Uni-Com FEP-32008T-3 Manual de usuario

Mico-Switch/8

8 Port 10/100Base-TX Switch

(Auto MDI/MDIX)

FEP-32008T-3

SER’S ANUAL

Package contents include the following:

IMPORTANT: If any piece is missing or damaged, please contact your

local dealer or reseller for service.

Product Name:

Serial Number:

Date of Purchase:

Purchased from:

Notes:

Micro-Switch/8; 8 Port 10/100Base-TX Switch

Micro-Switch/8 User ’s Guide Rubber feet Power Adapter

DC power adapter

Warranty card

Figure 1. Contents of package

8 port Switch

User ’s manual

Four (4) adhesive-backed rubber feet

Package Contents

For Your Records

Mic o-Swit ch/ 8

8 Port 10/ 100Base-TX S witch

(Auto MDI/MDIX)

FEP-32008T-3

SER’SANUAL

switch that provides wire-speed, a Fast Ethernet switching function which

allows high-performance, low-cost connections to Full-duplex, Half-duplex

10Mbps and 100Mbps Ethernet networks. The Mico-Switch/8 delivers

all the advantages of a switching hub in a compact desktop size and is

ideal for small office or SOHO network users. It’s also wall mountable

which conserves office space.

This Switch provides eight auto-sensing 10/100Mbps Ethernet RJ-45

ports which automatically detect the speed of the devices that you plug

into them. This switching function allows 10Mbps, 100Mbps, Full-duplex

and Half-duplex devices to communicate on the same network without

having to replace any infrastructure. This flexible feature allows your

network a timely, economical migration to 100Mbps Fast Ethernet.

Conforms to IEEE802.3, 802.3u, 802.3x

Automatic MDI/MDIX crossover for all ports

N-Way Auto-negotiation for 10/100Mbps transmissions

Space-saving compact size

Store-and-Forward switching architecture

Auto-detection of full/half-duplex mode in all ports

Plug-and-Play configuration auto address learning

768Kbit packet buffer

LED indicators for Power, Link/activity, and Full Duplex/Collision

Introduction

Key Features

The 8 port Mico-Switch/8 (Auto MDI/MDIX) is a compact Fast Ethernet

For full coverage of your warranty, be sure

to register your product using the enclosed

registration card.

Mico-Switch/8 8 Port 10/100Base-TX Switch

LINK/AC T

1 2 345678

The Front Panel

The front panel consists of LED Indications.

Per Device: Power

Per Port: LINK/ACT (Link/Activity)

LED

Power On Green

The switch is supplied with suitable

power.

Blinks

Off -The port is not linked successfully

with the device.

The port is receiving or transmitting

data.

The port is connecting at 10Mbps.

Green

LINK/ACT

Status Color Description

Power

Power Indicator

LINK/ACT Indicators

LED Indicators

Figure 2. Front panel view of LED indications

Hardware Description

The rear panel view of the Mico-Switch/8 consists of a DC power

connector and 8 auto-sensing ports.

RJ-45 Ports ( Auto MDI/MDIX )

8 auto-sensing ports of 10/100 N-way for 10Base-T or 100Base-TX

connections. [ In general, MDI means connecting to another Hub or

Switch while MDIX means connecting to a workstation or PC. Therefore,

Auto MDI/MDIX means that you can connect to another Switch or

workstation without changing pin-to-pin or crossover cabling. ]

Figure 3. Rear panel view of the Micro-Switch/8

DC Power Connector

Plug the female connector into the switch and male connector into

a power outlet. Supports input voltages 9 VDC at 700 mA.

The Real Panel

DC 9V

The Switch can be easily monitored through panel indicators to assist

in identifying problems. This section describes common problems you

may encounter and possible solutions.

If the power indicator does not light when the power cord is plugged

in, you may have a problem with the power outlet or cord. However, if

the power LED goes off after running for a while, check for loose power

Verify the proper cable type is used and its length does not exceed

certain the maximum distance between the Switch and what it’s

connections, power losses or surges at the power outlet. Turn off

power, wait 30 seconds and turn power on again. If problem is still

not resolved call for dealer’s assistance

If link indicator does not light after making a connection, check

Verify that the cabling type is correct. Make sure all cable connectors

whether network interface (e.g., a network adapter card on the

are securely seated in the required ports. Use only standard

attached device), network cable, or switch port is defective. Be sure

Unshielded Twisted-Pair (UTP), Category 3, 4, 5, or 5e cables. Use

the cable is plugged into both the switch and corresponding device.

only Category 5 or 5e when connecting with Fast Ethernet. Make

specified limits.

connected to is 100 meters or less.

Do not plug a standard telephone cord into an RJ-45 port.

This may damage the switch

Troubleshooting

Power

Diagnosing LED Indicators

Cabling

NOTE:

Product Specifications

Compliance:

Portocol:

Transfer Rate:

Connector:

MAC Address:

LED Indicator:

Network Cable:

Dimension:

Operating Temp:

Operating Humidity:

Power Supply:

Power Consumption:

EMI:

Memory Buffer:

Standard IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX Fast Ethernet

IEEE 802.3x Flow Control

CSMA/CD

14,880 pps for 10Mbps

148,800 pps for 100Mbps

RJ 45

Auto MDIX on all ports

1K Mac address table

768KBits

Per port: Link/Activity

Per unit: Power

10Base-T: 2-pair UTP Cat. 3,4,5e cable

(100m), EIA/TIA-568 100-ohm STP (100m)

100Base-T: 2-pair UTP Cat. 5e cable (100m),

EIA/TIA-568 100-ohm STP (100M)

137mm x 74mm x 24mm (W x D x H)

0℃ to 45℃ ( 32℉ to 113℉)

10% to 90% (Non-condensing)

External power supply

DC 9V, 700mA

5.8 Watt @ AC 240V/60Hz (Maximum)

FCC Class B

FCC Statement

This equipment has been tested and found to comply with the limits for a class B

device, pursuant to part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a commercial installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with instructions, may cause harmful

interference with radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference, in which case, the user will

be required to correct the interference at the user’s expense.

565 Brea Canyon Rd., Ste A

Walnut, CA 91789

www.unicomlink.com

@UNICOM 2007. UNICOM and “A Network Systems Solution” are trademarks of UNICOM Electric, Inc.

Rev: 11.12

e-mail: info@unicomlink.com

Phon e: 626.964.7873 Fax: 626.964.7880
