3LEO 10GigE Area Scan User Manual
1 1
Product
Description
1
CHAPTER 1 PRODUCT DESCRIPTION
Product Introduction
LEO series industrial cameras compatible with GigE、10GigE、USB3.0 and Cameralink data bus standards, support GenICam、
USB3 Vision® and GigE Vision®, Smoothly connect with third-party software, like HALCON and Vision Pro, not need for secondary
development. LEO series cameras with excellent cost performance and very suitable for various inspections measurement and high-
speed imaging applications. This series cameras won customers high praise because its outstanding performance in cellphone and
tablet PC screen inspection, LED automatic packaging, defect inspection, and electronic components manufacturing, wafer positioning
and other applications.
With this variety of sensors and interfaces, combined with the extensive features offered, LEO series cameras are fit for a wide range of
vision applications.
Product Features
■ 10 Gigabit Ethernet interface, compatible with Gigabit Ethernet, with maximum 100m transmission；
■ 1024MB on-board frame buffer for data transmission and image retransmission；
■ Supports software trigger, hardware trigger, free run mode and etc；
■ Supports sharpness, gamma correction, LUT, black level correction and other ISP function；
■ Supports interpolation algorithm, white balance algorithm, color conversion matrix, hue,saturation and etc. for color camera；
■ Supports various output formats for image data and supports ROI, binning, mirror and etc；
■ Conforms GigE Vision protocol and GenICam standards；
■ Support third-party software connection.
＊ The camera functions may differ by camera models,please refer to actual functions.
Status LED Description
Status LED Description
Slow Flashing Red
(the interval between on and off is 2000 milliseconds) The camera wiring exception occurs.
Red light is always on The camera exception occurs.
Blue light is always off The camera is in idle status.
Fast Flashing Blue
(the interval between on and off is 200 milliseconds) The camera is acquiring images normally.
Slow Flashing blue
(the interval between on and off is 1000 milliseconds) The camera is acquiring images in trigger mode.
Flashing Alternately Red and Blue _The firmware is updating.
_The function of finding me is executed,
