VOLTAWAY POCKETROCKET 26 Manual de usuario
USER MANUAL
ELECTRIC
SKATEBOARD
USER GUIDE
INTRODUCTION
Thank you for purchasing this board. It is a portable, fun and
eco-friendly transport unit. The lightweight design and compact
dimensions make it a perfect city vehicle. It allows you to travel up to
20km, with an exciting 25km/h top speed. Equipped with an
advanced braking system and three speed levels, it is safe for users
and other pedestrians alike.
Enjoy your ride !
RISK OF DEATH OR SERIOUS INJURY
Whenever you ride a board, you risk death or serious injury from an
accident. Please carefully read the following warnings in this manual.
Always wear a helmet when riding. Avoid water, wet and slippe-
ry/uneven surfaces, steep hills, trac, cracks, tracks, gravel, rocks, or
any obstacles that could cause a loss of traction and cause a fall.
Avoid riding at night, areas with limited visibility, and confirned
spaces.
WARNING:Do not ride the board in anywhere, or at speeds where
you would not be safely in control of an unpowered longboard. In the
event of wireless interference or battery fault, you may need to rely
on skating techniques like foot braking or sliding to stop.
WARNING:AVOID WATER !
Your board is not waterproof.
Electronics, bearings, and other components can be damaged.
Water damage is not covered under the warranty.
WARNING:pinch point. Keep your fingers, hair, and clothing
away from belts, motors, wheels and all moving parts.
WARNING:RISK OF ELECTRONIC SHOCK !
Do not open or tamper the electronic housing, which also voids
the warranty.
WARNING
PROTECTIVE EQUIPMENT
ALWAYS WEAR A HELMET
Find an open, flat area with smooth, clean pavement for your
first ride! Read the warnings on the skateboard and in the
beginning of manual.
OTHER PROTECTIVE EQUIPMENT IS HIGHLY RECOMMENDED.
STANCE
Follow these tips to ensure a safe riding experience :
- Move the throttle wheel slowly in small increments.
- Keep a wide stance on the board.
- Keep a low center of gravity.
- Lean forward when accelerating.
- Lean backward when braking.
FEATURES
Three speed mode:
Speed mode 3 - speed of 20km/h or 25km/h (Top Speed)
Speed mode 2 - speed of 15km/h
Speed mode 1 - speed of 6km/h
20% degrees uphill capability:
Actual performance depends on rider’s weight
and road condition.
DO NOT RIDE AT LOW SPEED WHEN UPHILL.
Quick charge:
Board charging time 3-5 hours (depending on models).
Remote charging time 50mins :
Light weight construction:
POCKET ROCKET 26’’ : net weight 4kg
GOOBER 28’’ : net weight 4.8kg
SLAB 34’’ : net weight 6kg
MACK 39’’ : net weight 7.5kg
POCKETROCKET|26
ELECTRIC POWERED SKATEBOARD
• SINGLE IN-WHEEL MOTOR : 200W
• TORQUE : 2.2Nm
• BATTERY : LITHIUM-ION 2.2Ah, 24v
• BATTERY LIFE : 15Km
• CHARGER : 110v/240v - 1,6A
• CHARGING TIME : 3H
• SPEED : 6-15-20Km/H
LIGHTWEIGHT
ONLY 4.0 Kg
LITHIUM-ION
2.2Ah, 24V
3 SPEED MODE
MAX 20 Km/H
WIRELESS
REMOTE
X1
BRUSHLESS
MOTOR
• MAX. LOAD : 70Kg
• WEIGHT : 4,0Kg
• DECK : MOLDED POLYPROPYLENE
• TRUCKS : 5’’ CLASSIC
• WHEELS : 72 x 51mm SHR
• DUROMETER : 78A
• BEARINGS : ABEC 7 / 2RS
TRUCK
CHARGING PORT
POWER BUTTON
PAIRING BUTTON
PAIRING
HOLD 6 SECONDS
BLUE LIGHT TURNS OFF
THEN LIGHTS AGAIN
WHEELS
MOLDED DECK
- BATTERY
- CONTROLER
IN-WHEEL MOTOR (x1)
KICKTAIL
• DOUBLE IN-WHEEL MOTOR : 200W
• TORQUE : 2.2Nm
• BATTERY : LITHIUM-ION 2.2Ah, 24v
• BATTERY LIFE : 15Km
• CHARGER : 110v/240v - 1,6A
• CHARGING TIME : 3-4H
• SPEED : 6-15-25Km/H
LIGHTWEIGHT
ONLY 4.8 Kg
LITHIUM-ION
2.2Ah, 24V
3 SPEED MODE
MAX 25 Km/H
WIRELESS
REMOTE
X2
BRUSHLESS
MOTOR
• MAX. LOAD : 100Kg
• WEIGHT : 4.8Kg
• DECK : 7 PLY CANADIAN MAPLE
• TRUCKS : 5’’ IKP
• WHEELS : 72 x 51mm SHR
• DUROMETER : 78A
• BEARINGS : ABEC 7 / 2RS
GOOBER28
DUAL ELECTRIC POWERED SKATEBOARD
COVER
- BATTERY
- CONTROLER
TRUCK
CHARGING PORT
POWER BUTTON
PAIRING BUTTON
PAIRING
HOLD 6 SECONDS
BLUE LIGHT TURNS OFF
THEN LIGHTS AGAIN
WHEELS
DECK
IN-WHEEL MOTOR (x2)
KICKTAIL
HANDLE
• DOUBLE IN-WHEEL MOTOR : 400W
• TORQUE : 3.5Nm
• BATTERY : LITHIUM-ION 4.4Ah, 36v
• BATTERY LIFE : 20Km
• CHARGER : 110v/240v - 1,6A
• CHARGING TIME : 4-5H
• SPEED : 6-15-25Km/H
LIGHTWEIGHT
ONLY 6.0 Kg
LITHIUM-ION
4.4Ah, 36V
3 SPEED MODE
MAX 25 Km/H
WIRELESS
REMOTE
X2
BRUSHLESS
MOTOR
• MAX. LOAD : 100Kg
• WEIGHT : 6.0Kg
• DECK : 7 PLY CANADIAN MAPLE
• TRUCKS : 7’’ IKP
• WHEELS : 80 x 52mm SHR
• DUROMETER : 78A
• BEARINGS : ABEC 7 / 2RS
SLAB34
DUAL ELECTRIC POWERED SKATEBOARD
COVER
- BATTERY
- CONTROLER
TRUCK
CHARGING PORT
POWER BUTTON
PAIRING BUTTON
PAIRING
HOLD 6 SECONDS
BLUE LIGHT TURNS OFF
THEN LIGHTS AGAIN
WHEELS
DECK
IN-WHEEL MOTOR (x2)
KICKTAIL
• DOUBLE IN-WHEEL MOTOR : 400W
• TORQUE : 3.5Nm
• BATTERY : LITHIUM-ION 4.4Ah, 36v
• BATTERY LIFE : 20Km
• CHARGER : 110v/240v - 1,6A
• CHARGING TIME : 4-5H
• SPEED : 6-15-25Km/H
• MAX. LOAD : 100Kg
• WEIGHT : 7.5Kg
• DECK : 7 PLY CANADIAN MAPLE
• TRUCKS : 7’’ IKP
• WHEELS : 80 x 52mm SHR
• DUROMETER : 78A
• BEARINGS : ABEC 7 / 2RS
LIGHTWEIGHT
ONLY 7.5 Kg
LITHIUM-ION
4.4Ah, 36V
3 SPEED MODE
MAX 25 Km/H
WIRELESS
REMOTE
X2
BRUSHLESS
MOTOR
MACK39
DUAL ELECTRIC POWERED SKATEBOARD
COVER
- BATTERY
- CONTROLER
TRUCK
CHARGING PORT
POWER BUTTON
PAIRING BUTTON
PAIRING
HOLD 6 SECONDS
BLUE LIGHT TURNS OFF
THEN LIGHTS AGAIN
WHEELS
DECK
IN-WHEEL MOTOR (x2)
SPEED
CONTROL
SCROLL
WHEEL
REVERSE
BUTTON
POWER
BUTTON
SPEED
MODE
SWITCH
CHARGING
PORT
SIGNAL
INDICATOR
SKATEBOARD
BATTERY
INDICATOR
REMOTE
BATTERY
INDICATOR
PAIRING
BUTTON
FIRST TIME USE
PAIRING THE REMOTE WITH THE SKATEBOARD
STEP 1 (SKATEBOARD)
•Switch on the skateboard by
pressing the power button.
Skateboard’s indicator lights up.
•Hold the skateboard’s pairing
button until the indicator flashes.
(May take up to 6 seconds)
STEP 2 (REMOTE CONTROL)
•Switch on the remote, the red
indicator lights up
•Press the pairing button
(lower left corner of remote).
When green indicator flashes,
pairing is successfull.
Don’t forget
to charge
your remote
regularly.
Micro-USB
cable included.
A
A
REMOTE CONTROL FUNCTIONS
SPEED CONTROL WHEEL
SKATEBOARD
BATTERY INDICATOR
ACCELERATE
SCROLL UP
100% 50% 10%
BRAKE
SCROLL DOWN
SPEED MODE SWITCH
SIGNAL INDICATOR
Turns Green when Remote
Control is Connected to
the Skateboard
REVERSE BUTTON
Press Button to Select
Forward or Reverse Gear
POWER BUTTON
Press Button to
Switch on and Switch o
REMOTE CONTROL
BATTERY INDICATOR
Lights up when Fully Charged
Flashes when Battery is Low
HIGH
20-25 km/h max
(depending on models)
MIDDLE
15 km/h max
LOW
6 km/h max
SKATEBOARD
CHARGING
PORT
IN-WHEEL BRUSHLESS MOTEUR
CHARGING INSTRUCTIONS
A) Take out the adapter and
the mains cable from the box,
make sure they’re dry and
clean. Combine the 2 parts.
B) Plug the charging cable
into to charging port of the
skateboard, then plug the
charger into the mains.
C) Continue charging until the
power indicator turns green.
INDICATOR
LIGHT
ADAPTER
MAINS
CABLE
CHARGING
PLUG
3H -> 5H
(depending on models)
