Rammer

BS 65-V

OPERATOR’S MANUAL

0176651en 001

0808

0176651EN

BS 65V Table of Contents

wc_bo0176651en_001TOC.fm 3

1. Foreword 5

2. Emission Control System Information 7

3. Safety Information 13

3.1 Laws Pertaining to Spark Arresters .................................................... 13

3.2 Operating Safety ................................................................................ 14

3.3 Operator Safety while using Internal Combustion Engines ................ 16

3.4 Service Safety .................................................................................... 17

3.5 Label Locations .................................................................................. 18

3.6 Safety and Operating Labels .............................................................. 19

4. Operation 24

4.1 Application .......................................................................................... 24

4.2 Recommended Fuel ........................................................................... 24

4.3 Before Starting ................................................................................... 24

4.4 To Start ............................................................................................... 25

4.5 To Stop ............................................................................................... 26

4.6 Proper Operation ................................................................................ 26

4.7 Proper Compaction ............................................................................ 27

4.8 Selecting Ramming Stroke ................................................................. 28

4.9 Adjusting Ramming Stroke ................................................................. 30

5. Maintenance 32

5.1 Periodic Maintenance Schedule ......................................................... 32

5.2 Air Cleaner ......................................................................................... 33

5.3 Lubrication .......................................................................................... 34

5.4 Fuel Lines ........................................................................................... 36

5.5 Shoe Hardware .................................................................................. 37

5.6 Carburetor Adjustments ..................................................................... 38

5.7 Long-Term Storage ............................................................................ 38

5.8 Transportation .................................................................................... 39

5.9 Troubleshooting .................................................................................. 40

Table of Contents BS 65V

wc_bo0176651en_001TOC.fm 4

6. Technical Data 41

6.1 Rammer ...............................................................................................41

6.2 Sound Measurements .........................................................................42

6.3 Vibration Measurements .....................................................................42

6.4 Dimensions ..........................................................................................42

Foreword

wc_tx000913gb.fm 5

1 Foreword

Machines covered in this manual

This manual provides information and procedures to safely operate

and maintain this Wacker Neuson model. For your own safety and

protection from injury, carefully read, understand and observe the

safety instructions described in this manual.

Keep this manual or a copy of it with the machine. If you lose this

manual or need an additional copy, please contact Wacker Neuson

Corporation. This machine is built with user safety in mind; however,

it can present hazards if improperly operated and serviced. Follow

operating instructions carefully! If you have questions about operating

or servicing this equipment, please contact Wacker Neuson

Corporation.

The information contained in this manual was based on machines in

production at the time of publication. Wacker Neuson Corporation

reserves the right to change any portion of this information without

notice.

All rights, especially copying and distribution rights, are reserved.

No part of this publication may be reproduced in any form or by any

means, electronic or mechanical, including photocopying, without

express written permission from Wacker Neuson Corporation.

Any type of reproduction or distribution not authorized by Wacker

Neuson Corporation represents an infringement of valid copyrights

and will be prosecuted. We expressly reserve the right to make

technical modifications, even without due notice, which aim at

improving our machines or their safety standards.

Machine Item Number

BS 65-V 0009423 Rev 123

0009423 Rev 200 and higher

Foreword

wc_tx000913gb.fm 6

CALIFORNIA

Proposition 65 Warning:

Engine exhaust, some of its constituents, and certain vehicle

components, contain or emit chemicals known to the State of

California to cause cancer and birth defects or other reproductive

harm.

WARNING

Emission Control System Information

wc_tx000928gb.fm 7

2. Emission Control System Information

Source of Emissions

The combustion process produces carbon monoxide, oxides of

nitrogen, and hydrocarbons. Control of hydrocarbons and oxides of

nitrogen is very important because, under certain conditions, they

react to form photochemical smog when subjected to sunlight. Carbon

monoxide does not react in the same way, but it is toxic.

Wacker Neuson utilizes lean carburetor settings and other systems to

reduce the emissions of carbon monoxide, oxides of nitrogen, and

hydrocarbons.

The U.S. and California Clean Air Acts

EPA and California regulations require all manufacturers to furnish

written instructions describing the operation and maintenance of

emission control systems.

The following instructions and procedures must be followed in order to

keep the emissions from your Wacker Neuson engine within the

emissions standards.

Tampering and Altering

Tampering with or altering the emission control system may increase

emissions beyond the legal limit. Among those acts that constitute

tampering are:

•Removal or alteration of any part of the intake, fuel, or exhaust

systems.

•Altering or defeating the speed-adjusting mechanism to cause the

engine to operate outside its design parameters.

Problems That May Affect Emissions

If you are aware of any of the following symptoms, have your engine

inspected and repaired by your servicing dealer.

•Hard starting or stalling after starting.

•Rough idle.

•Misfiring or backfiring under load.

•Afterburning (backfiring).

•Black exhaust smoke or high fuel consumption.

Emission Control System Information

wc_tx000928gb.fm 8

Replacement Parts

The emission control systems on your Wacker Neuson engine were

designed, built, and certified to conform with EPA and California

emissions regulations. We recommend the use of genuine Wacker

Neuson parts whenever you have maintenance done. These original-

design replacement parts are manufactured to the same standards as

the original parts, so you can be confident of their performance. The

use of replacement parts that are not of the original design and quality

may impair the effectiveness of your emission control system.

A manufacturer of an aftermarket part assumes the responsibility that

the part will not adversely affect emission performance. The

manufacturer or rebuilder of the part must certify that use of the part

will not result in a failure of the engine to comply with emission

regulations.

Maintenance

Follow the maintenance schedule. Remember that this schedule is

based on the assumption that your machine will be used for its

designed purpose. Sustained high-load or high-temperature operation,

or use in unusually wet or dusty conditions, will require more frequent

service.

OXYGENATED FUELS

Some conventional gasolines are being blended with alcohol or an

ether compound. These gasolines are collectively referred to as

oxygenated fuels. To meet clean air standards, some areas of the

United States and Canada use oxygenated fuels to help reduce

emissions.

If you use an oxygenated fuel, be sure it is unleaded and meets the

minimum octane rating requirement.

Before using an oxygenated fuel, try to confirm the fuel’s contents.

Some States / Provinces require this information to be posted on the

pump.

The following are EPA-approved percentages of oxygenates:

ETHANOL - (ethyl or grain alcohol) 10% by volume. You may use

gasoline containing up to 10% ethanol by volume. Gasoline containing

ethanol may be marketed under the name “Gasohol”. E85 fuel should

never be used, as it is an alternative fuel containing 85% ethanol, 15%

gasoline.

MTBE - (methyl tertiary butyl ether) 15% by volume. You may use

gasoline containing up to 15% MTBE by volume.

Emission Control System Information

wc_tx000928gb.fm 9

METHANOL - (methyl or wood alcohol) 5% by volume. You may use

gasoline containing up to 5% methanol by volume, as long as it

contains cosolvents and corrosion inhibitors to protect the fuel system.

Gasoline containing more than 5% methanol by volume may cause

starting and/or performance problems. It may also damage metal,

rubber, and plastic parts of your fuel system.

If you notice any undesirable operating symptoms, try another service

station, or switch to another brand of gasoline.

Fuel system damage or performance problems resulting from the use

of an oxygenated fuel containing more than the percentages of

oxygenates mentioned above are not covered under warranty.

Emission Control System Warranty

Your new Wacker Neuson engine complies with the U.S. EPA

emissions regulations. Wacker Neuson provides the same emission

warranty coverage for engines sold in all 50 states.

YOUR WARRANTY RIGHTS AND OBLIGATIONS

All States

Wacker Neuson must warrant the emission control system on your

engine for the period of time listed below provided there has been no

abuse, neglect or improper maintenance of your engine. Where a

warrantable condition exists, Wacker Neuson will repair your engine

at no cost to you including diagnosis, parts and labor.

Your emission control system may include such parts as the

carburetor, the ignition system and the catalytic converter.

Also included may be hoses, connectors and other emission-related

assemblies.

MANUFACTURER’S WARRANTY COVERAGE:

The 1998 and later engines are warranted for two years. If any

emission-related part on your engine is defective, the part will be

repaired or replaced by Wacker Neuson.

Emission Control System Information

wc_tx000928gb.fm 10

OWNER’S WARRANTY RESPONSIBILITY:

As the engine owner, you are responsible for the performance of the

required maintenance listed in your owner’s manual. Wacker Neuson

recommends that you retain all receipts covering maintenance on your

engine, but Wacker Neuson cannot deny warranty coverage solely for

the lack of receipts or for your failure to ensure the performance of all

scheduled maintenance.

As the engine owner, you should be aware that Wacker Neuson may

deny you warranty coverage if your engine or a part has failed due to

abuse, neglect, improper maintenance or unapproved modifications.

You are responsible for presenting your engine to a Wacker Neuson

dealer as soon as a problem exists. The warranty repairs should be

completed in a reasonable amount of time, not to exceed 30 days.

If you have any questions regarding your warranty rights and

responsibilities, you should contact your local Wacker Neuson dealer.

WARRANTY COVERAGE:

Wacker Neuson engines sold after January 1, 1998, are covered by

this Emission Control System Warranty for a period of two years from

the date of delivery to the original retail purchaser. This warranty is

transferable to each subsequent purchaser for the duration of the

warranty period.

Warranty repairs will be made without charge for diagnosis, parts or

labor. All defective parts replaced under this warranty become property

of Wacker Neuson. A list of warranted parts is located on the next

page. Normal maintenance items, such as spark plugs and filters, that

are on the warranted parts list are warranted up to the required

replacement interval only.

Wacker Neuson is also liable for damages to other engine

components caused by a failure of any warranted parts during the

warranty period.

Only Wacker Neuson approved replacement parts may be used in the

performance of any warranty repairs and must be provided without

charge to the owner. The use of replacement parts not equivalent to

the original parts may impair the effectiveness of your engine emission

control system. If such a replacement part is used in the repair or

maintenance of your engine, and an authorized Wacker Neuson dealer

determines it is defective or causes a failure of a warranted part, your

claim for repair of your engine may be denied. If the part in question is

not related to the reason your engine requires repair, your claim will not

be denied.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Herramientas eléctricas de Wacker Neuson

Wacker Neuson

Wacker Neuson VP1030A-CE Manual de usuario

Wacker Neuson

Wacker Neuson BS 50-2 Manual de usuario

Wacker Neuson

Wacker Neuson BPU 3545A Manual de usuario

Wacker Neuson

Wacker Neuson WP Series Manual de usuario

Wacker Neuson

Wacker Neuson VP 1135A Manual de usuario

Wacker Neuson

Wacker Neuson BPU 2440 series Instrucciones de funcionamiento

Wacker Neuson

Wacker Neuson BPU 4045 Manual de usuario

Wacker Neuson

Wacker Neuson WP 1030A Manual de usuario

Wacker Neuson

Wacker Neuson DPS 1850 Manual de usuario

Wacker Neuson

Wacker Neuson ARFU 36/6/120 Manual de usuario

Wacker Neuson

Wacker Neuson BS 50 Instrucciones de funcionamiento

Wacker Neuson

Wacker Neuson BS 50-4 Manual de usuario

Wacker Neuson

Wacker Neuson DPU Series Manual de usuario

Wacker Neuson

Wacker Neuson BV50A-H Manual de usuario

Wacker Neuson

Wacker Neuson BS 60-2i Manual de usuario

Wacker Neuson

Wacker Neuson WP 1540A Manual de usuario

Wacker Neuson

Wacker Neuson DPU 5045H Manual de usuario

Wacker Neuson

Wacker Neuson BPS1030 Manual de usuario

Wacker Neuson

Wacker Neuson BPU 2950A Manual de usuario

Wacker Neuson

Wacker Neuson BS 600 Manual de usuario

Wacker Neuson

Wacker Neuson DPU 4545 Manual de usuario

Wacker Neuson

Wacker Neuson EH 6 Manual de usuario

Wacker Neuson

Wacker Neuson EH 27/115 Manual de usuario

Wacker Neuson

Wacker Neuson VP 2050 Manual de usuario

Manuales populares de Herramientas eléctricas de otras marcas

AEG

AEG OMNI-JS Manual de usuario

SIP

SIP 01533 Manual de usuario

Ribimex

Ribimex PRS499 Manual de usuario

3M Fiber Optic Connector Crimp Tool Manual de usuario

Ryobi

Ryobi P524 Manual de usuario

ROJEK

ROJEK FSN 300A Manual de usuario

Kemper

Kemper 1740PRO Manual de usuario

WABCO

WABCO OptiTire Manual de usuario

EINHELL

EINHELL TE-MS 18/210 Li Manual de usuario

Orgapack

Orgapack OR-T 85 Guía rápida

TOUGHCUT

TOUGHCUT Diamond 400 Manual de usuario

Yaros

Yaros PB-3603 Manual de usuario

Fein

Fein BSS 2.0 E Guía de configuración

Baileigh Industrial

Baileigh Industrial SS-2725 Manual de usuario

Milwaukee

Milwaukee 2674-20 Manual de usuario

Fein

Fein BLs 1.6 Manual de usuario

Princess

Princess Electric Multi Sharpener Manual de usuario

FOREDOM

FOREDOM K.1050 Manual
