Wacker Neuson WP1540Aw US Manual de usuario

www.wackergroup.com

Vibroplate

WP 1540A

WP 1540AW

OPERATOR’S MANUAL

0154581en 009

0606

0154581EN

WP 1540A/AW Table of Contents

wc_bo0154581en_009TOC.fm 1

1. Foreword 3

2. Safety Information 4

2.1 Laws Pertaining to Spark Arresters ...................................................... 5

2.2 Operating Safety .................................................................................. 6

2.3 Operator Safety while using Internal Combustion Engines .................. 7

2.4 Service Safety ...................................................................................... 8

2.5 Label Locations .................................................................................... 9

2.6 Warning and Informational Labels ...................................................... 10

2.7 Operating Labels ................................................................................ 12

3. Technical Data 14

3.1 Engine Data ........................................................................................ 14

3.2 Machine Data ..................................................................................... 15

3.3 Sound and Vibration Specifications .................................................... 15

3.4 Dimensions ......................................................................................... 16

4. Operation 17

4.1 Recommended Fuel ........................................................................... 17

4.2 Before Starting ................................................................................... 17

4.3 To Start ............................................................................................... 18

4.4 To Stop ............................................................................................... 18

4.5 Application .......................................................................................... 19

4.6 Operation ............................................................................................ 20

4.7 Wheel Kit (0162986) ........................................................................... 21

4.8 Wheel Kit (0114334) ........................................................................... 22

Table of Contents WP 1540A/AW

wc_bo0154581en_009TOC.fm 2

5. Maintenance 23

5.1 Periodic Maintenance Schedule ..........................................................23

5.2 Cleaning Plate .....................................................................................23

5.3 Drive Belt .............................................................................................24

5.4 Exciter Lubrication ...............................................................................25

5.5 Spark Plug ...........................................................................................26

5.6 Engine Oil ............................................................................................27

5.7 Air Cleaner ..........................................................................................28

5.8 Cleaning Sediment Cup ......................................................................29

5.9 Adjusting Engine Speed ......................................................................29

5.10 Carburetor Adjustment ........................................................................30

5.11 Troubleshooting ...................................................................................31

5.12 Storage ................................................................................................32

5.13 Lifting Machine ....................................................................................33

5.14 Transporting Machine ..........................................................................34

CALIFORNIA

Proposition 65 Warning:

Engine exhaust, some of its constituents, and certain vehicle

components, contain or emit chemicals known to the State of

California to cause cancer and birth defects or other reproductive

harm.

1. Foreword

This manual provides information and procedures to safely operate

and maintain this Wacker model. For your own safety and protection

from injury, carefully read, understand and observe the safety

instructions described in this manual.

Keep this manual or a copy of it with the machine. If you lose this

manual or need an additional copy, please contact Wacker

Corporation. This machine is built with user safety in mind; however,

it can present hazards if improperly operated and serviced. Follow

operating instructions carefully! If you have questions about operating

or servicing this equipment, please contact Wacker Corporation.

The information contained in this manual was based on machines in

production at the time of publication. Wacker Corporation reserves the

right to change any portion of this information without notice.

All rights, especially copying and distribution rights, are reserved.

No part of this publication may be reproduced in any form or by any

means, electronic or mechanical, including photocopying, without

express written permission from Wacker Corporation.

Any type of reproduction or distribution not authorized by Wacker

Corporation represents an infringement of valid copyrights and will be

prosecuted. We expressly reserve the right to make technical

modifications, even without due notice, which aim at improving our

machines or their safety standards.

WARNING

Safety Information WP 1540A/AW

wc_si000017gb.fm 4

2. Safety Information

This manual contains DANGER, WARNING, CAUTION, NOTICE=and

NOTE callouts which must be followed to reduce the possibility of

personal injury, damage to the equipment, or improper service.

This is the safety alert symbol. It is used to alert you to potential

personal injury hazards. Obey all safety messages that follow this

symbol to avoid possible injury or death.

DANGER indicates a hazardous situation which, if not avoided, will

result in death or serious injury.

WARNING indicates a hazardous situation which, if not avoided, could

result in death or serious injury.

CAUTION indicates a hazardous situation which, if not avoided, could

result in minor or moderate injury.

NOTICE: Used without the safety alert symbol, NOTICE indicates a

hazardous situation which, if not avoided, could result in property

damage

Note: Contains additional information important to a procedure.

DANGER

WARNING

CAUTION

WP 1540A/AW Safety Information

wc_si000017gb.fm 5

2.1 Laws Pertaining to Spark Arresters

Notice: State Health Safety Codes and Public Resources Codes

specify that in certain locations spark arresters be used on internal

combustion engines that use hydrocarbon fuels. A spark arrester is a

device designed to prevent accidental discharge of sparks or flames

from the engine exhaust. Spark arresters are qualified and rated by

the United States Forest Service for this purpose.

In order to comply with local laws regarding spark arresters, consult

the engine distributor or the local Health and Safety Administrator.

Safety Information WP 1540A/AW

wc_si000017gb.fm 6

2.2 Operating Safety

Familiarity and proper training are required for the safe operation of

machine. Machines operated improperly or by untrained personnel

can be dangerous. Read the operating instructions contained in both

this manual and the engine manual and familiarize yourself with the

location and proper use of all controls. Inexperienced operators should

receive instruction from someone familiar with the machine before

being allowed to operate it.

2.2.1 NEVER allow anyone to operate this equipment without proper

training. People operating this equipment must be familiar with the

risks and hazards associated with it.

2.2.2 NEVER touch the engine or muffler while the engine is on or

immediately after it has been turned off. These areas get hot and may

cause burns.

2.2.3 NEVER use accessories or attachments that are not recommended by

Wacker. Damage to equipment and injury to the user may result.

2.2.4 NEVER operate the machine with the beltguard missing. Exposed

drive belt and pulleys create potentially dangerous hazards that can

cause serious injuries.

2.2.5 NEVER leave machine running unattended.

2.2.6 ALWAYS be sure operator is familiar with proper safety precautions

and operation techniques before using machine.

2.2.7 ALWAYS wear protective clothing appropriate to the job site when

operating equipment.

2.2.8 ALWAYS wear hearing protection when operating equipment.

2.2.9 ALWAYS close fuel valve on engines equipped with one when

machine is not being operated.

2.2.10 ALWAYS store the equipment properly when it is not being used.

Equipment should be stored in a clean, dry location out of the reach of

children.

2.2.11 ALWAYS operate machine with all safety devices and guards in place

and in working order. DO NOT modify or defeat safety devices. DO

NOT operate machine if any safety devices or guards are missing or

inoperative.

2.2.12 ALWAYS read, understand, and follow procedures in the Operator’s

Manual before attempting to operate the equipment.

WARNING

WP 1540A/AW Safety Information

wc_si000017gb.fm 7

2.3 Operator Safety while using Internal Combustion Engines

Internal combustion engines present special hazards during operation

and fueling. Read and follow the warning instructions in the engine

owner’s manual and the safety guidelines below. Failure to follow the

warnings and safety guidelines could result in severe injury or death.

2.3.1 DO NOT run the machine indoors or in an enclosed area such as a

deep trench unless adequate ventilation, through such items as

exhaust fans or hoses, is provided. Exhaust gas from the engine

contains poisonous carbon monoxide gas; exposure to carbon

monoxide can cause loss of consciousness and may lead to death.

2.3.2 DO NOT smoke while operating the machine.

2.3.3 DO NOT smoke when refueling the engine.

2.3.4 DO NOT refuel a hot or running engine.

2.3.5 DO NOT refuel the engine near an open flame.

2.3.6 DO NOT spill fuel when refueling the engine.

2.3.7 DO NOT run the engine near open flames.

2.3.8 ALWAYS refill the fuel tank in a well-ventilated area.

2.3.9 ALWAYS replace the fuel tank cap after refueling.

2.3.10 ALWAYS check the fuel lines and the fuel tank for leaks and cracks

before starting the engine. Do not run the machine if fuel leaks are

present or the fuel lines are loose.

DANGER

Safety Information WP 1540A/AW

wc_si000017gb.fm 8

2.4 Service Safety

Poorly maintained machines can become a safety hazard! In order for

the machine to operate safely and properly over a long period of time,

periodic maintenance and occasional repairs are necessary.

2.4.1 DO NOT attempt to clean or service the machine while it is running.

Rotating parts can cause severe injury.

2.4.2 DO NOT crank a flooded engine with the spark plug removed on

gasoline-powered engines. Fuel trapped in the cylinder will squirt out

the spark plug opening.

2.4.3 DO NOT test for spark on gasoline-powered engines if the engine is

flooded or the smell of gasoline is present. A stray spark could ignite

the fumes.

2.4.4 DO NOT use gasoline or other types of fuels or flammable solvents to

clean parts, especially in enclosed areas. Fumes from fuels and

solvents can become explosive.

2.4.5 ALWAYS keep the area around the muffler free of debris such as

leaves, paper, cartons, etc. A hot muffler could ignite the debris and

start a fire.

2.4.6 ALWAYS replace worn or damaged components with spare parts

designed and recommended by Wacker Corporation.

2.4.7 ALWAYS disconnect the spark plug on machines equipped with

gasoline engines, before servicing, to avoid accidental start-up.

2.4.8 ALWAYS keep the machine clean and labels legible. Replace all

missing and hard-to-read labels. Labels provide important operating

instructions and warn of dangers and hazards.

WARNING

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Herramientas eléctricas de Wacker Neuson

Wacker Neuson

Wacker Neuson WP1550A US Manual de usuario

Wacker Neuson

Wacker Neuson DPU 6555 Manual de usuario

Wacker Neuson

Wacker Neuson VP2050A US Manual de usuario

Wacker Neuson

Wacker Neuson BV50A-H Manual de usuario

Wacker Neuson

Wacker Neuson PV 35A Manual de usuario

Wacker Neuson

Wacker Neuson BPU 2540A Manual de usuario

Wacker Neuson

Wacker Neuson EH 25 Manual de usuario

Wacker Neuson

Wacker Neuson IEC Manual de usuario

Wacker Neuson

Wacker Neuson EH 6 Manual de usuario

Wacker Neuson

Wacker Neuson DPU 4545 Manual de usuario

Wacker Neuson

Wacker Neuson BPU 2440 series Instrucciones de funcionamiento

Wacker Neuson

Wacker Neuson BS 60-4s Manual de usuario

Wacker Neuson

Wacker Neuson BS 50 Instrucciones de funcionamiento

Wacker Neuson

Wacker Neuson DPU 4045 Manual de usuario

Wacker Neuson

Wacker Neuson BS 60-4s Manual de usuario

Wacker Neuson

Wacker Neuson bs65y Manual de usuario

Wacker Neuson

Wacker Neuson BS 60-2i Manual de usuario

Wacker Neuson

Wacker Neuson DPS 1850 Manual de usuario

Wacker Neuson

Wacker Neuson BS 50 Instrucciones de funcionamiento

Wacker Neuson

Wacker Neuson DPU 5045H Manual de usuario

Wacker Neuson

Wacker Neuson BPU 3545A Manual de usuario

Wacker Neuson

Wacker Neuson DPU80 Series Manual de usuario

Wacker Neuson

Wacker Neuson DPU 25 Series Manual de usuario

Wacker Neuson

Wacker Neuson DPU 3050H Manual de usuario

Manuales populares de Herramientas eléctricas de otras marcas

AEG

AEG OMNI-JS Manual de usuario

SIP

SIP 01533 Manual de usuario

Ribimex

Ribimex PRS499 Manual de usuario

3M Fiber Optic Connector Crimp Tool Manual de usuario

Ryobi

Ryobi P524 Manual de usuario

ROJEK

ROJEK FSN 300A Manual de usuario

Kemper

Kemper 1740PRO Manual de usuario

WABCO

WABCO OptiTire Manual de usuario

EINHELL

EINHELL TE-MS 18/210 Li Manual de usuario

Orgapack

Orgapack OR-T 85 Guía rápida

TOUGHCUT

TOUGHCUT Diamond 400 Manual de usuario

Yaros

Yaros PB-3603 Manual de usuario

Fein

Fein BSS 2.0 E Guía de configuración

Baileigh Industrial

Baileigh Industrial SS-2725 Manual de usuario

Milwaukee

Milwaukee 2674-20 Manual de usuario

Fein

Fein BLs 1.6 Manual de usuario

Princess

Princess Electric Multi Sharpener Manual de usuario

FOREDOM

FOREDOM K.1050 Manual
