V-tech Kidi Super Star DJ Instrucciones de montaje
91-003813-000 UK
Parent’s Guide
3
INTRODUCTION
Thank you for purchasing the VTech®Kidi Super Star®DJ!
Kidi Super Star®DJ helps encourage your child to sing, dance, show
their creativity and much more! This feature packed product includes
a microphone, adjustable stand and a 3.5mm jack audio cable, so you
can connect your own music player! Use the Music Magic feature to
remove or reduce the vocals of songs! Play 4 fun games and add in
over 30 sound effects to your performances! You can even record your
own sound effects and tracks! Sing along to the 6 songs in Singing Fun
mode or DJ to the 6 songs in DJ Mixer mode! It's time to set the mood
with the disco light and get this party started!
PRODUCT FEATURES
Microphone
On/Off Switch
Audience
Sound Effects
Button
DJ Pad Modes
DJ Sound
Effect Pads
Volume Slider
Music Magic
Left Button
Talent Show
Games
Right Button
Voice Changing
Effects
OK Button
DJ Disc
Instant Sound
Effects Buttons
DJ Creation
Record Playback
Light Effects
ON/OFF
Microphone
Jack
3.5mm DC
Jack
Audio-in Jack
4
PRODUCT LAYOUT AND BUTTONS
BUTTONS ON THE MAIN UNIT
ON/OFF Press this button to turn the unit ON/OFF.
Volume Slider This controls the master volume of the whole
unit, including the microphone volume. Slide
the slider to adjust the volume at any time.
NOTE: This unit complies with maximum
volume output standards to protect your
child’s hearing.
Music Magic
Button
This feature is for Singing Fun mode &
External Music Connection use only. It
reduces or removes the main vocal track
from most songs. This allows you to sing
along to the music as the lead. Press the
Music Magic button to toggle between Music
Magic mode and Normal mode.
Music Magic mode:
Reduces or removes the main vocal track
from songs*.
Normal mode:
Normal music playback.
NOTE:
This feature is not available in DJ Creation
mode.
*Music Magic feature may not work for all
songs. Its effectiveness varies depending on
the song. For best results, studio recorded
songs are recommended. Unfortunately we
cannot guarantee Music Magic will work for
every song. We do not recommend using
Music Magic for mono songs or live concert
performances, etc.
5
Record Press this button to record your performance.
A menu will appear with 2 recording slots.
Press the Directional buttons and press
the OK button to select a slot and begin
recording. During your recording, press this
button again to stop recording.
NOTE: Each slot can store a recording up to
2.5 minutes in length. Please ensure you do
not remove the batteries or power adaptor
(sold separately) during recording, otherwise
the recording may not be saved.
Playback
Press this button to play or pause your
recordings. Use the Directional buttons to
select the recording you would like to listen to
and press the OK button to play.
Light Effects Press this button to turn the light ON, to dim
the light, or to turn the light OFF. When the
light options are shown, use the Directional
buttons to change the light effect.
NOTE: We recommend turning off the
disco light if the light makes your eyes feel
uncomfortable.
Voice Changing
Effects
Press this button to switch between different
voice changing microphone effects.
Instant Sound
Effects Buttons
There are 5 instant sound effects buttons on
this unit. Press any of these buttons to add a
sound effect over your performance:
• Laughter • Applause
• Award • Cheering
• Intro Drum
6
DJ Pad Modes
DJ Sound Effects
Pads
There are 5 DJ Pad modes on this unit, press
these buttons to switch between different DJ
Pad sound effects.
DJ Sounds: After selecting this mode,
press any of the 6 DJ Sound Effects Pads to
play general DJ sound effects.
Announcer Sounds: After selecting this
mode, press any of the 6 DJ Sound Effects
Pads to play announcer sounds.
Drum Sounds: After selecting this
mode, press any of the 6 DJ Sound Effects
Pads to play drum set sounds.
Singing / Cartoon Sounds: After
selecting this mode, press any of the 6 DJ
Sound Effects Pads to play singing sound
effects or cartoon sound effects whilst playing
a DJ Mixer song, or to hear cartoon sound
effects only in any other mode.
NOTE: Pressing this button during a DJ
Mixer song will toggle between singing sound
effects and cartoon sound effects.
My SFX: After selecting this mode, press
any of the 6 DJ Sound Effects Pads to play
your own recorded sound effects.
DJ Disc
Scratch the DJ Disc to hear a scratch sound
effect, or to fast forward or rewind the track in
DJ Mixer mode.
Talent Show Press this button to enter Singing Fun,
External Music Connection or Free Play.
DJ Creation Press this button to enter the DJ Creation
menu. Here you can DJ along to the songs,
record your own sound effects and record
your own DJ Mixer track.
Games Press this button to enter Games mode for 4
different activities.
7
Directional Buttons
Press these buttons to make a selection.
OK Button Press this button to conrm your selection. In
DJ Mixer mode, press this button to sync the
drum loop in time with the track.
Microphone Jack Used to plug in your microphone.
NOTE: Please ensure a rm connection.
Audio-in Jack Used to plug in an external music player (not
included) using the supplied 3.5mm jack
audio cable.
3.5mm DC Jack
Used to plug in a 3.5mm DC 6V power
adaptor (not included).
BUTTONS ON THE MICROPHONE
Microphone
ON/OFF
Switch
Use this switch to turn the microphone ON or OFF.
Slide the switch up to (I) for ON and down to (O)
for OFF.
NOTE: To avoid picking up any unnecessary
harsh sounds from the microphone, place the
microphone away from the speaker and switch the
microphone OFF whenever it is not in use.
Audience
Sound Effects
Press this button to add audience sounds over
your performance.
NOTE: The microphone must be switched ON for
this button to work.
INCLUDED IN THIS PACKAGE
• 1 VTech®Kidi Super Star®DJ
• 1 microphone
• 1 3.5mm jack audio cable
• 1 parent's guide with lyrics
• 4 AA batteries for demo use only
• 1 set of stand components
8
x 1 x 1
x 1
x 2 x 1
x 1 x 1
x 1
x 1 x 3
x 1 x 1
WARNING: All packing materials such as tape, plastic sheets,
packaging locks, removable tags, cable ties and
packaging screws are not part of this toy, and should be
discarded for your child’s safety.
NOTE: Please keep this parent's guide as it contains important information.
The toy is only to be connected to Class II equipment bearing the
following symbol:
Turn the packaging lock
anticlockwise several times.
Pull out and discard the packaging lock.
Removing the packaging locks:
STAND ASSEMBLY
Adult assembly required. For your child’s safety, do not let your
child play with this product until it is fully assembled.
9
Stand components include 3 poles of different lengths to adjust height.
You can choose a suitable height from 7 combinations for your child's
height.
NOTE: For the best stability, we recommend positioning any foot of
the stand perpendicular to the back of the Kidi Super Star®DJ unit.
Please refer to the below illustration.
10
Portable Mode Stand Mode Table Mode
GETTING STARTED
BATTERY REMOVAL AND INSTALLATION
Kidi Super Star®DJ uses 4 AA batteries or a 3.5mm DC 6V power
adaptor (not included).
• Make sure the unit is turned OFF.
• Locate the battery cover on the bottom of the unit.
• Remove the battery cover and if used or spent batteries are present,
remove them by pulling up on one end of each battery.
• Install 4 new AA batteries and close the battery cover.
WARNING:
Adult Assembly required.
Batteries included to be installed by an adult before
giving the product to children.
Keep batteries out of reach from children.
