Vitea Care DRVG0C Manual de usuario

USER’S MANUAL

UMBRELLA

REHABILITATIVE

STROLLER

(DRVG0C)

EDITION PK01.2020ML

page - 1

INSTRUKCJA UŻYTKOWNIKA

UMBRELLA

WÓZEK INWALIDZKI SPECJALNY

DZIECIĘCY

(DRVG0C)

WYDANIE PK01.2020ML

strona - 21

USER’S MANUAL (EN)

Table of content

1. Introduction.....................................................................................................................2

2. Product description.........................................................................................................2

3. Application.......................................................................................................................4

4. Contradictions .................................................................................................................4

5. Usage...............................................................................................................................4

6. Safety of use....................................................................................................................8

7. Everyday use and maintenance ......................................................................................10

8. Technical parameters......................................................................................................19

9. Symbols ...........................................................................................................................20

10. Contact details...............................................................................................................21

ATTENTION

Always follow the basic precautions according to the information included

below and regarding safety measures when using the device. Read the entire

instructions carefully before use. Keep this user’s manual for future reference.

Umbrella rehabilitative stroller is available in three sizes, further known as

Umbrella 1, Umbrella 2 & Umbrella 3. For detailed information please refer to

the Technical Parameters section.

1. Introduction

Thank you for choosing our product. We are deeply convinced that it will meet your

expectations. Please read this document before first use. This manual was made in order to

provide the necessary information on the safe use of the device. The correct application of

the recommendations will contribute significantly to extended durability and visual design of

the product. We would like to highlight that to date we are constantly improving the quality

of our products, which may result in minor changes that are not included in this manual.

2. Product description

Fig. 1. Construction scheme of Umbrella rehabilitative stroller.

1. Handle, 2. Canopy handle, 3. The side lock, 4. Stroller frame, 5. Footrest length adjustment

knob, 6. Dual rear wheels (or single in Umbrella 3), 7. The front swivel wheel with possibility

of straight ahead ride lock, 8. Canopy, 9. Head stabilizer, 10. Backrest upholstery (with side

pelottes and lumbar roller support), 11. Front guard, 12. Abduction wedge, 13. Calf stabilizing

belt, 14. Basket for small items, 15. The footrest.

Basic and additional equipment of the stroller’s package

Fig 2. Stroller

Fig. 3. Canopy

Fig. 4. Head stabilizer, front guard (2 versions, black - additional option), abduction wedge,

set of side pelottes with lumbar roller support

Fig. 5. Basket for small items , umbrella (additional option), table (additional option), cup

Fig. 6. Sleeping bag Fig. 7. Raincover

3. Application

The stroller is designed for children with disabilities and / or dysfunctions movement activities

as a result of damage of the CNS Central Nervous System. It can be used in children with CP

Cerebral Palsy, myelomeningocele, muscle disorders, dysfunctions of the lower limbs. The

maximum weights are 30 kg (Umbrella 1) 45 kg (Umbrella 2) & 75 kg (Umbrella 3).

4. Contraindications

Contradictions against sitting position.

5. Usage

• After unpacking the package, check if it contains all parts in accordance with the list of

elements set out above.

• Ensure that all components have no visible damage. If any doubts, please contact the

manufacturer.

• Do not use the stroller until all parts are properly connected.

Assembly guide –please refer to Figure 1.

a) Unfolding the stroller

Fig. 8. Unfolding the stroller

•Unfolding the stroller should begin with pulling the stroller handles in a direction which is

shown in Figure 8. In order to make it easier, you can hold with hand the seat of the

stroller.

•When the stroller is partially unfolded, press foot on the stroller blockade (Figure 9.) to

the point where stabilizing elements will stop in a horizontal position (Figure 10).

Fig. 9. Rear lock of the stroller Fig. 10.Correct position of rear lock

•To prevent unplanned movement of the stroller, lock the possibility of rotation the two

rear wheels.

•To do this, press the foot brake lever, located at the rear wheel.

•It is necessary to make sure that the brake has been launched on both wheels.

•Stroller frame is equipped with the side lock. To lock the side frame, the side lock eyelet

should be put on the free end of the frame (Figures 11., 12.).

Fig. 11. Stroller frame with lock Fig. 12. Locked eyelet on the stroller

Fig. 13. Assembled and locked rehabilitative stroller

Rear lock of the

stroller

Side

lock

eyelet

•To install the front guard, put the plastic ends into the guides on the stroller frame in the

direction from top to bottom (Figures 14., 15.).

Fig. 14. Front guard lock button (open) Fig. 15. Front guard lock button (closed)

•By using the snaps attach the upholstery belt to the front guard. But first you need to

fasten abduction wedge to the upholstery belt.

•In the same way table can be attached to the stroller (Figure 16).

•Abduction wedge is connected to velcro which should be wrapped around the upholstery

waist (Figure 16.).

Fig. 16. Abduction wedge, table and upholstery waist assembled

•Then install the backrest. Unfasten the velcro fasteners of head stabilizer at the rear part

of the upholstery, select the appropriate location of the head stabilizer. Drag velcro

headrest through the holes in the top of the backrest upholstery, then fasten velcro.

•To install the canopy put the plastic ends into the guides on the stroller frame in the

direction from top to bottom. (Figures 17., 18.)

•The footrest should be lowered on the footrest frame and push it until total blockade.

Fig. 17. Canopy lock button (open) Fig. 18. Canopy lock button (closed)

•The back part of the canopy should be located on the outer side of the backrest. Velcro

strips on both sides of the canopy should be fastened on the wheelchair frame under the

handles.

Fig. 19.Canopy assembled to the stroller Fig. 20.Basket assembled to the stroller

•Basket for small items must be installed between the seat and the cross frame. (Figure 20.)

The basket is equipped with velcro to be wrapped around four the furthest located stroller

frame.

b) Folding the stroller

•To fold the stroller, unclip the footrest from one side. Unfasten the upholstery belt. Slide

rail in the direction from the bottom to the top by pressing at the same time two front

guard lock buttons located at both ends of the rail.

•In order to remove the canopy, press the canopy lock button and slide in the direction

from the bottom to the top.

•Unlock two side lock at both side.

•Unlock the rear lock of the stroller by lifting it upwards.

•Now you are ready to fold the stroller by directing the handle to the front wheels and by

directing the side frames to each other to the point where the stroller will be looking like

as shown in Figure 7.

•The last stage is fastening a safety belt.

6. Safety of use

a) Before using the stroller, refer to this manual and keep it for future reference.

b) Your child's safety may be compromised case of non-compliance of rules contained in this

manual.

c) Never leave a child unattended. Always watch the child when he/she is in the stroller.

Caretakers are responsible for the safety of the child.

d) The seat is not suitable for children under 6 months.

e) Always use the seat belts to avoid serious injuries caused by the child falling out or slipping

out of the stroller.

f) It is important to fasten seat belt properly and its adjustment to the user.

g) The seat and belts do not replace proper supervision of caretaker.

h) While adjusting the parameters of the stroller, the child should not be in a stroller.

i) All repairs must be carried out by qualified personnel. And during the warranty period only

by the manufacturer's service.

j) The stroller is not suitable for running or ice-skating and roller skating.

k) The stroller is designed for transporting only one child.

l) It is unacceptable to use the stroller, if you found visible or palpable damage, or worn out

parts and stroller parts indicates a potential risk of an accident (e.g. Consumption wheels,

upholstery, cracks, etc.).

m) Always check before use if the stroller is properly unfolded. Ensure that all locks blocked

before use.

n) To avoid injury to make sure that the child is far away when the product is being folded

and unfolded.

o) When moving the stroller through doors and other passages, make sure that on both sides

there is enough space to avoid injury of hands or damage the stroller.

p) Do not allow your child to play with this product.

q) Do not allow your child to stand on the stroller or footrest. The stroller might fall over

and hurt the child.

r) When in motion, always hold the handle of the stroller.

s) Be especially careful while using the wheelchair near to steps and stairs.

t) The stroller is not intended for use on stairs and escalators.

u) Do not to move the stroller if a child is sitting in it.

v) Do not to move the stroller by holding the front guard. If there is a need to move your

stroller, you should hold the fixed elements of the frame.

w) In order to avoid accidental rolling off the stroller, always put on the brakes and turn on

the lock of driving direction when the stroller is stopped, when patient get in, get off,

changing the position.

x) Do not let the child stand on the footrest. Never leave the stroller unattended on sloping

ground, even if the brakes are on.

y) The stroller is designed for children up to 30 kg (Umbrella 1), 45 kg (Umbrella 2)

and 75 (Umbrella 3).

z) Stroller should always be easy to fold out. In case of problems with unfolding. You should

re-read the user's manual or contact the manufacturer.

aa) Keep extreme caution while passing an obstacle. Extreme use of the stroller could cause

damage or destroy it.

bb)Never use the stroller as a seat for the transportation of people in cars, buses or any motor

vehicles.

cc)During transport (e.g. In the trunk), do not burden stroller, it may weaken or damage its

structure.

dd)Do not leave the stroller with the user close to open sources of fire

ee) Be aware that the surface temperature of the upholstery and the frame parts may be

increased after exposure to the sun or other heat source. Furthermore, with low

temperatures there is a danger of overcooling metal parts of stroller. It may cause burns

or frostbite parts of the body.

ff) Keep caution while moving on sloping surfaces. The maximum allowable slope angle up

and down is 5%.

gg) With the stroller you can only use on surfaces where all four wheels touching the ground

are to use all of four wheels.

hh)Stroller is designed for use indoors and outdoors only on paved and even surfaces.

ii) Use of the product i.e. The icy, wet, greasy, strongly gritty surfaces is unacceptable - it

creates a risk of falling.

jj) It is extremely important to keep all strollers’ components clean in order to maintain the

product parameters.

kk) Do not add additional loads (bags, etc.) on the stroller handles.

ll) Storing the stroller in areas with very high humidity (baths, laundry, etc.) or in the open

air, also the lack of hygiene causes rapid loss of operating parameters and aesthetic of the

product.

mm)Do not leave the child in the stroller for longer, because persons with neurological

affections who stay in unchanged positions may experience problems with skin

nourishment and develop bedsores.

nn)When the footrests will not be removed before folding the stroller, it can cause damage.

oo)During use, handing of the product and during its assembly, regulating mechanisms, it

might happen trapping and / or squeeze user's or caretaker's body part in holes / gaps

between the elements.

Tabla de contenidos

Idiomas:

Otros manuales de Paseante de Vitea Care

Vitea Care

Vitea Care Premium PROMYK Manual de usuario

Vitea Care

Vitea Care UMBRELLA Manual de usuario

Vitea Care

Vitea Care PROMYK PLUS Manual de usuario

Vitea Care

Vitea Care PROMYK Manual de usuario

Vitea Care

Vitea Care Junior Plus 2 Manual de usuario

Vitea Care

Vitea Care PREMIUM PROMYK SPECIAL PLUS Manual de usuario

Vitea Care

Vitea Care Junior Plus Manual de usuario

Vitea Care

Vitea Care MDH Junior Manual de usuario

Vitea Care

Vitea Care UMBRELLA Manual de usuario

Manuales populares de Paseante de otras marcas

Hauck

Hauck Priya Trioset Manual de usuario

CHILDHOME

CHILDHOME CWQDN Manual de usuario

Dreamer Design

Dreamer Design Rebound GST Manual de usuario

Britax

Britax STEELCRAFT AGILE Manual de usuario

Graco

Graco 7427 Manual de usuario

Comfort

Comfort COMPASS Manual de usuario

OBaby

OBaby Aura Manual de usuario

Tutek

Tutek Tirso Manual de usuario

Babify

Babify Dual Plus Manual de usuario

Graco

Graco Stroller Manual de usuario

Special Tomato

Special Tomato Jogger Manual de usuario

Chicco

Chicco CORTINA TOGETHER TWO-PASSENGER STROLLER Manual de usuario

Otto Bock

Otto Bock Kimba neo Manual de usuario

Milly Mally

Milly Mally ROYAL Guía de inicio rápido

Hauck

Hauck DUETT 3 PRAM Manual de usuario

BOB

BOB DUALLIE Manual de usuario

Nuna

Nuna Pepp Manual de usuario

Britax

Britax B2 Manual de usuario
