WamBam NANTUCKET Manual de usuario
WWW.WAMBAMFENCE.COM 1
ASSEMBLY
INSTRUCTIONS BL19102
BL19102
ASSEMBLY
INSTRUCTIONS
60 MIN
Want to see a video on how to
assemble this product?
Scan the QR code
NANTUCKET
VINYL PICKET
GATE WITH WITH
STAINLESS STEEL
HARDWARE
WWW.WAMBAMFENCE.COM VER. 043021
WWW.WAMBAMFENCE.COM
2
ASSEMBLY
INSTRUCTIONS
BL19102
kCheck the inside of the larger pieces in your box for other
materials packed inside.
kWhen assembling components, place on a non-abrasive
surface (i.e. shipping box) to avoid scratching.
k
unobstructed assembling.
kYou should not need to use excessive force when assembling
components.
VISIT OUR WEBSITE FIRST,
SO WE CAN HELP YOU RIGHT AWAY!
Although great care has been taken to ensure proper packaging
and handling of this product, occasionally problems occur. If you
our website to order replacement parts. If you experience any
further trouble with your product, please contact our customer
service department.
parts.nychbrands.com
hmmm@wambamfence.com
704-892-5222 /877-778-5733
Customer service agents are available to take calls weekdays from 9am-
5pm EST. If you call outside of business hours, please leave a voicemail.
To help you quickly and accurately, please have reference item
number BL19102
on page 5. It is helpful if you can provide the batch lot which is a
stamped number on the inside of the box.
this product, we are happy to assist you with the process, so
please give us a call at 704-892-5222 / 877-778-5733.
If for some reason you need to return this product, please
return the product,
GENERAL
INFORMATION
MISSING
OR
DAMAGED
PARTS?
NEED
ASSEMBLY
HELP?
NEED TO
RETURN?
IMPORTANT
WWW.WAMBAMFENCE.COM 3
ASSEMBLY
INSTRUCTIONS BL19102
understand your fence.
install your gate posts before you do anything else.
of fence that is connected to another post. This way, the weight strain will be trans-
ferred onto two posts versus just one. Installing fence panels on both sides of your
stainless steel screws to permanently assemble the gate.
1. That you have everything necessary to complete the gate.
2. That you will have assembled the gate frame in the correct order.
4. The gate height and width are similar to the measurements shown on page four.
GENERAL
INFORMATION
WWW.WAMBAMFENCE.COM
4
ASSEMBLY
INSTRUCTIONS
BL19102
DETAILED PRODUCT DIMENSIONS AND SPECIFICATIONS
48 in
3.5 in
3.78 in
1.5 in
7.75 in
24.875 in
4 in
3.5 in
47.5 in
B
C C
A
1
.5in.
3.5in.
3.5in.
1
.5in.
AB
3.5in.
1
.5in.
.090in. wall thickness
C
B
WWW.WAMBAMFENCE.COM 5
ASSEMBLY
INSTRUCTIONS BL19102
STEP 1:
LAY OUT MATERIALS
A
D E
F G
B C H
I
J
K
L
(2)
(2)
(2)
(2)
Steel Screws (26)
Screws (6)
(1) with
Screws (6)
(2)
(1)
1½
(2)
1½
⅞
(1)
1½
Stainless Steel
(16)
WWW.WAMBAMFENCE.COM
6
ASSEMBLY
INSTRUCTIONS
BL19102
STEP 2:
ASSEMBLE GATE FRAME
STEP 2.1 STEP 2.2
all the way into the
corner as illustrated.
Insert fully to
this point
Insert fully to
this point
B
F
D
STEP 2.3
Insert fully to this point
Insert fully to this point
STEP 2.4
48 in
Insert fully to
this point
WWW.WAMBAMFENCE.COM 7
ASSEMBLY
INSTRUCTIONS BL19102
STEP 2.4 STEP 2.5
Insert the Top Rail all the
hits the back as illustrated.
Insert the top rail all the
way into the opposite
back as illustrated.
Insert fully to
this point
E
C
Insert fully to
this point
STEP 2.6
Slide the assembled gate
frame top down over the
Completely assembled
gate frame
WWW.WAMBAMFENCE.COM
8
ASSEMBLY
INSTRUCTIONS
BL19102
STEP 3:
GATE FRAME TOGETHER
STEP 3.1
Fasten the gate frame together
-
less Steel Screws .
Note: Do not put
screws in the outward
facing holes of this
T-bracket and gate
allow for future hinge
H
WWW.WAMBAMFENCE.COM 9
ASSEMBLY
INSTRUCTIONS BL19102
STEP 4:
PICKETS INTO GATE FRAME AND
POST CAPS
STEP 5:
GATE HINGES AND LATCH FINGER
STEP 4.1
STEP 5.1
STEP 4.2
Insert Pickets
through the top rail and
Install Post Caps as illustrated.
Use PVC glue (not included) if you
would like to permanently secure
the post caps to the T-brackets.
Fasten the Latch Finger
to the top bracket with (6)
-
less steel screws.
Fasten the Hinge to the
black self-drilling stainless
steel screws.
G
A
K
I
WWW.WAMBAMFENCE.COM
10
ASSEMBLY
INSTRUCTIONS
BL19102
STEP 6:
GATE HINGES TO POST
STEP 7:
LEVEL GATE AND HINGES
STEP 6.1
STEP 7.1
Use temporary spacers or
wooden blocks to rest the gate on
Fasten the gate hinges to the post
screws.
Fasten the gate hinges to
the inside of the fence post
self-drilling stainless steel
screws by swinging the
gate out as illustrated.
