timeSWITCH 150

GB, IE, ES, PT

Operating and installation manual

For the owner and heating engineer

Operating and installation manual

timeSWITCH 150

24-hour timer

GB, IE

Contents

timeSWITCH 150 24-hour timer operating and installation manual

Contents

Notes on the

documentation . . . . . . . . . . . . . . . . . . 4

Other valid documents.......................... 4

Symbols used........................................... 4

Storage of the documents.................... 5

Safety . . . . . . . . . . . . . . . . . . . . . . . . . 5

Operating instructions . . . . . . . . . . . 5

1 Description of the device. . . . . . 5

2 Operation. . . . . . . . . . . . . . . . . . . 8

2.1 Selecting the operating mode .... 8

2.2 Setting the timer............................ 8

2.3 Setting slides................................... 9

2.4 Setting the heating program....... 9

2.5 Weekend mode ............................... 9

2.6 Summer time mode....................... 9

2.7 Power failure................................... 10

3 Recycling and disposal. . . . . . . . 10

Installation manual . . . . . . . . . . . . . . 11

4 Information on the installation

and

operation . . . . . . . . . . . . . . . . . . . 11

4.1 CE label............................................. 11

4.2 Intended use.................................... 11

3timeSWITCH 150 24-hour timer operating and installation manual

Contents

GB, IE

5 Safety instructions and regula-

tions. . . . . . . . . . . . . . . . . . . . . . . 13

5.1 Safety instructions ........................ 13

5.2 Regulations...................................... 14

6 Installation . . . . . . . . . . . . . . . . . 14

7 Start-up. . . . . . . . . . . . . . . . . . . . 16

8 Handing over to the owner . . . . 17

9 Customer service and warranty 18

10 Technical data. . . . . . . . . . . . . . . 19

4timeSWITCH 150 24-hour timer operating and installation manual

Notes on the documentation

Notes on the

documentation

The following information is intended to

help you throughout the entire docu-

mentation. Further documents apply in

combination with this operating and

installation manual.

We accept no liability for any damage

caused by failure to observe these

instructions.

Other valid documents

Operating and installation manuals for

all system components

Symbols used

Please observe the safety instructions in

this manual.

The symbols used in the manual are

explained below:

Caution!

Potentially dangerous situations

for the product and environment!

Note!

Useful information and instruc-

tions

• Symbol for a required task

5timeSWITCH 150 24-hour timer operating and installation manual

GB, IE

Notes on the documentation; Safety; Description of the device 1

Storage of the documents

Please pass on this operating and instal-

lation manual to the owner of the system

so that it is available whenever it is

required.

Safety

The timer must be installed by an

approved specialist, who is responsible

for the observance of the relevant stand-

ards and regulations.

Operating instructions

1 Description of the device

The timeSWITCH 150 timer is a 24-hour

timer used to time control Vaillant boiler

with or without hot water supply.

The timer is installed at the front of

Vaillant ecoTEC combi boilers.

6timeSWITCH 150 24-hour timer operating manual

1 Description of the device

Overview of the device

Fig. 1.1 Overview of the device

Key

1 Minute hand

2 Time mark

3a Slide pushed in (boiler on)

3b Slide pulled out (boiler off)

4 Time of day

5 Operating mode switch

7timeSWITCH 150 24-hour timer operating manual

GB, IE

Description of the device 1

Minute hand (1)

For displaying and setting the time.

Time mark (2)

The triangular time mark indicates the

time of day (e. g. 3.00 pm in Fig. 1.1).

Slide pushed in (3a)

The boiler is switched on by a pushed in

slide and remains on until the timer

arrives at a pulled out slide.

Slide pulled out (3b)

The boiler is switched off by a pulled out

slide and remains off until the timer

arrives at a pushed in slide.

Time of day (4)

The time of day is indicated by the time

mark of the movable number ring with

the time of day. The time of day is indi-

cated by a 24-hour scale.

Operating mode switch (5)

This switch is used to select the operat-

ing mode (refer to Section 2.1).

8timeSWITCH 150 24-hour timer operating manual

2 Operation

2.1 Selecting the operating mode

You can use the operating mode switch

(5) to change the operating mode of

your boiler as desired.

– The boiler is switched off permanently

if set to “off”.

– The boiler is switched on permanently

if set to “on”.

– The boiler is time controlled according

to the slide settings if set to “ ”.

2.2 Setting the timer

Viewing the time of day

The time of day is indicated by the

number ring on the time mark (2).

Note!

The timer has a 24-hour scale.

15:00 therefore corresponds to

3pm.

Setting the time

• Turn the minute hand (1) clockwise

until the desired time of day (4) is set

on the time mark (2) and the hand of

the clock indicates the desired time.
