Tripp Lite SmartPro SLT SMX750SLT Guía de configuración

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: SMX750SLT

SmartPro .75kVA Line Interactive Sine Wave UPS, SNMPWEBCARD option, Tower, USB, Serial, 220/230/240V

Highlights

750VA line interactive tower UPS; Sine wave output

220/230/240V nominal output during brownouts and overvoltages

USB, RS232 and optional SNMP/Web card are available for simultaneous use

Front panel status LEDs with load level and battery capacity display

C14 input; 6 C13 outlets; Includes 2 C13 to C14 cables

Description

Tripp Lite's SMX750SLT intelligent, line-interactive sine wave UPS system protects servers, networking accessories and telecommunications

equipment from blackouts, voltage fluctuations and transient surges. Large internal batteries offer 15 minutes half load runtime and 5 minutes full

load runtime. 750VA/500 watt power handling capability and full-time sine wave output offers guaranteed compatibility with networking, telecom and

other sensitive electronic applications. Includes 6 protected C13 output receptacles total. Network management interfaces support communications

via USB, RS-232 and optional SNMPWEBCARD network interface. HID-compliant USB interface enables integration with built-in power

management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment load

levels, self-test data and utility power conditions. Includes PowerAlert monitoring software and complete cabling. Single line Tel/DSL and network

Ethernet line surge suppression. Built-in audible alarm and 9 LEDs offer status notification for line power, battery power, battery charge level, load

level, plus AVR boost and trim operational status information. Network grade AC surge suppression protects equipment from damage and

performance problems resulting from transient surges. Attractive, all-black tower housing.

Package Includes

SMX750SLT UPS System

PowerAlert Software CD-ROM

USB and serial cabling

User manual with warranty information

Features

SMX750SLT line-interactive UPS offers battery derived sine wave AC output during power outages, voltage regulation during brownouts

and overvoltages, plus network-grade AC surge suppression

750VA/500 watt power handling capability with full-time sine wave output offers guaranteed compatibility with networking, telecom and other

sensitive electronic devices

Large internal batteries offer runtimes of 15 minutes at half load (325VA/250 watts) and 5 minutes at full load (750VA/500 watts)

Automatic Voltage Regulation (AVR) circuits maintain user-selectable 220, 230 or 240V nominal output over an input voltage range of 151

to 290

Includes 6 C13 output receptacles

IEC320-C14 input connection accepts a variety of detachable cordsets

Built-in USB, RS-232 and optional SNMPWEBCARD accessory monitoring options

HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X

Included PowerAlert UPS monitoring software

Supports Tripp Lite's WatchDog software application (requires optional WATCHDOGSW)

9 LEDs offer continuous status information of UPS operating parameters and site power quality

Hot-swappable batteries allow on-site battery replacement without powering off connected equipment

Single line Tel/DSL and network Ethernet line surge suppression

Specifications

OUTPUT

Output Volt Amp Capacity

(VA)

750

Output Watt Capacity

(watts)

500

Output power factor 0.7

Nominal Output

Voltage(s) Supported

220V; 230V; 240V

Nominal Voltage details 230V default (voltage selection via back panel switches)

Frequency compatibility 50 / 60 Hz

Output voltage regulation

(line mode)

-11%, +6%

Output voltage regulation

(Battery mode)

+/- 5%

Built-in UPS output

receptacles

6 C13 outlet(s)

Included output power

cables

Includes 2 C13 to C14 output power cables

Output AC waveform (AC

mode)

Sine wave

Output AC waveform

(battery mode)

Pure Sine wave

INPUT

Rated input current (at

maximum load)

3.6A (220V), 3.5A (230V), 3.4A (240V)

Nominal Input Voltage(s)

Supported

220V AC; 230V AC; 240V AC

UPS input connection type C14 inlet

UPS input connection

description

IEC320-C14 input connection accepts a variety of detachable cordsets to match country or site-specific wall

receptacles

BATTERY

Full load runtime

(minutes)

5 min. (500w)

Half load runtime

(minutes)

15 min. (250w)

DC system voltage (VDC) 24

Battery recharge rate

(included batteries)

Less than 4 hours to 90%

Replacement battery

cartridge (internal UPS

battery replacement)

RBC24-SLT

Battery Access Battery access door

Battery replacement

description

Hot-swappable, user replaceable batteries

VOLTAGE REGULATION

Voltage regulation

description

Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 151 to 290V

Overvoltage correction Voltage reduction of 12% applies when input is 232-266 (220V), 244-278 (230V), 254-290 (240V)

Undervoltage correction Voltage boost of 15% applies when input is 175-198 (220V), 182-206 (230V), 190-216 (240V)

Severe undervoltage

correction

Voltage boost of 30% applies when input is 151-174 (220V), 158-181 (230V), 166-190 (240V)

LEDS ALARMS & SWITCHES

LED Indicators 9 LEDs indicate line power, battery power, AVR, overload and replace battery status - with a 3-LED level meter

for load and battery charge level

Alarms Audible alarm indicates power failure and overload conditions

Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; rear panel protected switches

support nominal voltage selection

SURGE / NOISE SUPPRESSION

UPS AC suppression

joule rating

504

UPS AC suppression

response time

Instantaneous

UPS Dataline suppression 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet

EMI / RFI AC noise

suppression

Yes

PHYSICAL

Installation form factors

supported with included

accessories

Tower

Primary form factor Tower

UPS / Power Module

dimensions in primary

form factor (height x

width x depth / inches)

10.25 x 6.75 x 13.25

UPS / Power Module

dimensions in primary

form factor (height x

width x depth / cm)

26 x 17.1 x 33.7

UPS / Power Module

weight (lbs)

34.1

UPS / Power Module

weight (kg)

15.5

UPS Shipping dimensions

(height x width x depth /

inches)

14 x 9.75 x 18.5

UPS Shipping dimensions

(height x width x depth /

cm)

35.6 x 24.8 x 47

Shipping weight (lbs) 38.6

Shipping weight (kg) 17.5

Cooling method Fan

UPS housing material Steel

ENVIRONMENTAL

Operating Temperature

Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature

Range

+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr. (full

load)

Battery mode BTU / hr.

(full load)

349

Audible Noise Audible Noise < 50 dBA at Front Side 1 Meter

COMMUNICATIONS

Communications interface USB (HID enabled); DB9 Serial; Slot for SNMP/Web interface

Network monitoring port

description

Supports detailed monitoring of UPS and site power conditions

PowerAlert software Included

Communications cable USB and DB9 cabling included

WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

LINE / BATTERY TRANSFER

Transfer time 4-8 milliseconds

Low voltage transfer to

battery power (setpoint)

151 (220V), 158 (230V), 166 (240V)

High voltage transfer to

battery power (setpoint)

266V (220V), 278V (230V) or 290V (240V)

SPECIAL FEATURES

Cold Start (startup in

battery mode during a

power failure)

Cold-start operation supported

High availability UPS

features

Hot swappable batteries

Green & high efficiency

features

Greater than 95% efficiency - GREEN UPS

CERTIFICATIONS

UPS Certifications CE; Tested to GOST (Russia); Tested to SASO (Saudi Arabia)

UPS Certification details EN62040-1, EN62040-2

WARRANTY

Product Warranty Period

(International)

2-year limited warranty

Product Warranty Period

(Mexico)

2-year limited warranty

Product Warranty Period

(Puerto Rico)

2-year limited warranty

Related Items

Optional Products

Related Model Description Qty.

DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial lines 1

DNET1 Network Surge Suppressor - Essential protection for data and communication lines 1

DTEL2 Network Surge Suppressor - Essential protection for data and communication lines 1

ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires SNMPWEBCARD

or switched PDU.)

SNMPWEBCARD For remote monitoring and control via SNMP, Web, or Telnet. 1

U022-010 10-ft. USB2.0 A/B Gold Device Cable

(A Male to B Male)

WATCHDOGSW WatchDog Service Monitoring / Reboot Software 1

MODBUSCARD For remote monitoring and control via MODBUS protocol 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3021.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
