TW Audio FDB30 Manual de usuario
Operating manual
FDB30
Operating manual FDB30
2
Introduction
Thank you for choosing a high-quality product “MADE IN GERMANY” from TW AUDiO.
The FDB30 dolly is an accessory for the B30, VERA S30 or T24N loudspeaker.
This accessory set is characterized by a subtle look, a remarkable size to weight ratio and
ease of use.
If you lend your product to another party, inform that party of the safety-related operating pro-
cedures and hand over this assembly guide. If you require additional copies of this manual,
you can obtain them free of charge from TWAUDiO or download them from www.twaudio.de
Instructions in this user manual
Strictly adhere to the instructions contained in this operating manual that are marked as
follows:
This symbol in combination with the signal word “Caution” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to light or moderate injury.
This symbol in combination with the signal word “Note” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to product damage.
This symbol in combination with the signal word “Tip” identifies additional information or
notes that will simplify working with TWAUDiO products on the basis of practical experience.
This symbol in combination with the signal word “Warning” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to serious injury or even death.
NOTE
TIP
CAUTION
WARNING
Operating manual FDB30
3
Notes on the products
Read manual
before use!
Before using the device, carefully read the operating manual and keep it with the FDB30 dolly.
General information
Operation manual: OM-FDB30
Version 1.0 en, 03/2019
© by TW AUDiO 2019; all rights reserved.
All information contained in this operating manual was correct to the best of our knowledge
at the time of printing.
Quality warranties or assurance of suitability for a certain type of use based on the technical
specifications, dimensions and weights are not granted by TWAUDiO.
TW AUDiO also shall not assume liability for any secondary damage (property damage and/or
personal injury) nor for the failure to comply with this operating manual!
TW AUDiO reserves the right to update this document based on recent developments.
TW AUDiO GmbH
Osterholzallee 140
71636 Ludwigsburg
Germany
Phone : + 49 (0) 71 41-48 89 89 0
Fax: + 49 (0) 71 41-48 89 89 99
WWW: www.twaudio.de
Operating manual FDB30
4
Content
1. Safety | Intended use...................................................................................................... 5
2. Overview ........................................................................................................................ 6
2.1 Components ........................................................................................................... 6
3. Technical specifications .................................................................................................. 7
3.1 Data sheet............................................................................................................... 7
4. Commissioning............................................................................................................... 8
4.1 Using FDB30 dolly with B30 or VERA S30 loudspeaker ........................................... 8
4.2 Using FDB30 dolly with T24N loudspeaker ............................................................ 10
5. Transport and Storage.................................................................................................. 12
6. CE Conformity Declaration............................................................................................ 13
7. Disposal ....................................................................................................................... 13
Operating manual FDB30
5
1. Safety | Intended use
To avoid risks please observe the following safety instructions when using accessories.
The FDB30 dolly was developed for professional use in sound systems. The dolly may only
be used by trained and qualified personnel.
Note the operating modes described in this operating manual. Other uses are not permis-
sible.
Damage caused by improper use is not covered by TW AUDiO.
Before each use, check the integrity of the FDB30 dolly and ensure that all components are in
perfect condition.
WARNING
The FDB30 dolly may only be used with the B30, VERA S30 or T24N loudspeaker.
These operating manual describe how to use the FDB30 dolly. Any other use shall be deemed
improper and may result in damage or even injury.
Modifications or alterations to individual parts of the FDB30 dolly are not permitted! Danger to
life!
WARNING
The FDB30 is an accessory designed both for indoor and outdoor use.
CAUTION
The FDB30 dolly may only be used by trained and qualified personnel. Personnel must check
the FDB30 for its full suitability before each use.
WARNING
When visible damage to any part of the FDB30 dolly is detected, it must be decommissioned
immediately.
WARNING
When moving the FDB30 dolly, ensure full load-bearing capacity and stability of the substrate.
The FDB30 dolly is specified for a load of not more than one B30 or one VERAS30 or one
T24N loudspeaker. This load capacity must never be exceeded!
WARNING
During movement (assembly or dismantling, transport to the place of use) of the FDB30 dolly
with the B30, VERAS30 or T24N loudspeaker, ensure sufficient space to prevent collisions
with other objects.
WARNING
Operating manual FDB30
6
2. Overview
2.1 Components
1. Dolly - Surface Warnex textured paint
2. Handles (2 pieces)
3. Butterfly-Latch, middle (2 pieces)
4. 100mm castor with stopper (2 pieces)
5. Recesses for stacking the dollys (4 pieces)
6. 100mm castor without stopper (2 pieces)
Figure 2.1 - Overview
123
4
6
5
Operating manual FDB30
7
3. Technical specifications
3.1 Data sheet
Maximum load capacity 1x B30 or 1x VERA S30 or 1x T24N
Dimensions (h x w x d) 700 x 440 x 150 mm (27.5 x 17.3 x 5.9in)
Weight 7,4 kg (16 lbs)
Surface Warnex textured paint
Operating manual FDB30
8
4. Commissioning
4.1 Using FDB30 dolly with B30 or VERA S30 loudspeaker
Figure 4.1.1 - Transport setup B30 loudspeaker with FDB30
Please note that two persons are always required to set up the FDB30 dolly with the B30 or
VERA S30 loudspeaker!
WARNING
Place the B30 or VERA S30 loudspeaker sideways upright on the floor and position the
FDB30 dolly so that the castors with stoppers are at the top.
Attach the FDB30 dolly to the B30 or VERA S30 loudspeaker using the butterfly latches.
WARNING
Figure 4.1.2 - Put up the B30 loudspeaker with FDB30
Operating manual FDB30
9
Figure 4.1.3 - Moving B30 loudspeaker with FDB30
Move the transport setup longitudinally to avoid overturning during transport.
When moving the FDB30 dolly transport assembly with the B30 or VERAS30 loudspeaker,
note that there is a risk of tipping due to the high center of gravity.
When moving the stacked FDB30 dolly, note that there is a risk of tipping on each individual
FDB30 dolly.
Figure 4.1.4 - Stacking the FDB30 dolly
The FDB30 dolly can be stacked for storage. For this purpose, recesses (see figure 2.1 -
Pos.5) are provided in the dolly (see figure 2.1 - Pos.1).
WARNING
WARNING
TIP
Operating manual FDB30
10
4.2 Using FDB30 dolly with T24N loudspeaker
Figure 4.2.1 - Transport setup T24N loudspeaker with FDB30
Please note that two persons are always required to set up the FDB30 dolly with the
T24N loudspeaker!
WARNING
Place the T24N loudspeaker on the floor and position the FDB30 dolly so that the castors
with stoppers are at the top.
Attach the FDB30 dolly to the T24N loudspeaker using the butterfly latches.
WARNING
Figure 4.2.2 - Put up the T24N loudspeaker with FDB30
