VISIONARY DESIGNS MOD-9008 Manual
© 2021
Order #XXXXX
Locked layer contains
placeholder marks.
Graphic
Velcro
Velcro
Keep Z-plate attached to post
when packing.
Steps:
1) Attach base plate to bottom of post, using bolt.
2) Connect Z-plate to post, using bolts.
3) Attach Graphic to back of Z-plate, using Velcro.
When assembled
Bolt
Base
Plate
Bolt
Bolt
Z-Plate
Post
w/Cap
MOD-9008 Hand Sanitizer Stand
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS
© 2021
Order #XXXXX General Information
DO NOT USE POWER TOOLS
DO NOT USE SCREWS
THAT ARE STRIPPED
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all set screws
and locks during disassembly.
Hex Tool - Essential for Assembly
