TScale SP Series Manual de usuario

Water proof scale

TECHNICAL MANUAL

SP Series Technical Manual

- 1 -

SP Series Technical Manual

- 2 -

CONTENTS

1. PRECAUTIONS……………………………………………………………..3

2. INTRODUCTION……………………………………………………………4

3. SPECIFICATIONS……………………………………………………….....5

DIMENSION…………………………………………………………………5

4. INSTALLATION……….…………………………………………………….7

5. PARTS DESCRIPTION…......................................................................9

6. OPERATION………………………………………………………….………..12

1. Power ON/OFF…………………………………………………………12

2. Zero……………………………………………………………………...12

3. Tare……………………………………………………………………...12

4. Unit Quantity…………………………………………………………….….12

5. Commodities without weighing……………………………….……….13

6. Backlight…………………………………………………………………....13

7. Auto Power Off…………………………………………………..……….13

7. PARAMETER………………………………………………………….……….14

8. CALIBRATION…………………………………………………………..……..16

9. DRAW ING………………………………………… ………… ………... 17

PARTS NAME………………………………………………………………….18

10.ERROR CODE……………………………………………………………...20

SP Series Technical Manual

- 3 -

1. PRECAUTIONS

CAUTION

Permit only qualified persons to service the instrument

Before connecting or disconnecting any components, remove the

power.

Failure to observe these precautions bodily harm or damage to or

destruction of the equipment.

Avoid installing the scale in direct sunlight, which may cause discoloration.

Avoid overloading that could cause damage to the scale.

If the scale is not to be used for a long period of time, remove all batteries

from the battery compartment to avoid leakage.

Avoid stack materials on the scales, when scale is not in use.

Avoid unsuitable tables. The tables or floor must be rigid and not vibrate.

Do not place near vibrating machinery.

Avoid unstable power sources. Do not use near large users of electricity

such as welding equipment or large motors.

Do not mix the type of batteries. Replace all the batteries at the same time

(Dry Cell).

Only use original SP adaptor, other could cause damage to the scale.

When the scale is used with an adaptor, the does not conform to IP-67

protection.

IP 6 5

Protected against:

Protected against entry of dust

IPCode (International Protection Rating) of IEC 60529

SP Series Technical Manual

- 4 -

2. INTRODUCTION

The SP series weighing scales is fully water proof scale.

It is suitable for sanitary applications, general weighing, price computing

and accumulation applications

IP65 waterproof technology

ABS Plastic housing.

Super low power consumption.

Optional options for dry cell battery and rechargeable battery.

15mm LCD with white LED back light display.

20 mechanical switches

SP Series Technical Manual

- 5 -

3. SPECIFICATIONS

DIMENSION

SPECIFICATION

Model

Capacity

3kg

6kg

15kg

Division

External Resolution

3000/6000/Dual

Display

15mm LCD x 3 display with White back light

Pan Size

200mm x 260mm

Keypad

20 mechanical keys

Operate

Temperature

0°C - 40°C /32°F - 104°F

Power

Adaptor 12V/500mA, Battery 6V/3.2 AH

Internal Counts

Up to 60000

Weight

Lead Acid 4.2 kg

SP Series Technical Manual

- 6 -

Load cell specifications

Model No

L6D

Rated Capacity

6~50 (kg)

Rated Out put

2.0 mV/V±0.2 mV/V

Excitation Voltage

18 VDC

IP Level

IP65

Material

Aluminum Alloy

Cable

Φ 3.8mm four core shield

Input Resistance

409Ω ±6Ω

Out put Resistance

350 Ω ± 3Ω

Temperature

Range

-10°C ~ +40°C

Safe overload

150 %R.C

Ultimate overload

300 %R.C

Repeatability

0.02 %R.O

Creep

0.02 %R.O/ 20min

Zero Balance

±0.2 mV/V

Weight

200g

SP Series Technical Manual

- 7 -

4. INSTALLATION

Unpacking

Carefully take the balance out of its package, make it sure its not damaged and

all accessories are included.

Remove the Indicator from the carton.

Remove the protective covering. Store the packaging and to use if you

need to transport the scale later.

Inspect the scale and terminal for damage.

Make sure all components are included

Accessories,

1. Balance

2. Adaptor

3. Pan

4. Product manual

Level Adjusting

Place the scale on a table.

Check the water mark. If, bubble is not centre

adjust the leveling feet until reach centre. Check

the level when you change the location.

Charging Battery

To charge the battery insert the adaptor pin to jack, jack is locating below

the scale. Adaptor simply plug into the mains power. The scale no needs

to be turned on.

The battery should be charged for 12 hours for full capacity.

Left side of the display there is an LED to indicate the status of battery

charging. When the scale is plugged into the mains power the internal

battery will be recharged. If the LED is green, the battery has a full charge.

If it is red, the battery is nearly discharged and if yellow, the battery is

being charged.

Do not use any other type of power adaptor than the one supplied with the

scale.

Verify that the AC power socket outlet is properly protected.

Note: Please charge the battery before using the scale for the first time

SP Series Technical Manual

- 8 -

CAUTION

Below the scale there is a breathable knob. Its default setting is for weigh. If you

want to wash tighten the knob, after wash release the knob for weigh

When want to weigh, release

screw for getting normal

pressure

When want to wash, tight screw

for getting seal

Installation

Place the scale on a table..

Connect the adaptor pin in to the indicator adaptor jack.

Adaptor jack is locating, rear side of the scale.

Adaptor connects into your AC power socket. Pluggable equipment

must be installed near an easily accessible socket outlet with a

protective ground/ earth contact.

Turn on the On/Off key. If you want to turn off, press the key again.

Display will be show the version number and will be starting self checking.

After self checking, display will be come to normal weighing mode.

Warm-up time of 15 minutes stabilizes the measured values after

switching on.

Calibrate with exact calibration weights, minimum 1/3 of the scale capacity

want to use for calibration. For calibration see details in parameter.

Then you can start your operation

SP Series Technical Manual

- 9 -

5. PARTS DESCRIPTION

Overall View

Sealing Ring Breathable knob &

Adaptor jack

Adaptor

Pan

Leveling Feet

Key board

Spirit Level
