Unitron

uDirect™ 2

guide

Thank you

Thank you for choosing the Unitron uDirect™ 2.

At Unitron, we care deeply about people with

hearing loss. We work closely with hearing

healthcare professionals to make advanced,

purpose-driven solutions available to everyone.

Because hearing matters.

Your uDirect 2

Hearing healthcare professional: ________________

____________________________________________

Telephone: __________________________________

Serial number of uDirect 2: _____________________

Warranty: ___________________________________

Date of purchase: _____________________________

Table of contentsQuick reference

Your uDirect 2 at a glance ................................................................2

Setting up the power supply ...........................................................4

Charging the uDirect 2 .....................................................................5

Turning the uDirect 2 ON and OFF ....................................................6

Battery status information ...............................................................7

uDirect 2 Bluetooth pairing ............................................................8

Wearing the uDirect 2 correctly ......................................................9

Testing sound via the uDirect 2 ......................................................10

Streaming music via a cable ..........................................................11

Streaming music via Bluetooth .................................................... 12

Watching TV .................................................................................. 14

Adjusting the volume ....................................................................15

Using uDirect 2 for phone calls ...................................................... 16

Advanced phone options ...............................................................23

Using uDirect 2 as a remote control ...............................................27

Using uDirect 2 with FM ................................................................. 31

Wearing the uDirect 2 in different ways .........................................34

Managing multiple audio inputs to the uDirect 2 ..........................35

Resetting your uDirect 2................................................................ 40

Summary of indicator lights ...........................................................41

Introduction to Bluetooth ..............................................................44

Setting up Bluetooth .....................................................................48

Caller identiﬁcation: spoken caller names .....................................55

Troubleshooting guide ...................................................................58

Warnings ........................................................................................66

Compliance information .................................................................72

OFF ON

Charging uDirect 2

Power indicator

Solid red - charging

Solid green - fully charged

Red blink - low battery

No light - battery drained

Bluetooth pairing

Wearing uDirect 2

On/Off

2 sec Blue blink

Accessories

o, p Universal power supply with mini-USB plug

q, r, s, t US, EU, UK, AUS adapter

Other optional accessories

External lapel microphone “MC1”

Short neckloop (51 cm)

Unitron uTV 2 (Bluetooth transmitter for TV use)

Audio cable, 1.5 m / 5 ft.

USB cable, 3 m / 10 ft.

Included country adaptors may vary by country.

Your uDirect 2 at a glance

Buttons

a Access ( )

b Volume or SmartFocus* ( )

c Home ( )

d Connect ( )

e ON/OFF switch ( )

Inputs

f Microphone openings

g Audio input (3.5 mm jack)

h FM input (Europlug)

i Charging input (mini-USB)

Indicators

j Audio indicator

k Power indicator (power)

Neckloop

l Neckloop sockets

m Neckloop (with antenna)

n Neckloop plugs

*Can be conﬁgured by your hearing healthcare professional.

g h i

p q r

Charging the uDirect 2

Your uDirect 2 has a non-removable rechargeable

battery.

To charge it:

1. Plug the mini-USB plug into the

mini-USB port on the uDirect 2.

2. Plug the power supply into a

power outlet.

Power indicator

Solid red: Charging,

typically 90 minutes.

Solid green: Battery fully charged.

It is safe to leave the uDirect 2

connected to the charger overnight.

When charging your uDirect 2 for the ﬁrst time,

let it charge for at least three hours, even if the

battery indicator is not lit or turns green earlier.

A new battery’s full performance is achieved only

after two to three complete charge and discharge

cycles.

Setting up the power supply

1. Select the adapter that corresponds to your

country.

US EU UK AUS

2. Insert the round corner of

the adapter to the round

corner of the universal

power supply until it is

completely inserted.

3. Click the tail of the adapter

in to lock it into place. Make sure the adapter

is securely locked.

To remove the power adapter:

a. Pull back the tab on the

universal power supply and

hold.

b. Gently pull the adapter upwards

to remove it from receptacle.

c. Then start over with step 1 (above).

a. b.

Turning the uDirect 2 ON and OFF

Slide the power switch

() as shown to turn

the uDirect 2 ON or OFF.

Switch the uDirect 2

OFF when not in use or if in storage or during

transportation.

For operational use switch the uDirect 2 ON.

Battery status information

The power indicator shows the following:

Green for 2 seconds Switching ON

Blink red then solid

for 2 seconds

Switching OFF

Slow blink green Normal operation

Short blink red <20% battery left,

please charge

No blinking just

after switching ON

Charge for at

least 2 hours

If the neckloop has been unplugged for more

than 2 minutes, the power indicator is only lit as

long as a button is pressed.

OFF ON

Wearing the uDirect 2 correctly

Before any phone, music or TV streaming can

take place, the uDirect 2 must be switched ON

and worn correctly as shown below:

1. Put the neckloop around

your neck (easily done by

unplugging one neckloop

plug).

2. Make sure both plugs

are well connected in the

neckloop sockets.

3. Switch the uDirect 2 ON.

For streaming, the neckloop must always be

plugged in. When unplugged, the uDirect 2

will go into sleep mode after two minutes. The

power and audio indicators will stop blinking

and all active Bluetooth connections are

terminated to save power. Plug the neckloop in

again to activate the streaming.

uDirect 2 Bluetooth pairing

1. Switch ON ( ) the uDirect 2.

2. Press and hold the connect ( ) and volume

() buttons simultaneously for 2 seconds until

the audio indicator starts to rapidly blink blue.

3. Start the pairing process on the Bluetooth®

device (e.g., phone) within 1 minute according

to the devices user guide and use code

“0000” when prompted.

4. After successful pairing, the audio indicator

will stop rapidly blinking blue.

The pairing process does not require the neckloop

to be plugged in. For streaming and Bluetooth

connection, the neckloop is mandatory.

When pairing to a cellular phone, we recommend

disabling the phone key tones and SMS alerts.

2 sec

1110

Make sure the uDirect 2 is charged and

switched ON.

Make sure you are not on a phone call

connected through the uDirect 2.

Streaming music via a cable

The uDirect 2 must be switched ON and worn

correctly around your neck.

1. Insert the audio cable into the headphones

socket on your audio player and start the

player.

2. Insert the other end of the audio cable into

the audio input on your uDirect 2. The audio

streaming is

automatically

activated and the

audio indicator

will change to

orange.

Testing sound via the uDirect 2

1. Wear the uDirect 2 correctly and switch it ON.

2. Press and hold the connect

( ) and access ( ) buttons

simultaneously for 2 seconds until

the audio indicator turns violet.

The hearing aids will switch to the

streaming mode and you will hear the uDirect 2

sound demo for 30 seconds after the last volume

adjustment.

Use the volume ( ) buttons to adjust the

volume.

The sound demo will stop 30 seconds after the last

volume adjustment or by pressing any other key.

If you cannot hear the sound demo:

Make sure your hearing aids are inserted

correctly.

Make sure the uDirect 2 neckloop is properly

plugged in on both ends and worn around

your neck.

1312

2. Switch ON the other Bluetooth device.

3. For some Bluetooth devices it may be

necessary to press “play” on the device.

4. If the devices were paired and connected

correctly, streaming will start automatically

and the audio indicator will turn solid blue.

Use the access ( ) button to stop and restart

Bluetooth streaming.

To stop Bluetooth streaming completely, switch

the other Bluetooth device OFF or disable its

Bluetooth feature.

The uDirect 2 will conﬁrm that Bluetooth

streaming is activated with spoken notiﬁcations

or beeps, depending on the uDirect 2

conﬁguration.

The hearing aid programs cannot be changed

via the uDirect 2 access ( ) button when the

Bluetooth device is streaming.

Brieﬂy press the access ( ) button to stop and

restart streaming.

The programs of your hearing aids cannot be

changed via the uDirect 2 access ( ) button

when the audio cable is plugged in.

uDirect 2 will conﬁrm streaming via cable when

activated with either spoken notiﬁcations or

beeps, according to the uDirect 2 conﬁguration.

Streaming music via Bluetooth

If you have an audio source equipped with

Bluetooth functionality (e.g., MP3 player), you

can stream audio wirelessly to your hearing

aids.

In order to use your uDirect 2 with a Bluetooth

enabled audio device or transmitter, you must

ﬁrst pair the devices.

To start Bluetooth streaming:

1. uDirect 2 must be switched ON and worn

correctly.

1514

Adjusting the volume

Press the uDirect 2 volume ( ) buttons to adjust:

Press ( ) to increase the volume

Press ( ) to decrease the volume

Adjusting the volume on the uDirect 2 will have

the same effect as adjusting the volume of the

hearing aids.

You can also change the volume of the streaming

audio signal only by using the volume controls of

the audio device (e.g., cellular phone, MP3 player,

uTV 2). This gives you the ability to decrease the

hearing aid volume using the minus ( ) button

during a phone call in a noisy environment, and

increase the phone volume at the same time by

using the volume up button on the phone.

If your uDirect 2 was not paired with your hearing

aids by your hearing healthcare professional,

the ( ) volume buttons will only change the

streaming audio but not the hearing aid volumes.

If your uDirect 2 was conﬁgured to adjust

SmartFocus™ (comfort/clarity) instead of volume,

press ( ) for more clarity and ( ) for more

comfort.

Watching TV

We recommend using the dedicated and

optimized uTV 2 for watching TV.

It ensures low latency wireless transmission for

up to 30 meters (90 ft.), offers a built-in volume

control and acts as a charging cradle for the

uDirect 2.

Otros manuales para uDirect 2

Tabla de contenidos

Otros manuales de Audífono de Unitron

Unitron

Unitron uMic Manual de usuario

Unitron

Unitron Latitude Moxi 13 Instrucciones de montaje

Unitron

Unitron Connect SmartFocus Manual de usuario

Unitron

Unitron Flex:trial Manual de usuario

Unitron

Unitron Stride P Pro Manual de usuario

Unitron

Unitron Quantum micro BTE Manual de usuario

Unitron

Unitron Stride P Pro Manual de usuario

Unitron

Unitron Max Manual de usuario

Unitron

Unitron Moxi2 Dura Manual de usuario

Unitron

Unitron uDirect 3 Manual de usuario

Unitron

Unitron uDirect 2 Manual de usuario

Unitron

Unitron Passport Manual de usuario

Unitron

Unitron Latitude Moda 13 Manual de usuario

Unitron

Unitron uTV 2 Manual de usuario

Unitron

Unitron Stride B9-UP Manual de usuario

Unitron

Unitron Latitude Moxi 13 Manual de usuario

Unitron

Unitron Latitude ITE Manual de usuario

Unitron

Unitron T Moxi All 800 Manual de usuario

Unitron

Unitron Tandem Manual de usuario

Unitron

Unitron iCube Manual

Unitron

Unitron Unison Digital BTE Manual de usuario

Unitron

Unitron Latitude Moxi 3G Manual de usuario

Unitron

Unitron Quantum Manual de usuario

Unitron

Unitron Shine Rev Manual de usuario

Manuales populares de Audífono de otras marcas

Sonic

Sonic Bliss miniBTE Manual de usuario

Lexie

Lexie B1 Manual de lista de piezas

Widex

Widex FM+DEX Manual de usuario

Siemens

Siemens Triano Manual de usuario

Camplicomms

Camplicomms HC-200 Manual de usuario

Widex

Widex SUPER 220 S2-VSD Manual de usuario

Phonak

Phonak Q90 Manual de usuario

Williams Sound

Williams Sound SoundPlus WIR 237 Guía

Oticon Medical

Oticon Medical Ponto SoundConnector Manual de usuario

Siemens

Siemens Life micon Manual de usuario

Starkey

Starkey Destiny Manual de usuario

Audicus

Audicus The Icon Manual de usuario

Advanced Bionics

Advanced Bionics Slim HP Standard Manual de usuario

Widex

Widex DREAM440 THE DREAM SERIES Manual de usuario

Phonak

Phonak myPilot Manual de usuario

NIKEN

NIKEN NK-401 Manual de usuario

ON Semiconductor

ON Semiconductor Ezairo 7111 Pre Suite Manual de usuario

Sonetik

Sonetik GOHEAR Manual de usuario
