Tripp Lite SmartPro SMART700USB Guía de configuración

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: SMART700USB

SmartPro USB UPS System - Intelligent, line-interactive battery backup for workstations

Highlights

700VA line interactive tower UPS system

Enhanced communications via USB port, free PowerAlert softare and cabling

Corrects brownouts as low as 83V

6 outlets (3 UPS / 3 Surge-only)

Single line TEL/DSL or ethernet line surge suppression

$200,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Description

Tripp Lite's SMART700USB line-interactive UPS system offers voltage regulation, surge suppression and long lasting battery support for personal

computers, internetworking equipment and other sensitive electronics. Internal UPS circuits support entry level PC systems for up to 45 minutes

during power failures so that connected equipment can be shutdown without data loss. Automatic Voltage Regulation (AVR) circuits regulate

brownouts as low as 83 volts back to usable levels without using battery power. Offers complete desktop power protection in an attractive black

upright tower configuration. Includes 3 battery supported outlets for computer, monitor and one vital system peripheral, plus 3 additional surge

suppression-only outlets for printers and other system accessories not requiring battery support. USB port enables optional unattended system

shutdown without data loss in the case of extended power failure, USB cable included. PowerAlert software available via free download from

www.tripplite.com. Built-in dataline protection jacks offer protection of a single dialup phone/DSL line or network ethernet connection. Built-in audible

alarm and 4 front panel LEDs indicate line power status, battery power status, battery low/replace status and voltage boost operation. 700VA/450

watt power handling ability supports entry-level PCs, network workstations, point-of-sale equipment, small business phone systems, audio/video

equipment and home theater systems. Offers 5 minutes battery runtime with a full load of 700VA/450 watts and 17 minutes with a half load of

350VA/225 watts. Supports battery replacement via built-in access panel. 2 year warranty. $200,000 connected equipment insurance (USA & Canada

Only).

Applications

Entry-level PCs, networked workstations, point-of-sale equipment, small business phone systems, audio/video equipment and home theater

systems. Ideal for sensitive electronic applications in areas where brownout conditions are common.

Package Includes

SMART700USB Standby UPS System

USB and Telephone interconnection cables

Instruction manual with warranty information

Features

SMART700USB line-interactive UPS system offers voltage regulation and battery support, plus complete AC and dialup/DSL/ethernet line

surge suppression

Supports entry level PC systems for up to 45 minutes during power failures to enable a safe system shutdown

Supports a max load of 700VA/450 watts for 5 minutes and a half load of 350VA/225 watts for 17 minutes

Automatic Voltage Regulation (AVR) circuits correct brownouts as low as 83 volts without using battery power

Attractive black tower configuration

Includes 3 battery supported outlets, plus 3 additional surge suppression-only outlets, 6 foot AC line cord (all NEMA 5-15)

USB port enables unattended shutdown without data loss during extended power failures, includes USB cable

Built-in USB port supports on battery, low battery, power restored, AC line voltage, DC battery voltage and battery capacity messaging;

interface supports timed inverter shutoff after unattended shutdown, activate self-test and 10 second reboot of connected equipment

PowerAlert UPS monitoring and unattended shutdown software available via free download from www.tripplite.com

Supports Tripp Lite's WatchDog software application to restore unresponsive programs by automatically restarting them and rebooting

completely locked computers by automatically switching UPS power off and back on again (part #75-0071)

Built-in dataline suppression jacks protect a single dialup phone/DSL line or network ethernet line connection

Built-in audible alarm and 4 front panel LEDs indicate UPS system and line power status

700VA/450 watt power handling ability supports a variety of computer, internetworking, telecom and consumer electronics equipment

Supports battery replacement via built-in access panel

Compatible with 120V/60Hz applications for USA, Canada, Mexico and more

2 year manufacturers warranty

$200,000 connected equipment insurance (USA & Canada Only)

Specifications

OUTPUT

Frequency

compatibility

60 Hz

Output VA 700

Output watts 450

Output nominal

voltage

120V AC

Output voltage

regulation

BATTERY MODE: PWM sine wave 120V +/-5%

Output frequency

regulation

LINE MODE: Passes line frequency of 60Hz +/-10%

BATTERY MODE: Inverter output regulated to 60Hz +/-0.5Hz

Outlet quantity / type 6 NEMA 5-15R output receptacles (3 with UPS and surge suppression / 3 with surge suppression only)

INPUT

UPS Input cord

length (ft.)

6 ft., 16 gauge

Recommended

Electrical Service

15A 120V

Maximum Input

Amps (A)

Input connection type NEMA 5-15P

Voltage compatibility

(VAC)

120

BATTERY

DC system voltage

(VDC)

Battery Access Battery access door allows user replacement of UPS batteries

Full load runtime 5 minutes (700VA)

Half load runtime 17 minutes (350VA)

Typical battery

lifespan

3-6 years, depending on usage

Battery recharge rate 2-4 hours to 90%

VOLTAGE REGULATION

Voltage regulation

description

Line interactive voltage regulation corrects brownouts as low as 83V back to 120V nominal values

Brownout correction Input voltages between 83 and 105 are boosted by 14%

Direct pass through Voltages of 106V and greater are passed through to connected equipment unchanged

LEDS ALARMS & SWITCHES

Alarms Audible alarm with 15 second delay sounds to indicate loss of utility power. Alarm can be silenced by pressing front

panel alarm cancel button. Once silenced, alarm will re-sound when approximately 2 minutes runtime remain.

Switches Includes 2 front panel switches — one main on/off power switch and one dual function "alarm cancel" / "self test"

button

Front panel LEDs 4 LEDs indicate performance conditions:

GREEN "online"

GREEN "voltage regulation enabled"

RED "on battery"

YELLOW "battery low/replace"

SURGE / NOISE SUPPRESSION

UPS AC suppression

joule rating

Conforms to IEEE 587 / ANSI C62.41 specifications

EMI / RFI AC noise

suppression

Yes

AC suppression

response time

Instantaneous

Dataline suppression Single line TEL/DSL or network ethernet surge suppression via single pair of RJ-style 8 position jacks (ethernet

protection pins 1,2,3,6 - 7.5V clamping / phone protection pins 4,5 - 260V clamping), includes phone cable

PHYSICAL

Shipping weight (lbs) 18.6

Shipping weight (kg) 8.4

Unit Dimensions

(HWD/in)

10.75 x 5.25 x 7.25

Unit Dimensions

(HWD/cm)

27.3 x 13.3 x 18.4

Unit weight (lbs) 17.2

Unit weight (kg) 7.8

Cooling method Convection

Material of

construction

PVC

Form factors

supported

Tower, wall mountable with optional UPSWM accessory

ENVIRONMENTAL

Relative Humidity 0 to 95%, non-condensing

COMMUNICATIONS

WatchDog

compatibility

Yes, compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft

reboot of application / OS or hard power off/on reboot of connected equipment - ideal for unattended kiosk

applications

Network monitoring

port

Built-in USB port supports on battery, low battery, and power restored messaging

Software and cabling

included

USB cabling included, PowerAlert software available for free download at www.tripplite.com

LINE / BATTERY TRANSFER

Transfer time from

line power to battery

mode

2-4 milliseconds

Low voltage transfer

to battery power

Switches to battery power as line voltage decreases to 83 volts or less. Resets to line power mode as line voltage

increases to 87V or higher.

High voltage transfer

to battery power

Switches to battery power as line voltage increases to 147 volts or higher. Resets to line power mode as line voltage

decreases to 143V or less.

SPECIAL FEATURES

Appearance Attractive all-black tower UPS

Cold Start Yes, inverter can be "cold started" to enable temporary AC output during a power failure

CERTIFICATIONS

Certifications Tested to UL1778 (USA), cUL (Canada), FCC Class B (emissions), NOM (Mexico), FCC Part 68 / Industry Canada

(Telecommunications)

WARRANTY

Product Warranty

Period (Worldwide)

2-year limited warranty

Optional Coverage 3-5 year warranties, plus next day and on-site warranty coverage available for select opportunities. Contact Tripp

Lite for additional information.

Connected

Equipment Insurance

(U.S., Canada &

Puerto Rico)

$200,000 Ultimate Lifetime Insurance

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=50.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
