Owner's Manual

SmartPro®

Datacenter INT

Intelligent, Line-Interactive

UPS Systems (230V Output)

9905251 230V SmartPro Datacenter OM.p65 8/8/00, 2:02 PM1

This manual contains important instructions and warnings that should be followed

during the installation, operation and storage of all Tripp Lite UPS Systems.

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, dust or

direct sunlight.

• For best performance, keep the indoor temperature between 0° C and

40° C (between 32° F and 104° F).

• Leave adequate space around all sides of the UPS for proper ventilation.

UPS Connection Warnings

• If your UPS has a corded input, connect it to a properly grounded AC

power outlet. Do not modify the UPS's plug. Do not use adapters that

eliminate the UPS's connection to ground.

• If your UPS has a hardwired input, ensure that it is properly grounded.

• Do not plug your UPS into itself; this will damage the UPS and void

your warranty.

• If you are connecting your UPS to a motor-powered AC generator,

the generator must provide clean, filtered computer-grade output.

Equipment Connection Warnings

• Do not use Tripp Lite UPS Systems for life support applications in

which a malfunction or failure of a Tripp Lite UPS System could cause

failure or significantly alter the performance of a life-support device.

• Do not connect surge suppressors to the output of your UPS. This

may damage your UPS and will void both the surge suppressor and

UPS warranties.

Battery Warnings

• Your UPS does not require routine maintenance. Do not open your

UPS for any reason. There are no user-serviceable parts inside.

• Battery replacement must be performed by qualified service personnel.

Because the batteries present a risk of electrical shock and burn from

high short-circuit current, qualified service personnel should observe

proper precautions: Unplug and turn off the UPS before performing

battery replacement. Use tools with insulated handles and replace the

existing batteries with the same number and type of new batteries

(Sealed Lead-Acid). Do not open the batteries. Do not short or bridge

the battery terminals with any object.

• The UPS batteries are recyclable. Refer to local codes for disposal

requirements, or in the US only call 1-800-SAV-LEAD for disposal

information. Do not dispose of the batteries in a fire.

• When adding external batteries, connect only Tripp Lite battery packs

of the correct voltage and type. Your UPS's External Battery Connector

should match the color of the connector of any battery pack you want

to connect.

Safety

9905251 230V SmartPro Datacenter OM.p65 8/8/00, 2:02 PM2

Quick Installation

Position your External Battery

Pack(s).

• If positioning multiple Battery Packs, place them side

by side or stack them no more than three high.

Position your Power Module.

• The Module may be stacked on top of your Battery

Packs or placed beside them.

Plug your External Battery Pack

into your Power Module's

External Battery Connector on

its back panel.

• For multiple Battery Packs, connect the first to the

Power Module, then daisy-chain the others: connect the

second to the first, the third to the second, and so on.

Plug your Power Module into a

L6-30 single-phase AC outlet on

a 30-amp dedicated circuit that

provides 220V to 240V at 50 Hz.

Plug your equipment into the

Power Module.

Turn your UPS ON.

• Set the System Switch on the UPS's back panel to the

“ENABLE” (RIGHT) position. (Figure 1a)

This switch activates the battery charger and microprocessor.

The “ ” light will flash until you engage the ON/Standby

Switch to activate the “ON” mode.

• Engage the momentary ON/Standby Switch on the UPS's

front panel and release it to activate the “ON” mode and

supply power to the UPS receptacles. (Figure 2b)

Communications on Next Page...

0VA4500W

50/60HZ 5000VA 3700W

50HZ 5000VA 3700W

CAUTION: DO NOT UNPLUG WHILE

OPERATINGOR ARCING WILL OCCUR

36VDC 175 AMPS MAX

BRANCH CIRCUIT #1

230VAC10AMPS

0/60HZ 5000VA 4500W

0VAC NOM 50/60HZ 5000VA 3700W

VAC NOM 50HZ 5000VA 3700W

CAUTION: DO NOT UNPLUG WHILE

OPERATING ORARCING WILL OCCUR

36VDC 175 AMPS MAX

BRANCH CIRCUIT #1

230VAC 10AMPS

1a.

Back panel

2b.

Front panel

9905251 230V SmartPro Datacenter OM.p65 8/8/00, 2:02 PM3

DB9 Port Connection

–Optional–*

Using the grey or tan Tripp Lite cable

that came with your UPS, connect your

primary server’s DB9 port to the single

DB9 port labeled “LAN 4.1” or "Smart

LAN Primary" (which provides complete

intelligent RS-232 communications).**

If you have additional

computers:

Connect them to the DB9 ports

labeled “LAN 2.1” (which provide

basic, contact-closure shutdown

capabilities) using the black cables

that came with your UPS.

Set their corresponding LAN Interface

DIP Switches to the ACTIVATE (DOWN)

position. See diagram for which switch

controls which port.*** Note: the last

switch on the right has no function.

* Computer communications are optional. Your UPS will function properly without these connections.

** The “LAN 4.1” or "Smart" DB9 port is always enabled and is not controlled by the LAN Interface DIP Switches.

*** If you do not connect a computer to any of the “LAN 2.1” DB9 ports, set their corresponding LAN Interface DIP

Switches to the DEACTIVATE (UP) position.

2a. Back panel

Load software and run the installation program

appropriate for your operating system.

2b. Back Panel

CAUTION: DO NOT UNPLUG WHILE

OPERATING OR ARCING WILL OCCUR

36VDC 175 AMPS MAX

IN: 230VAC 50/60HZ 5000VA 4500W

OUT-LINE: 230VAC NOM 50/60HZ 5000VA 3700W

OUT-BAT: 230VAC NOM 50HZ 5000VA 3700W

Computer Communications (Optional)*

9905251 230V SmartPro Datacenter OM.p65 8/8/00, 2:02 PM4

Basic Operation

Switches

System Switch (Middle Back Panel)

This switch activates the UPS's battery charger and intelligent

microprocessor. ALWAYS leave it in the “ENABLE” (RIGHT)

position when your UPS is plugged in. Only set the switch to

“DISABLE” (LEFT) to reduce battery drain when you unplug your

UPS for storage or shipping.

Note: When this switch is on "ENABLE", the “ ” light will flash until you engage the ON/

Standby Switch to turn power ON at the UPS receptacles.

ON/Standby Switch (Front Panel)

This momentary switch on the front panel controls power to the

UPS receptacles. Engage it momentarily and release it to toggle

between the “ON” mode (power ON at the UPS receptacles) and

“Standby” mode (power OFF at the UPS receptacles).

Mute/Test Switch (Front Panel)

Use this momentary switch on the front panel to do two things:

Silence the UPS On Battery alarm

Engage this switch and release it to silence the UPS On Battery

alarm, a series of short beeps that sounds intermittantly when

the UPS is providing AC power from battery. Note: when the

battery is nearly depleted, the Low Battery alarm, a continuous

beep that cannot be silenced, will alert you to immediately shut

down connected equipment.

Test your UPS’s battery charge

Leave your connected equipment ON. With your UPS plugged in

and completely turned ON, engage this switch; hold it there for

5 seconds and release it. You will hear a series of short beeps as

the UPS momentarily switches to battery to test its charge. The

“” light will turn ON and the alarm (a long, continuous beep)

will sound if your UPS fails a self-test and/or the UPS battery is

less than fully charged. If this occurs, let the UPS charge for 12

hours and perform a second self-test. If the light continues to

stay on, contact Tripp Lite for service. CAUTION: Do not unplug

your UPS to test its batteries. This will remove safe electrical

grounding and may introduce a damaging surge into your network

connections.

Maintenance Bypass Switch (Middle Rear Panel)

This switch, used during hot swap battery replacement, should be

left in the “NORMAL” (LEFT) position during ordinary operation.

Set this switch to “BYPASS” (RIGHT) to connect or disconnect

external battery packs while the UPS is plugged in and supporting

a load. The “ ” light on the front panel will light to indicate that

battery backup protection is not available until this switch is

returned to the "NORMAL" (LEFT) position.

—

9905251 230V SmartPro Datacenter OM.p65 8/8/00, 2:02 PM5

Indicator Lights

Light descriptions apply when the UPS is plugged into a wall outlet and turned ON.

This green light will shine constantly to indicate AC power is

available at the receptacles. It will flash to indicate AC power is

not available. (See “System Enable Switch” and “On/Standby

Switch” descriptions above.)

This multi-colored light displays 7 separate UPS battery charge

conditions. It will turn from red (low) to yellow (medium) to green

(full) to show you the level of battery charge remaining in both

internal and connected batteries. If the light is constant, your

UPS is operating from line power, and the battery is charging. If the

light is flashing, your UPS is operating from battery power, and the

battery is discharging. When the light flashes red, close any files

you are working on and shut down your computer.

Whenever your UPS is automatically correcting high or low AC

line voltage, this green light will turn ON and the UPS will gently

click. These are both normal, automatic operations of your UPS,

and no action is required on your part.

This red light will turn ON if your UPS fails a self-test and/or the

UPS battery is less than fully charged. If it lights, let the UPS

charge for 12 hours, then perform a self-test. If the light

continues to stay on, contact Tripp Lite for service.

This multi-colored light displays 4 separate UPS load conditions.

It will turn from green (low) to yellow (medium) to red (high) as

you connect equipment to show you the load level your UPS is

supporting. When the light is red, your UPS is supporting a load

above 85% of its capacity. If the red light begins flashing, then

your UPS is severely overloaded. Remove overload immediately

until light stops flashing.

This red light will turn ON when you set the Maintenance Bypass

Switch to “BYPASS”, indicating that the Power Module has turned

off its battery charger, allowing you to properly disconnect and

replace the Battery Packs. The light may also come on if Battery

Packs are improperly disconnected, indicating that the Power

Module is protecting itself from potential overvoltages. While this

light is on, the UPS will still provide filtered utility AC power and

will provide battery backup power if any batteries are connected.

DB9 communications are unaffected. To return the UPS's charger

to normal operation, set the Maintenance Bypass Switch to

“NORMAL”. If the light has come on due to improper battery

disconnection, cycle the Maintenance Bypass Switch to “BY-

PASS” then to “NORMAL” to reset the UPS.

Basic Operation (Continued)

9905251 230V SmartPro Datacenter OM.p65 8/8/00, 2:02 PM6

Other UPS Features

AC Receptacles (Rear Panel)

These 230V IEC-320 receptacles provide your connected equipment

with AC line power during normal operation and battery power

during blackouts and brownouts. They also protect your equipment

against damaging surges and line noise. You can remotely reboot

connected equipment by turning receptacles OFF and ON using

Tripp Lite PowerAlert software.

Circuit Breakers (Rear Panel)

These breakers will trip to prevent damage to your UPS due to

overload. Two single-pole circuit breakers protect each 230V

outlet bank and one double-pole circuit breaker protects the main

input circuit bank that powers all the outlets. If a breaker trips,

remove any overload then allow the UPS to cool before resetting

the breaker.

"Smart" RS-232 Port (Lower Rear Panel)

This port, labeled “SMART LAN PRIMARY” or “LAN 4.1” on the

UPS, connects your UPS to a workstation or server. Use with Tripp

Lite software and cabling to monitor and manage network power

and to automatically save open files and shut down equipment

during power failures. This port uses RS-232 communications to

transmit UPS and power conditions (Pin 7 = Transmit; Pin 8 =

Common; Pin 9 = Receive). Contact Tripp Lite Customer Support

for more information and a list of available SNMP, network

management and connectivity products.

Contact Closure Ports (Lower Rear Panel)

These ports, labeled “LAN 2.2” on the Control Module, are also

used to connect your UPS to a workstation or server. Use with

Tripp Lite software and cabling to automatically save open files

and shut down equipment during a blackout. This port uses

contact-closure signals to indicate line-fail and low-battery

status. Contact Tripp Lite Customer Support for more information.

Battery Connector (Rear Panel)

Use to connect Tripp Lite battery packs. Refer to the label next to

the connector for the appropriate Tripp Lite battery pack to

connect. Refer to instructions available with the battery pack for

complete connection information and safety warnings.

Remote Control Interface Port (Lower Rear Panel)

Use to connect an optional RT-2 Remote Control Adapter to

control the DataCenter via telephone or modem. Contact Tripp

Lite for information about ordering the RT-2; refer to the RT-2

manual for operating instructions.

9905251 230V SmartPro Datacenter OM.p65 8/8/00, 2:02 PM7

Storage & Service

Storage

Turn your UPS OFF: first engage the ON/Standby Switch and release it to place

your UPS in the “Standby” mode, then move the System Enable Switch to the

“DISABLE” (DOWN) position to prevent battery drain, then disconnect the UPS

power cord from the wall outlet. If you plan on storing your UPS for an extended

period of time, recharge the UPS batteries once every three months. Follow

steps #3 and #4 in the Quick Installation section and allow the UPS to charge

until the “ ” light glows green (may take 6 or more hours depending on the

number of batteries connected). If you leave your UPS batteries discharged for

an extended period of time, they may suffer permanent loss of capacity.

Service

If returning your UPS for service, contact your local Tripp Lite dealer or

distributor. They will refer you to a service center. Please carefully pack the UPS

using the ORIGINAL PACKING MATERIAL that came with the unit. Enclose a

letter describing the symptoms of the problem. If the UPS is within the 2 year

warranty period, enclose a copy of your sales receipt.

Specifications

SMARTDC3000INT SMARTDC3000XRINT

Output Capacity (VA/Watts): 3000/2400 3000/2400

Battery Runtime (with Battery Pack) (with 1 BP36V33*) (with 1 BP36VXR*)

for Half Load/Full Load in Minutes: 26+/11+†84+/36+†

Battery Recharge Time: 2-4 hrs. 2-4 hrs.

Approvals: — —

SMARTDC5000INT SMARTDC5000XLINT

Output Capacity (VA/Watts): 5000/3750 5000/3750

Battery Runtime (with Battery Pack) (with 1 BP36V33*) (with 2 BP36V33*)

for Half Load/Full Load in Minutes: 42+/18+†108+/42+†

Battery Recharge Time: 2-4 hrs. 2-4 hrs.

Approvals: SASO SASO

* Included with UPS.

† Battery Runtime can be increased by adding additional external battery packs. This will increase recharge time, however.

Input Voltage (220-240V); Input Frequency (50 Hz); On-Line Input Voltage Range (166-276 volts); Voltage-Regulated Output Voltage

Range (220/240V +8%/-15%); On-Battery Output Voltage Range (220/240V ± 5%); Output Waveform Line Mode (filtered sinewave); Output

Waveform Battery Mode (PWM sine wave); AC Surge Suppression (exceeds IEEE 587 Cat. A & B standards);

AC Noise Attenuation (>40 dB); AC TVSS Protection Modes (H to N, H to G, N to G).

The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change.

93-1417 (9905251) 0800

9905251 230V SmartPro Datacenter OM.p65 8/8/00, 2:02 PM8

Tabla de contenidos

Otros manuales de Unión Postal Universal de Tripp Lite

Tripp Lite

Tripp Lite SmartPro SLT Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU10000RT3U2TF Manual de usuario

Tripp Lite

Tripp Lite SmartPro AG-0019 Manual de usuario

Tripp Lite

Tripp Lite SM1500RMXL2UTAA Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU10K Manual de usuario

Tripp Lite

Tripp Lite ECO-UPS ECO850LCD Manual de usuario

Tripp Lite

Tripp Lite Digital UPS System OMNI1300LCD Manual de usuario

Tripp Lite

Tripp Lite SmartOnline 220/230/240V Input/Output Manual de usuario

Tripp Lite

Tripp Lite SU2200RTXL2UN Manual de instalación y operación

Tripp Lite

Tripp Lite SU10000RT3UG Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU5000RT3U Manual de usuario

Tripp Lite

Tripp Lite LCDT Series Manual de usuario

Tripp Lite

Tripp Lite SmartPro SMART1500XL Guía de configuración

Tripp Lite

Tripp Lite SmartOnline Manual de usuario

Tripp Lite

Tripp Lite SmartPro Rackmount SMX1000RT2U Manual de usuario

Tripp Lite

Tripp Lite SmartPro SMART1500RM2U Manual de usuario

Tripp Lite

Tripp Lite OMNI750ISO Manual de usuario

Tripp Lite

Tripp Lite Internet Office & BC Personal UPS System Manual de usuario

Tripp Lite

Tripp Lite AVRX Series Manual de usuario

Tripp Lite

Tripp Lite HT1000UPS Manual de usuario

Tripp Lite

Tripp Lite SMART1050SLTAA Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU1500XLCD Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU2200RMNAFTA Manual de usuario

Tripp Lite

Tripp Lite SMART1500LCDT Manual de usuario

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

CyberPower

CyberPower CP585LCD Manual de usuario

Eaton

Eaton 3S Instrucciones de montaje

CyberPower

CyberPower Office Tower Series UPS 1000 Manual de usuario

CyberPower

CyberPower BM100 Manual de usuario

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

LEGRAND

LEGRAND keor 310081 Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario
