Trust DISAN Manual de usuario

DISAN PC LAPTOP

WIRELESS

Frequently asked questions:

www.trust.com/22210/FAQ

www.trust.com/22210/driver

Trust.com - 22210

WINDOWS 10 (64-BIT)

WINDOW 10

WINDOWS 8 (64-BIT)

WINDOWS 8

WINDOWS 7 (64-BIT)

WINDOWS 7

WINDOWS XP

DOWNLOAD PDF (50,51 MB)

DOWNLOAD PDF

DOWNLOAD EXE (8,20 MB)

PRODUCTS PRODUCTS CONTACT & SUPPORT

^^^

SUPPORT

DOWNLOAD

MANUALS PRODUCT INFORMATION SOFTWARE

Select type Select your language Select your operating system (OS)

Taal: Multilingual

Versie: 1.0

USER MANUAL ENGLISH

Trust GXT

161

Trust GXT 161 Gaming Mouse

Trust International BV

Network Drive

Program name:

Veriﬁed publisher

File origin: c

a b

IIII

III

b c

GXT 161 Gaming Mouse - USER’S MANUAL

1. Button layout

- Button 1 (Default = Left mouse button)

- Button 2 (Default = Right mouse button)

- Button 3 (Default = Mid click)

- Button 4 (Default = Forward)

- Button 5 (Default = Backward)

- Button 6 (Default = DPI cycle)

2. I nstallation

- Open the internet browser and go to www.trust.com/ 22210/driver.

Click the “Download EXE” button to download the software.

Click on the “22210_X.exe” and follow the installation wizard.

Click on the “GXT 161 Gaming Mouse” shortcut to start the software.

You can now start to configure the mouse. In the manual will be referred to ‘OK’ to update the mouse.

Button Programming

Assign a function

Click on the ‘MAIN’ tab.

Click on the button you want to re-assign

Click on tab ‘C’ for common functions.

Click on the function you want to assign.

Click on ‘OK’, to finalize your choise.

Click on ‘OK’, the mouse is being updated.

At least one button has to be assigned as “Left Click”.

GXT 161 Gaming Mouse - USER’S MANUAL

Mouse Movement Settings

DPI , Pointer, Polling rate and Scroll wheel settings.

- ‘a’ shows your active DPI setting.

- Click on the arrows to adjust the DPI speed.

- Change the windows pointer speed.

- Change the polling rate.

- Change the windows scrolling speed.

- Click on ‘OK’, the mouse is being updated.

LED colours indicate which DPI level is currently active. These indication colours cannot be

changed;

oRED = Level 1

oGREEN = Level 2

oBLUE = Level 3

oTURQOISE = Level 4

oPURPLE = Level 5

GXT 161 Gaming Mouse - USER’S MANUAL

Light Settings

Basic Light Effect

Click on the ‘LED LIGHT’ tab.

Click on ‘Breathing’ for a breathing LED effect, Click on ‘Constant On’ for a constant LED effect.

You can move the sliders to adjust the breathing speed or LED brightness.

‘Breathing’ + ‘Constant On’ current colour indicator.

Change the colour by one of three options;

I Click on the desired color from the preset box.

II Dragging the Red, Green or Blue slider.

III Click on one spot on the color wheel.

Click on ‘OK’, the mouse is being updated.

LED Zones, fixed colors

Click on the ‘Multicolor mode’ to individually set each of the 3 LED zones.

Activate the ‘fixed color’ mode.

To select each colour;

I Click on the colour box

II Click on the desired colour

III Repeat this untill all zones are selected

Click on ‘OK’, the mouse is being updated.

LED Zones, varied colors

Activate the ‘varied color’ to activate the rainbow wave effects.

Move the slider to change the animation speed.

Click on ‘OK’, the mouse is being updated.

GXT 161 Gaming Mouse - USER’S MANUAL

Macro Settings

Create a Macro

(Store asequence of keys in the soft w are)

Click on the ‘MACRO’ tab.

Click on ‘+ ’ to create a new macro.

Fill in the name of the macro.

Click ‘Start Record’ to start recording the macro. Now enter your preferred macro sequence.

Click ‘Stop Record’ ones you finished recording the macro. (max. 100 actions)

To modify your recorded macro, click on the required step you want to modify.

Click on the button to activate the edit panel.

Change the key or delay and press ‘OK’ next to the entry field.

Assign a Macro

Click on the ‘MAIN’ tab.

Click on the button to which you want to assign the macro to.

Click on the ‘Macro selection’ tab.

Click on the desired macro.

Click on ‘OK’ to select the macro.

Click on ‘OK’, the mouse is being updated.
