Oxgard K-14 Manual de usuario
VOZROZHDENIE LLC
OKPD 2 27.90.40.190
TU 27.90.40-001-33120038-2018
APPROVED
VZR.248100.000 AS
SWING GATE
MODEL K-14
VZR.248100.000 RE
OPERATION MANUAL
27 pages
2019
VZP 248100.000 OP
K-14 Swing gate
Operation manual
2
CONTENTS
1PRODUCT DESCRIPTION AND OPERATION ................................................................................ 4
1.1 Product description and operation.......................................................................................... 4
1.2 Indication panel of the product................................................................................................ 8
2INTENDED USE ............................................................................................................................... 9
2.1 Operation limitations............................................................................................................... 9
2.2 The product preparation for installation ................................................................................ 10
2.4 Actions in extreme conditions............................................................................................... 13
3MAINTENANCE ............................................................................................................................. 14
3.1 General instructions.............................................................................................................. 14
3.2 Safety measures .................................................................................................................. 15
3.3 Procedure for the product maintenance................................................................................ 15
3.4 Visual inspection of the product............................................................................................ 15
3.5 Check of the product components........................................................................................ 16
3.6 Check of the product performance........................................................................................ 16
4MINOR REPAIR ............................................................................................................................. 17
4.1 Minor repair of the product.................................................................................................... 17
4.2 Minor repair of the product components ............................................................................... 17
4.3 Malfunctions during the warranty period............................................................................... 18
5STORAGE...................................................................................................................................... 19
6TRANSPORTATION....................................................................................................................... 20
7UTILIZATION.................................................................................................................................. 21
APPENDIX А — distributors and service centers.............................................................................. 22
ABBREVIATIONS................................................................................................................................. 23
VZP 248100.000 OP
K-14 Swing gate
Operation manual
3
This Operation Manual (OP) is applied to Oxgard K-14 swing gate and its
variants (hereinafter referred to as Product).
The manufacturer reserves the right to change equipment, technical
specifications and appearance of the product without notice.
Before using the product, it is necessary to additionally read
VZR.248100.000 DTS.
This Operation Manual is a document certifying basic parameters and
characteristics of the product guaranteed by manufacturer.
This Operation Manual intended for studying principle of operation,
structure and design of the product for proper operation, ensuring full use of
technical capabilities and maintaining permanent readiness for operation.
VZP 248100.000 OP
K-14 Swing gate
Operation manual
4
1 PRODUCT DESCRIPTION AND OPERATION
1.1 Product description and operation
1.1.1 Oxgard K-14 motorized swing gate is designed for control of access and
flow of people.
The product can be used at entrance of enterprises, organizations and
banks, educational institutions, sports and entertainment facilities, shops, train
stations and other institutions.
1.1.2 The product structure is shown in Table 1.
Table 1 –The product structure
Designation of the
product
Name of the product
Quantity
Note
swing gate
K-14
1
Control panel
Praktika universal control panel
1
Power supply unit*
Power supply unit
Fence section kit *
Praktika fence
Note-Parts of the product marked with ( * ) are delivered optionally.
VZP 248100.000 OP
K-14 Swing gate
Operation manual
5
1.1.3 The product technical specifications are given in Table 2
Table 2 –Technical specifications
Name of parameter
Value
Dimensions (WхHхL ) for passage width, mm:
- 600 mm
- 900 mm
- 1000 mm
- 1200 mm
820х1140х159
1120х1140х159
1220х1140х159
1420х1140х159
Weight, kg for passage width, mm:
- 600 mm
- 900 mm
- 1000 mm
- 1200 mm
50.0
56.0
58.0
62.0
Range of ambient temperatures, °С:
- operation
- transportation and storage
+1...+40
+1...+40
Relative humidity, %, not more than
80
Width of formed passage, mm
600-1200
Throughput capacity, person/ min
12
Service life, years
8
Supply voltage (DC), V:
- nominal
- working
24.0
19.0...29.0
Average current at standby mode*, A
0.4
Average current at operation mode*, A
2.0
Maximum current consumption*, A
5.0
Note - * current values are given for nominal supply voltage
VZP 248100.000 OP
K-14 Swing gate
Operation manual
6
1.1.4 The product structure.
All component of the gate are made of polished stainless steel, the gate
leaf is made of tempered glass.
The gate includes a fixed stand with housing, cup for fastening to the floor,
indication panel, rotary upper housing with electric drive and glass leaf.
The gate leaf can turn within 180° (+90°-90°).
Figure 1-General view of the fence gate.
Figure 1-General view of the fence gate.
1 - Cover; 2 –Insert; 3 - Indication panel; 4- Body housing;
5 –Cap; 6- Glass; 7- Upper housing
VZP 248100.000 OP
K-14 Swing gate
Operation manual
7
1.1.5 Overall dimensions.
Figure 2 - Overall dimensions of the gate for passage width of 600 mm.
Figure 2 - Overall dimensions of the gate for passage width of 600 mm
1.1.6 The marking contains manufacturer's trademark, designation,
serial number.
1.1.7 Overall dimensions of packaging.
Overall dimensions of the gate with glass, mm:
1) Gate with passage width of 600 mm –1035х775х185;
2) Gate with passage width of 900 mm –1035х1075х185;
3) Gate with passage width of 1000 mm –1035х1175х185;
4) Gate with passage width of 1200 mm –1035х1375х185.
VZP 248100.000 OP
K-14 Swing gate
Operation manual
8
1.2 Indication panel of the product
The gate has a tri-color light indication (Figure 1-3, indication panel):
1) Green - passing allowed (leaf is open);
2) Red - passing prohibited (leaf is closed);
3) Yellow - mode of power initialization (when power is being supplied).
VZP 248100.000 OP
K-14 Swing gate
Operation manual
9
2 INTENDED USE
2.1 Operation limitations
ATTENTION: FAILURE TO COMPLY WITH THE SAFETY
REQUIREMENTS SPECIFIED IN THIS SECTION MAY RESULT IN DEATH AND
DAMAGE TO HEALTH, COMPLETE OR PARTIAL LOSS OF PERFORMANCE
OF THE PRODUCT AND (OR) AUXILIARY EQUIPMENT.
ATTENTION: INSTALLATION OF A PRODUCT SHOULD BE
CARRIED OUT BY QUALIFIED PERSONNEL ACCORDING TO THE
INSTALLATION MANUAL.
ATTENTION: MANUFACTURER DISCLAIMS ANY LIABILITY FOR
DEATH AND DAMAGE TO HEALTH, COMPLETE OR PARTIAL LOSS OF
PERFORMANCE OF THE PRODUCT AND (OR) AUXILIARY EQUIPMENT IF
USER FAILS TO COMPLY WITH SAFETY REQUIREMENTS SPECIFIED IN
THIS SECTION, AND ALSO WILL VOID YOUR WARRANTY ON THE
PRODUCT.
VZP 248100.000 OP
K-14 Swing gate
Operation manual
10
IT IS PROHIBITED TO:
INSTALL POWER SUPPLY UNIT INSIDE THE PRODUCT, AS IT MAY
CAUSE ELECTRIC SHOCK TO PEOPLE.
INSTALL THE PRODUCT OUTSIDE DRY AND HEATED ROOMS.
PREVENT OR ACCELERATE THE MOVEMENT OF THE PRODUCT
LEAF DURING SWITCHING ON (OFF) ANTI-PANIC MODE - AP.
APPLY FOR THE PRODUCT CLEANING PASTES AND LIQUIDS
CHEMICALLY AGGRESSIVE TO MATERIALS OF HOUSING.
2.2 The product preparation for installation
2.2.1 Safety measures at the product preparation for installation
ATTENTION: TO AVOID INJURY AND THE PRODUCT LOCKING,
BEFORE CONNECTING THE PRODUCT MAKE AREA FOR THE LEAF
ROTATION FREE FROM PEOPLE AND FOREIGN THINGS.
2.2.2 Rules and procedure for the product visual inspection
Visual inspection of the product before power supply switching on is
obligatory and should include the following:
1) checking absence of mechanical damages of the product housing: cracks, through
apertures of dropped fastener;
2) careful visual inspection of all product connections.
