ILLUSTRATED ASSEMBLY MANUAL H3505IP-1

Total solder points: 94

Difficulty level: beginner 1 2 3 4 5 advanced

Nomoredeadbatteriesdueto

headlightsthatwerelefton.

CAR HEADLIGHT ALARM

VELLEMAN NV

Legen Heirweg 33

9890 Gavere

Belgium Europe

www.velleman.be

www.velleman-kit.com

Features:

 Continuously repeated alarm tone for lights ON (may be disabled)

 Repeated alarm tone for lights OUT

 Only 3 wires are required for hook-up

Specifications:

 Supply voltage: 12V battery

 PCB dimensions: 48 x 57mm (1.9" x 2.2")

 Recommended housing: WCAH2855

Features & Specifications

Assembly hints

1. Assembly (Skipping this can lead to troubles ! )

Ok, so we have your attention. These hints will help you to make this project successful. Read them carefully.

1.1 Make sure you have the right tools:

• A good quality soldering iron (25-40W) with a small tip.

• Wipe it often on a wet sponge or cloth, to keep it clean; then apply solder to the tip, to give it a wet look. This is called ‘thinning’ and will

protect the tip, and enables you to make good connections. When solder rolls off the tip, it needs cleaning.

• Thin raisin-core solder. Do not use any flux or grease.

• A diagonal cutter to trim excess wires. To avoid injury when cutting excess leads, hold the lead so they

cannot fly towards the eyes.

• Needle nose pliers, for bending leads, or to hold components in place.

• Small blade and Phillips screwdrivers. A basic range is fine.

For some projects, a basic multi-meter is required, or might be handy

1.2 Assembly Hints :

⇒Make sure the skill level matches your experience, to avoid disappointments.

⇒Follow the instructions carefully. Read and understand the entire step before you perform each operation.

⇒Perform the assembly in the correct order as stated in this manual

⇒Position all parts on the PCB (Printed Circuit Board) as shown on the drawings.

⇒Values on the circuit diagram are subject to changes.

⇒Values in this assembly guide are correct*

⇒Use the check-boxes to mark your progress.

⇒Please read the included information on safety and customer service

* Typographical inaccuracies excluded. Always look for possible last minute manual updates, indicated as ‘NOTE’ on a separate leaflet.

Assembly hints

1.3 Soldering Hints :

1- Mount the component against the PCB surface and carefully solder the leads

2- Make sure the solder joints are cone-shaped and shiny

3- Trim excess leads as close as possible to the solder joint

REMOVE THEM FROM THE TAPE ONE AT A TIME !

DO NOT BLINDLY FOLLOW THE ORDER OF THE

COMPONENTS ONTO THE TAPE. ALWAYS CHECK

THEIR VALUE ON THE PARTS LIST!

 R1 : 47K (4 - 7 - 3 - B)

 R2 : 47K (4 - 7 - 3 - B)

 R3 : 47K (4 - 7 - 3 - B)

 R4 : 47K (4 - 7 - 3 - B)

 R5 : 220K (2 - 2 - 4 - B)

 R6 : 470 (4 - 7 - 1 - B)

 R7 : 470 (4 - 7 - 1 - B)

 R8 : 10K (1 - 0 - 3 - B)

 R9 : 10K (1 - 0 - 3 - B)

 R10 : 1M (1 - 0 - 5 - B)

4. Resistors

R...

Construction

 D1 : 1N4148

 D2 : 1N4148

 D3 : 1N4148

 D4 : 1N4148

 D5 : 1N4148

 D6 : 1N4148

 D7 : 1N4148

 D8 : 1N4007

 D9 : 1N4007

2. Diodes. Watch the polarity !

D. . .

CATHODE

 IC1 : 14p

 IC2 : 14p

5. IC sockets, Watch the

position of the notch !

 Between IC1 & IC2

1. Jumper

 C1 : 100nF (104)

6. Capacitor.

 T1 : BC547B

7. Transistor.

 ZD1 : 2V4

3. Zener diode. Watch the

polarity !

ZD...

CATHODE

 Buz1

 Remove the safety sticker form

the buzzer, if any.

8. Buzzer

+BUZ...

Construction

 J1 : 2P

 J2 : 3P

 IC1 : CD40106 or eq.



IC2 : CD4070 or eq.

11. IC’s. Check the position of

the notch!

 C2 : 22µF



C3 : 22µF



C4 : 22µF



C5 : 22µF



C6 : 22µF



C7 : 470µF

9. Electrolytic Capacitors.

Watch the polarity !

C...

10. Screw connectors

Use and connection

Mount the circuit underneath the dash board and make the following connections: (see Fig. 1.0)

 Connect the GND connection with the chassis or the battery (-) pole.

 Connect the L connection with the connection carrying voltage when the lights are turned on.

 Connect the C connection with the connection carrying voltage when the contact is switched ON.

12. Use and connection

LIGHTS ON AND OFF

WARNING TO TURN

CAR LIGHT

CONTACT

K3505

CLGND

Fig. 1.0

If the alarm should only operate when the driver forgets to turn off the lights, a jumper should be inserted

between the J2 connections.

LIGHTS OFF ONLY

WARNING TO TURN

GND L C

K3505

CONTACT

CAR LIGHT

Fig. 2.0

Use and connection

13. PCB layout.

PCB

P3505'1

VELLEMAN

ZD1

BUZ1

CLGND

R10

J1 R3

IC1

IC2
