Trust 14832 Manual de usuario
UK
PRESENTER MOUSE 14832
DE
FR
IT
ES
PL
NL
PT
GR
DK
SE
HU
CZ
FI
NO
TR
RU
User’s manual UK
DE
Version 2.0 FR
IT
ES
PL
NL
PT
GR
DK
SE
HU
CZ
SKSK
FI
NO
TR
RU
RO
BU
CN
USER’S MANUAL
1
H
G
F
E
D
C
B
A
P
O
I
J
K
L
M
NQ
R
1 23
USER’S MANUAL
1
23
2
5
4
6 6 Hrs.
USER’S MANUAL
1
7
2
8
9
…
USER’S MANUAL
10 12
1
2
Trust Mouse Mode
Easy Mouse Configuration
2x 3
1
2
11
USER’S MANUAL
1
12
2
13
12
1
14
2
USER’S MANUAL
+
USER’S MANUAL
1
Product information
UK
MOUSE
A: Laser
B: Right button
C: Left button
D: Trackball / scroll
E: Third button
F: Laser button
G: Low power indicator
H: Battery compartment
I: Desk sensor
J: Fourth button
K: Fifth button
L: On/Off
M: Recharge cable input
N: ID connect button
CRADLE
O: Mini receiver (removable)
P: ID connect button
Q: Recharge indicator
RECHARGE CABLE
R: Recharge indicator
Batteries
1 (1) Push battery cover. (2) Place batteries. (3) Close cover.
Installation
2 Put mouse in cradle.
3 PC off.
4 Connect USB cable to PC.
5 PC on.
6 Recharge batteries 6 hours.
When indicator green: batteries full.
7 (1) Press connect button receiver. (2) Press connect button mouse.
8 Insert CD-ROM. Click ‘Install driver’.
9 Follow on-screen instructions to finish.
Configuration
10 Double click icon.
11 (1) Click ‘Wheel’. (2) Select ‘Trust Mouse Mode’. (3) Click ‘Apply’.
12 (1) Click ‘Programmable button’. (2) Select mouse button to program.
13 (1) Assign function to button. (3) Click ‘OK’.
Click ‘Help’ for function details.
Travelling
14 Recharge mouse: (1) Connect cable to notebook. (2) Connect cable to mouse.
When indicator green: batteries full.
15 Connection: (1) Pull out mini receiver. (2) Connect receiver to notebook.
Repeat 7if necessary.
Note
USER’S MANUAL
2
General use
•Adjust the speed of mouse pointer: (1) Open Windows Help (Start →Help). (2) Search “adjust the speed of
mouse pointer”. (3) Follow instructions.
•Some applications may need MS IntelliMouse compatible mouse for correct function (see 6).
•The trackball will automatically switch to scroll function when mouse is placed on desk.
•Use soft brush to clean the optical sensor when it is dusty.
See www.trust.com/14832 for up-to-date FAQs, drivers and instruction manuals. For extensive service, register
at www.trust.com/register.
Wireless performance
•This device has 16 channels with 8192 different ID’s. Repeat step 8 to change ID.
•Wireless range is 15 m maximum in open field.
•Reduced wireless performance can be caused by:
- Metal objects close to or between the adapter and the other device.
- Empty batteries.
- Other wireless devices close by.
- The reception is limited when the signal must pass through concrete walls and floors.
Energy
•For the best performance, use rechargeable AAA NiMH batteries.
•If cradle indicator is off during recharge, check batteries!
•The device will enter the energy saving mode when it is not used for 3 minutes. Click any button (except
laser) to re-activate. To save energy, turn the device off after use.
•Do not throw the batteries onto a fire.
•Observe local regulations when disposing of batteries.
Safety instructions
•CAUTION! LASER CLASS 2. Do not stare into the laser beam.
•Do not open or repair this device.
•Do not use the device in a damp environment. Clean the device with a dry cloth.
•This device meets the essential requirements and other relevant conditions of the applicable European
directives. The Declaration of Conformity (DoC) is available at www.trust.com/14832/ce.
USER’S MANUAL
3
Wireless
•This class 1 wireless device works at a frequency of 2.4 GHz. It meets the essential requirements and other
relevant conditions of R&TTE Directive 1999/5/EC and can be used in the following countries: all EU
countries, as well as CH, RU, TR, NO and HU. There are no limitations per channel for the above-mentioned
countries. See www.trust.com/14832 for an updated list of the countries where the use of this device is
permitted.
UK
•There may be restrictions for the use of this device outside of the EU. If this device is used outside of the EU,
check whether this device meets the local regulations. Frequency: 2.402 ~ 2.479 GHz. Bandwidth: approx. 1
MHz; Power: 1 mW.
Be careful when using wireless devices if you have a pacemaker or are dependent on other life-saving,
sensitive electronic equipment, because this device transmits radio signals.
•If possible, dispose of the device at a recycling centre. Do not dispose of the device with the household
waste.
Warranty & copyright
•This device has a two-year product warranty which is valid from the date of purchase. See
www.trust.com/warranty for more information.
•It is forbidden to reproduce any part of this instruction manual without the permission of Trust International
B.V.
