Universal Electronics Potenza ST Manual de usuario

www.urcsupport.com

Potenza ST

Universal Remote Control

Users Guide

PREPROGRAMMED FOR YOUR SET-TOP BOX

Remote guide V3 8/25/08 9:01 AM Page 1

www.urcsupport.com

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Key Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Device Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Programming Device Control . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Setting Up a Combo Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Searching for Your Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Checking the Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Using Learning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Learning Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Programming a Learned Key . . . . . . . . . . . . . . . . . . . . 13

Deleting a Single Learning Key . . . . . . . . . . . . . . . . . . 14

Deleting All Learned Keys in a Specific Mode . . . . . . . 15

Programming Channel Control Lock . . . . . . . . . . . . . . . . . . . 15

Unlocking Channel Control . . . . . . . . . . . . . . . . . . . . . . 16

Locking Channel Control to STB . . . . . . . . . . . . . . . . . . 16

Changing Volume Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Unlocking Volume Control for a Single Device

(Individual Volume Unlock) . . . . . . . . . . . . . . . . . . . 17

Unlocking All Volume Control (Global Volume

Unlock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Locking Volume Control To One Mode (Global

Volume Lock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Programming ID Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Programming Macro Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Programming a Macro Key . . . . . . . . . . . . . . . . . . . . . . 19

Clearing a Macro Key . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Using the Master Power Key . . . . . . . . . . . . . . . . . . . . . . . . . 20

Programming the Master Power Key . . . . . . . . . . . . . . 20

Using the Master Power Key . . . . . . . . . . . . . . . . . . . . 21

Clearing the Master Power Key . . . . . . . . . . . . . . . . . . 21

Re-Assigning Device Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Clearing Custom Programming . . . . . . . . . . . . . . . . . . . . . . . 23

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

FCC Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Remote guide V3 8/25/08 9:01 AM Page 2

www.urcsupport.com

Some features might not be available.

INTRODUCTION

The Potenza ST Universal Remote Control by Universal

Electronics is our latest generation universal remote

control. Its sophisticated technology allows you to

consolidate up to five of your original home

entertainment remote controls into one easy-to-use

product. Moreover, its packed with advanced features

such as:

• Preprogrammed control to operate the set-top box

supplied by your service provider

• Dedicated keys to control popular functions on your

DVR/PVR (Digital/Personal Video Recorder)

• Programmable Master Power key for master on/off

control of your home entertainment equipment with

a single keystroke

• Programmable Macro Keys to allow you to activate

certain keys in a specific order

• Channel Lock to lock channel selection only to the

cable converter

• Volume Lock to lock volume controls to one mode or

individual modes

• Device Key Re-Assignment to remotely control a

second (duplicate) device

• Code Search to help program control of older or

discontinued components

• Color-coded keys to quickly locate popular

functions

• Code library for popular video and audio devices

Before using the product, you will need to install the

enclosed batteries and also perform some programming

to operate the specific home entertainment devices you

wish to control.

Please follow the instructions detailed in this manual to

set up the unit and then start enjoying your new remote

control.

Remote guide V3 8/25/08 9:01 AM Page 3

www.urcsupport.com

Some features might not be available.

FEATURES AND FUNCTIONS

Use the illustration below to locate features on the

Potenza ST Universal Remote Control and then study the

Key Charts (on the next three pages) to learn how they

function.

To find out what type of devices can be controlled by

each device key after programming, see “Device Table”

on page 7.

Remote guide V3 8/25/08 9:01 AM Page 4

www.urcsupport.com

Some features might not be available.

Key Charts

Key Function

Use SETUP for all programming

sequences.

Press POWER once to turn on or off a

home entertainment device. For

MASTER POWER control, see “Using the

Master Power Key” on page 20.

Press VCR, DVD, AUD, TV, or STB once to

select a home entertainment device to

control. Also see “Device Table” on

page 7.

Each device key has an embedded LED

(red light) that blinks upon selection

and indicates the remote control is

working and (after programming) is

sending signals.

Use GUIDE to display the program

guide.

Use INFO to display the current channel

and program information.

Use DAY+ (or DAY-) to move a day

forward (or back) on your set-top box’s

program guide.

Use the Cursor keys to move the cursor

in the program guide and menu screens

and to navigate within the interactive

service.

Use OK to choose options, PPV events,

and to tune to programs from the

program guide.

Use PAGE+ (or PAGE-) to page up (or

page down) through menu screens and

the program guide.

Use EXIT to exit out of your set-top box’s

menu and guide.

Use VOL+ (or VOL-) to raise (or lower)

the audio volume.

Use FAV to cycle through your favorite

channels stored in your set-top box.

Remote guide V3 8/25/08 9:01 AM Page 5

www.urcsupport.com

Some features might not be available.

Key Charts

Key Function

Use CH+ (or CH-) to select the next

higher (or lower) channel.

For DVD players, use these keys to skip

forward (or reverse) through chapters.

For amplifiers/receivers, use these keys

to select the next higher (or lower)

preset station.

Press MUTE once to turn the sound off

or on.

Press LAST once to recall the last

channel.

Press ON DEMAND to access Video on

Demand services.

Use A, B, C, and D(round red, green,

yellow or blue keys) to access additional

features on your set-top box (see set-top

box manual for details). These keys bring

up different options when you’re in the

guide and when your not. In the guide,

refer to the color codes at the bottom of

the screen for options.

Use to command your PVR/DVR

set-top box to instantly replay the last 7

seconds of a program you are watching.

Press LIVE to command your PVR/DVR

set-top box to return to watching live

TV.

Press LIST once to display a list of

recorded shows on your PVR/DVR settop

box.

In all modes except STB, use REW, PLAY,

FFWD, STOP, and PAUSE to control a

VCR, DVD player, or a PVR (after

selecting a desired device). To record in

the VCR mode, press REC twice.

In the STB mode, use these keys to

control the DVR/PVR functions of the

set-top box.

Use the keypad numbers (1-9, and 0) to

directly tune channels (e.g., 09).

For amplifiers/receivers, use the keypad

numbers to select inputs 1 through 10.

Press ASPECT once to change the aspect

ratio of the show you are watching. (Not

available on all set-top boxes).

Remote guide V3 8/25/08 9:01 AM Page 6

www.urcsupport.com

Some features might not be available.

Key Charts

Key Function

Press SHIFT to access additional set-top

box features (see your set-top box’s

manual).

PIP turns the Picture-In-Picture feature

on or off (if available on your TV or

settop box).

SWAP is used to switch PIP images and

sound between the main and window

pictures.

MOVE moves the PIP window to

different positions on your TV screen.

PIP CH+ and CH- are used to select the

next higher or lower channel and is

displayed on your PIP window.

INPUT in STB mode is used to view other

video sources (Aor B). In other modes,

use INPUT to switch between the source

inputs on the device you are controlling.

MACRO 1 and MACRO 2 are reserved for

use as macro keys (See “Programming

Macro Keys” on page 19.).

Device Table

NOTE: Please refer to the table below when

performing the instructions in

“Programming Device Control” on page 8 or

“Setting Up a Combo Unit” on page 10.

After programming, the Potenza ST Universal Remote

Control will be able to control the following types of

devices:

Device Key Controls these types of devices

VCR, TV/VCR Combo, PVR (Personal

Video Recorder), or extra DVD Player

DVD Player, or extra VCR, TV/VCR

Combo or PVR

Audio Amplifier, Tuner, or Receiver

Television

Set-top box

Remote guide V3 8/25/08 9:01 AM Page 7

www.urcsupport.com

Some features might not be available.

INSTALLING BATTERIES

1. On the back of the remote control, push the

tab and lift off the battery cover.

2. Locate the two (2) enclosed AA batteries.

Match the + and - marks with those in the

battery case, then insert them.

3. Align the covers keys with the cases holes and

press the cover back into place. The tab should

click when the cover is locked.

4. Test the remote control by pressing any mode

key (e.g., TV). If the batteries are inserted

correctly, the LED (red light) will blink once.

NOTE: When batteries need replacement, the remote

control will cease to operate. Replace the

batteries and the unit will be restored to its

full functionality, complete with your favorite

settings.

PROGRAMMING DEVICE CONTROL

The Potenza ST Universal Remote Control is

preprogrammed to operate the set-top box provided by

your television service provider, an RCA TV, a Toshiba

DVD player, an RCA VCR, and a Pioneer audio receiver.

To control devices other than the default brands,

perform the following steps; otherwise skip this section.

Remote guide V3 8/25/08 9:01 AM Page 8

www.urcsupport.com

Some features might not be available.

NOTES: For control of a Combo device (for example, a

TV/VCR combo), skip this section and perform

the instructions on “Setting Up a Combo

Unit” on page 10. Also refer to “Device Table”

on page 7 to find out which devices can be

programmed onto each device key.

If you have another brand of set-top box you

would like to control, you’ll need to unlock the

STB ID Lock before changing the set-top box

code (see “Programming ID Lock” on

page 18).

1. Turn on a device and, if applicable, insert

video media, (e.g., cassette or disc).

NOTE: Please read steps 2 through 5 completely

before proceeding. Highlight or write down

the codes and device you wish to program

before moving on to step 2.

2. On the remote control, press a device key once

(i.e., VCR, DVD, AUD, TV, or STB); it will blink

once.

3. Press and hold SETUP until the selected mode

key blinks twice, then release SETUP.

4. Use the “Manufacturer’s Codes” at

www.alliancecom.net/pdf/remote_code.pdf to

locate the type of device and brand name and

then enter the first four-digit code for your

device. If performed correctly, the selected

mode key will blink twice.

If you don’t want to use the Internet to search

for the code, see “searching for the code” on

page 11 for instructions on how to procede.

NOTE: If the selected mode key emits a long blink,

the entry is invalid. Repeat steps 2 through 4

and try entering the same code again.

5. Aim the remote control at the device and

press POWER once. The device should turn

off. If it does not, repeat steps 2 through 4,

trying each code for your brand until you find

one that works. If it still does not respond, try

searching for the code (see “Searching for

Your Code” on page 11).

NOTE: If the device does not have a POWER key (e.g.,

DVD and VCR), press the (Play) key.

6. Repeat steps 1 through 5 for each device you

want the remote control to operate. For future

reference, write down each working device

code in the boxes on the following page.

Remote guide V3 8/25/08 9:01 AM Page 9

VCR Code

Device Type:

DVD Code

Device Type:

STB Code

Device Type:

STB Code

Device Type:

www.urcsupport.com

Some features might not be available.

SETTING UP A COMBO UNIT

If you own a combo unit such as a TV/VCR Combo or a

TV/DVD Combo, you need to follow special steps to set

it up. Perform the following instructions to control

combo device:

1. For a TV/VCR Combo, turn on your TV/VCR

Combo and insert a video cassette. (For a TV/

DVD Combo, insert a DVD).

2. On the remote control, press VCR once; it will

blink once. Then press and hold SETUP until

the VCR key blinks twice.

3. Use the “Manufacturer’s Codes” at

www.alliancecom.net/pdf/remote_code.pdf to

locate the brand name and enter the first four-

digit code for your combo device (for example,

TV/VCR). If you perform this procedure

correctly, the VCR key will blink twice.

If you don’t want to use the Internet to search

for the code, see “Searching For Your Code” on

page 11 for instructions on how to procede.

NOTE: If the VCR key did not blink twice after

entering the codes last digit, repeat steps 2

VCR Code

Device Type:

DVD Code

Device Type:

STB Code

Device Type:

STB Code

Device Type:

Remote guide V3 8/25/08 9:01 AM Page 10

Otros manuales para Potenza ST

Tabla de contenidos

Otros manuales de Mando a distancia de Universal Electronics

Universal Electronics

Universal Electronics ATLAS Manual de usuario

Universal Electronics

Universal Electronics URC-2054 Manual de usuario

Universal Electronics

Universal Electronics URC-2054 Manual de usuario

Universal Electronics

Universal Electronics MediaRemote Manual de usuario

Universal Electronics

Universal Electronics CERVINO Manual de usuario

Universal Electronics

Universal Electronics URC2068BC2 Manual de usuario

Universal Electronics

Universal Electronics Millennium 4 Manual de usuario

Universal Electronics

Universal Electronics Polaris 1090 Manual de usuario

Universal Electronics

Universal Electronics Delta M3068 Manual de usuario

Universal Electronics

Universal Electronics ATLAS OCAP 5 Manual de usuario

Universal Electronics

Universal Electronics URC1090 Manual de usuario

Universal Electronics

Universal Electronics Millenium 4 Manual de usuario

Universal Electronics

Universal Electronics ATLAS XL Manual de usuario

Universal Electronics

Universal Electronics ATLAS DVR 5, PVR 5 Manual de usuario

Universal Electronics

Universal Electronics Potenza ST Manual de usuario

Universal Electronics

Universal Electronics Apple TV Remote for Video Service Providers Manual de usuario

Universal Electronics

Universal Electronics Nevo C3 Manual de usuario

Universal Electronics

Universal Electronics Apple TV Remote for Video Service Providers Manual de usuario

Universal Electronics

Universal Electronics MTS 2150 Manual de usuario

Universal Electronics

Universal Electronics ATLAS CABLE 4-DEVICE Manual de usuario

Universal Electronics

Universal Electronics Millennium 4 Manual de usuario

Universal Electronics

Universal Electronics NEVO PORTAL Manual de usuario

Universal Electronics

Universal Electronics Apple TV Remote for Video Service Providers Manual de usuario

Universal Electronics

Universal Electronics Helix Z-wave Manual de usuario

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
