washers (H), and the two

Nylon Locknuts (I) removed in step 3.

9. Attach the Leg Lever Bumper (L) to the Leg (14)

with the two Screws (K) removed in step 4. 9

12. Attach the Curl Pad (4) to the Curl Post (3) with

two M6 x 16mm Screws (2). 12

This section explains how to adjust the resistance system accessory. Make sure all parts are properly tightened

each time the resistance system accessory is used. Replace worn parts immediately. The resistance system

accessory can be cleaned with a damp cloth and a mild, non-abrasive detergent. Do not use solvents.

USING THE LEG LEVER

To use the Leg Lever (9), attach it to the Leg (14) with

a Leg Station Pin (B). Slide a Cotter Pin (A) onto the

Leg Station Pin.

Route the hook end of the Leg Lever Cable (S) under

the Pulley (R) in the Leg (14), and attach it to the Leg

Lever (9). Make sure the hook is oriented as

shown when attaching it to the Leg Lever.Insert a

Leg Station Pin (B) into the Leg, under the Cable.

Slide a Cotter Pin (A) onto the Leg Station Pin.

See the inset drawing. Attach a long end of the Leg

Lever Cable (S) to one end of the lower cable (T) with

a Cable Clip (U). Attach the other long end of the

Leg Lever Cable to the other end of the low cable

in the same manner.

To perform the leg extension exercise, the indicat-

ed Pad Tube (5) should be inserted through the Leg

(14) as shown.

To perform the leg curl exercise, remove a Large

Foam Pad (7) from the Pad Tube (5). Remove the

Pad Tube and insert it through the hole in the Leg

Lever Bumper (L). Slide the Large Foam Pad back

onto the Pad Tube.

ATTACHING THE CURL PAD

To attach the Curl Pad (4), insert the Curl Post (3)

into the Leg (14). Secure the Curl Post with the Curl

Knob (12).

Remove the Curl Pad (3) from the resistance sys-

tem when performing an exercise that does not

require it.

Hook

ADJUSTMENTS

ATTACHING THE CURL BAR

To use the Curl Bar (8), first attach the leg lever to the

leg (see USING THE LEG LEVER on page 9). Attach

the Curl Bar to the hook on the Leg Lever (9) with a

Cable Clip (13). 8
