Vivotek SD8161 Manual de usuario

Quick Installation Guide

VIVOTEK INC.

6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.

|T:+886-2-82455282|F:+886-2-82455532|E:[email protected]

VIVOTEK USA, INC.

2050 Ringwood Avenue, San Jose, CA 95131

|T: 408-773-8686|F: 408-773-8298|E: [email protected]

1080P HD • 18x Zoom • PoE

All specications are subject to change without notice.

P/N:625028100G Rev.: 1.0

SD8161 Speed Dome

Network Camera

English

VIVOTEK Netherlands B.V.

Busplein 36, 1315KV, Almere, The Netherlands

|T:+31 (0)36 5389 149|F:+31 (0)36 5389 111|E:[email protected]

EN-1

English

Warning Before Installation

Refer to your user’s manual for the

operating temperature.

Power off the Network Camera as soon as

smoke or unusual odors are detected.

Do not touch the Network Camera during

a lightning storm.

Do not disassemble the Network Camera.

Do not drop the Network Camera.

Do not insert sharp or tiny objects into the

Network Camera.

Do not manually pan and tilt the Network

Camera when the power is on.

Package Contents

Software CD

SD8161

Cable hole

Cable track

Front

Quick Installation Guide

PC/ABS / Smoked Dome Cover (Sold

separately)

Screws / Alignment Sticker / T25

Stardriver

EN-2

Lens

Outer View

Physical Description

Status LED

Network LED

Reset Button

This drawing shows a camera with its dome

cover removed.

icro

The MicroSD card slot is accessed by removing

the dome cover using the T25 stardriver.

EN-3

English

The camera weighs 2.2kg. Select a rigid mounting location to prevent vibration to the

camera.

1. Turn and detach the top section.

2. Attach the alignment sticker to the wall. Drill 3 pilot holes into the wall, and drill

another hole for routing cables.

1. IO wires are user-supplied.

2. Avoid touching the circuit boards to prevent damage by electro static discharge.

3. Use CAT5e and CAT6 cables only.

NOTE:

Hardware Installation

EN-4

4. Hammer in the threaded anchors.

5. Secure the top section to ceiling using the included screws.

6. Pass cables through the pre-drilled hole or the side openings, and then connect to the

camera.

The product is not likely to require connection to an Ethernet network with outside plant

routing, including the campus environments; and the ITE is to be connected only to PoE

networks without routing to the outside plant.

IMPORTANT:

EN-5

English

Mounting the Camera

Alignment Mark

7. Align the camera body with the top section. Align the alignment mark on the camera

with that on the top section. Push the camera up to match the top section.

8. Rotate the camera clockwise.

9. Use the included T25 stardriver to tighten the anti-tamper screw on the side to secure

the connection. Make sure all parts have been securely tightened.

EN-6

Network Deployment

1. Connect the Network Camera's Ethernet cable (CAT5e/CAT6) to a PoE Plus switch.

When using a non-PoE switch

Use a PoE Plus power injector (separately purchased) capable of 30W output to connect

between the Network Camera and a non-PoE switch.

Non-PoE Switch

PoE Plus PoE Power

Injector

2. Connect the power wires to an AC 24V power adaptor (user-supplied).

You can connect both power sources for redundancy in power supply.

Power over Ethernet (High Power PoE)

General Connection

AC 24V 3.5A Adapter

(User-supplied)

IEEE 802.3at PoE Switch (30W output)

and / or

EN-7

English

1. Install "Installation Wizard 2" from the Software Utility directory on the software CD.

2. The program will conduct an analysis of your network environment. After your network

is analyzed, please click on the "Next" button to continue the program.

3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network

Cameras on the same LAN.

4. After a brief search, the main installer window will pop up. Double-click on the MAC

address that matches the one printed on the camera label or the S/N number on the

package box label to open a browser management session with the Network Camera.

Assigning IP Address

For further setup, please refer to the user's manual on the software CD.

18x

Ready to Use

1. A browser session with the Network Camera should prompt as shown below.

2. You should be able to see live video from your camera. You may also install the

32-channel recording software from the software CD in a deployment consisting of

multiple cameras. For its installation details, please refer to its related documents.

What Is Covered: This warranty covers any hardware defects in materials or

workmanship, with the exceptions stated below.

How Long Coverage Lasts: This warranty lasts for THIRTY-SIX MONTHS from

the date of purchase by the original end-user customer.

What Is Not Covered: This warranty does not cover cosmetic damage or any

other damage or defect caused by abuse, misuse, neglect, use in violation of

instructions, repair by an unauthorized third party, or an act of God. Also, if serial

numbers have been altered, defaced, or removed. Further, consequential and

incidental damages are not recoverable under this warranty.

What VIVOTEK Will Do: VIVOTEK will, in our sole discretion, repair or replace

any product that proves to be defective in material or workmanship. Any repair or

replaced part of the product will receive a THREE-MONTH warranty extension.

How To Get Service: Contact our authorized distributors in your region. Please

check our website (www.vivotek.com) for the information of an authorized

distributor near you.

Your Rights: SOME STATES DO NOT ALLOW EXCLUSION OR LIMITATION

OF CONSEQUENTIAL OR INCIDENTAL DAMAGES, SO THE ABOVE EXCLU-

SION OR LIMITATION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES

YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS

WHICH VARY FROM STATE TO STATE.

1. Proof of the date of purchase is required. In the event you can not render such

document, warranty will commence from the date of manufacture.

2. Cosmetic damage will only be covered by this warranty if such damage has

been existed at the time of purchase.

P/N:627004600G

VIVOTEK INC.

6F, No. 192, Lien-Cheng Rd., Chung-Ho,

Taipei County, Taiwan.

www.vivotek.com

Quick Installation Guide

VIVOTEK INC.

6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.

|T:+886-2-82455282|F:+886-2-82455532|E:[email protected]

VIVOTEK USA, INC.

2050 Ringwood Avenue, San Jose, CA 95131

|T: 408-773-8686|F: 408-773-8298|E: [email protected]

1080P HD • 18x Zoom • PoE

All specications are subject to change without notice.

P/N:625028100G Rev.: 1.0

SD8161 Speed Dome

Network Camera

English 繁中日本語 Español Português

簡中 Français Deutsch Italiano Türkçe Polski Русский Česky Svenska

Dansk

Nederlands

Indonesia

VIVOTEK Netherlands B.V.

Busplein 36, 1315KV, Almere, The Netherlands

|T:+31 (0)36 5389 149|F:+31 (0)36 5389 111|E:[email protected]
