Ubiquiti NBE--2AC--13 Manual de usuario

NanoBeam BallJointMount LockRing

MetalStrap GigabitPoE(24V,0.5A)with

MountingBracket

PowerCord

PackageContents

InstallationRequirements

Polemounting:7mmsocketwrenchorscrewdriver

Wallmounting:wallfastener(notincluded)

ShieldedCategory5(orabove)cablingwithdrainwireshouldbeusedforall

wiredEthernetconnectionsandshouldbegroundedthroughtheACgroundof

thePoE.

Werecommendthatyouprotectyournetworksfromharmfuloutdoor

environmentsanddestructiveESDeventswithindustrialgrade,shielded

EthernetcablefromUbiquiti.Formoredetails,visitui.com/toughcable

Surgeprotectionshouldbeusedforalloutdoorinstallations.Werecommend

thatyouusetwoEthernetSurgeProtectors,modelETHSP,onenearthe

NanoBeamandtheotherattheentrypointtothebuilding.TheETHSPwill

absorbpowersurgesandsafelydischargethemintotheground.

NBE2AC13QuickStartGuide

HardwareOverview

ResetButton

EthernetPort

PowerLED

EthernetLED

SignalLEDs

Toresettofactorydefaults,pressandholdtheResetbuttonformorethan10

secondswhilethedeviceispoweredon.Alternatively,thedevicemaybereset

remotelyviaaResetbuttonlocatedonthebottomoftheGigabitPoEAdapter.

ThisGigabitEthernetportisusedtoconnectthepowerandshouldbe

connectedtotheLANandDHCPserver.

ThePowerLEDwilllightbluewhenthedeviceisconnectedtoapowersource.

TheEthernetLEDwilllightsteadybluewhenanactiveEthernetconnectionis

madeandflashwhenthereisactivity.

InairOS®,youcanmodifythethresholdvalueforthewirelesssignalstrength

LEDsontheWirelesstabunderSignalLEDThresholds.EachLEDwilllight

whenthewirelesssignalstrengthisequaltoorgreaterthantheLED’s

thresholdvalue.ThedefaultthresholdvaluesfortheseLEDsareshownbelow:

HardwareInstallation

Gototheappropriatemountinginstructions:PoleMountingor“WallMounting”.

Note:TheNanoBeamcanalsobemountedinsideawindowusingthe

NanoBeamWindowMount,modelNBE19WM(soldseparately).For

instructions,seetheNanoBeamWindowMountQuickStartGuide.

PoleMounting

1.

2.

3.

4.

WallMounting

TheNanoBeammustbemounteddirectlytoawoodstudorotherstructurally

stablesurfacetoavoiddamagetothemountingholewhenyouadjusttheaim.

OptionalAccessory

Toenhancestability,youcanusetheNanoBeamWallMountKit,modelNBE

WMK(soldseparately).

Note:Centerscrewincluded.Twooptionalscrews(notincluded)provide

additionalstability.

InstallationInstructions

1.

2.

3.

Fastener(notincluded) NanoBeamWallMountKit

4.

Aiming

1.

2.

ConnectingPower

1.

2.

3.

4.Connectthepowerusing:

includedGigabitPoEAdapter

PoEswitch

WARNING:Theswitchportmustcomplywiththepowerspecifications

listedinthisQuickStartGuide.

ConnectingtothePoEAdapter

1.ConnecttheEthernetcablefromthedevicetothePOEportofthePoEadapter.

2.ConnectanEthernetcablefromyourLANtotheLANportofthePoEadapter.

3.ConnectthePowerCordtotheadapter,andthenplugthePowerCordintoa

poweroutlet.

MountingthePoEAdapter(Optional)

1.RemovethePoEMountingBracketfromtheadapter,placethebracketatthe

desiredlocation,andmarkthetwoholes.

2.Predrilltheholesifnecessary,andsecurethebracketusingtwofasteners(not

included).

3.Aligntheadapter’sslotswiththetabsofthePoEMountingBracket,andthen

slidetheadapterdown.

AccessingairOSviaWiFi

VerifyconnectivityintheairOS®ConfigurationInterfaceusingtheUNMS™appor

WebPortal.Bothareavailablefor15minutesimmediatelyafteryoupoweronthe

device.Ifnecessary,youcanpowercyclethedevicetoreenableitsWiFi.

UNMSApp

1.DownloadtheUNMSapp.

2.Connectyourdevice’sWiFitotheSSIDnamed:<model>:<MACAddress>

Note:EnsurethatDHCPisenabledonyourWiFiadapter.
