Tripp Lite ECO550UPSTAA Manual de usuario

TAA-Compliant 550VA Eco Energy-Saving UPS

System

MODEL NUMBER: ECO550UPSTAA

Description

The ECO550UPSTAA is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

This standby green UPS offers complete protection from blackouts, brownouts and transient surges. Supports

green energy savings via built-in Eco outlets that automatically power off unused computer accessories like

printers or multi-media speakers when the computer is not in use. Full load efficiency rating of 99% also offers

energy-savings and cooler operation by limiting UPS power consumption to only 3 watts! Eco-friendly design

meets strict RoHS environmental standards. Provides uninterrupted transition to battery-derived AC output

during brownouts and power failures with enough runtime to save and shutdown connected equipment without

data loss. Offers complete protection in an ultra-compact desktop or wall-mountable housing. Includes 4 battery

supported outlets for computer, monitor and two vital system peripheral, plus 4 additional surge

suppression-only outlets for accessories not requiring battery support. Three of the surge-only outlets are

designated Eco outlets that can be configured to automatically power-off when the computer enters standby

mode or is shutdown. USB port enables UPS configuration options and unattended system shutdown without data loss in the case of extended power failure.

PowerAlert software is available via free download from www.tripplite.com. USB cable included. Built-in single line RJ11 phone suppression protects modem,

fax machine, cordless phone or other accessories with a dialup/DSL phone connection. Built-in audible alarm and front panel LEDs offer continuous status

information regarding line and battery power operation. 550VA / 300 watt power handling ability supports entry-level PC systems for up to 17 minutes during

power fail conditions. $100,000 connected equipment insurance (USA, Puerto Rico, & Canada Only).

Features

Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

ECO550UPSTAA standby green UPS offers complete protection from blackouts, brownouts and transient surges

Built-in Eco outlets automatically power off unnecessary computer accessories like printers, scanners and speakers when computer is not in use

Full load efficiency rating of 99% saves energy and heat output by limiting UPS power consumption to only 3 watts with only 4 BTU/hr. of heat output

Eco-friendly design meets strict RoHS (Restriction of Hazardous Substances) environmental standards

550VA / 300 watt UPS provides battery-derived AC output during brownouts and power failures to support entry-level desktop computer with 15 inch LCD

monitor up to 17 minutes

Ultra compact UPS supports a variety of placement options for desktop or wallmount use

Highlights

Federal Trade Agreements Act /

TAA Compliant for GSA

Schedule purchases

550VA ultra-compact 120V

standby UPS, energy-saving

ECO outlets

Maintains AC output during power

failures, 99% line mode efficiency

ECO option turns off set of three

outlets when the computer is not

in use

USB port, TEL/DSL protection,

Wall mountable, Surge-only

outlets

NEMA 5-15P input plug and 8

NEMA 5-15R outlets

This product is ENERGY STAR

qualified for its ability to save

customers money while

helping to protect the

environment

Package Includes

ECO550UPSTAA TAA Compliant

UPS System

USB cable

Instruction manual with warranty

information

1 / 5

Ultra compact UPS supports a variety of placement options for desktop or wallmount use

Includes 4 UPS supported outlets for computer, monitor and 2 vital system peripherals requiring uninterrupted power

Includes 4 Surge-only outlets for accessories not requiring battery support

Three of the Surge-only outlets are designated Eco outlets that can be configured to automatically power-off when the computer is not in use

USB port enables UPS configuration options and unattended system shutdown without data loss in the case of extended power failure.

PowerAlert UPS monitoring software is available for free download from www.tripplite.com

Single line RJ11 phone suppression jacks protects modem, fax machine, cordless phone or other accessories from surges on dial-up/DSL phone

connections

USB cable included

Space-saving right angle input plug

$100,000 connected equipment insurance (USA, Puerto Rico and Canada only)

Specifications

OUTPUT

Output Volt Amp Capacity (VA) 550

Output Watt Capacity (watts) 300

Nominal Output Voltage(s)

Supported 115V; 120V

Frequency compatibility 60 Hz

Output voltage regulation (Battery

mode) 115V (+/- 5%)

Built-in UPS output receptacles 8 5-15R outlet(s)

Surge suppression only outlets 4 UPS outlets, 4 surge-only outlets

Output AC waveform (AC mode) Sine wave

Output AC waveform (battery mode) PWM sine wave

INPUT

Rated input current (at maximum

load) 10A

Nominal Input Voltage(s) Supported 120V AC

UPS input connection type 5-15P; Right-Angled

UPS Input cord length (ft.) 6

UPS Input cord length (m) 1.8

Recommended Electrical Service 15A 120V

Phase Single-Phase

BATTERY

Full load runtime (minutes) 3.5 min. (300w)

2 / 5

Half load runtime (minutes) 10 min. (150w)

DC system voltage (VDC) 12

Battery recharge rate (included

batteries) Less than 15 hours from 10% to 90%

LEDS ALARMS & SWITCHES

LED Indicators 3 LEDs indicate power status, overload/check battery and ECO-mode status

Alarms Audible alarm indicates power-failure and overload status

Switches Combination switch controls on/off power status and self-test operation; second recessed push-button switch

enables ECO outlet switching

SURGE / NOISE SUPPRESSION

UPS AC suppression joule rating 420

UPS AC suppression response time Instantaneous

UPS Dataline suppression 1 line TEL/DSL (1 in / 1 out)

EMI / RFI AC noise suppression Yes

PHYSICAL

Installation form factors supported

with included accessories Tower; Ultra-compact desktop

Primary form factor Desktop

UPS / Power Module dimensions in

primary form factor (height x width x

depth / inches)

3.1 x 10.8 x 5.7

UPS / Power Module dimensions in

primary form factor (height x width x

depth / cm)

7.8 x 27.6 x 14.6

UPS / Power Module weight (lbs) 6.6

UPS / Power Module weight (kg) 3

UPS Shipping dimensions (height x

width x depth / inches) 4.1 x 13 x 8

UPS Shipping dimensions (height x

width x depth / cm) 10.4 x 33 x 20.3

Shipping weight (lbs) 7.1

Shipping weight (kg) 3.2

UPS housing material ABS

ENVIRONMENTAL

Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

3 / 5

AC mode BTU / hr. (full load) 10.3

Battery mode BTU / hr. (full load) 194.3

AC mode efficiency rating (100%

load) 99%

COMMUNICATIONS

Communications interface USB (HID enabled)

PowerAlert software Free download from www.tripplite.com

Communications cable USB interface cable included

WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

LINE / BATTERY TRANSFER

Transfer time AC to battery mode: 4 milliseconds / Battery to AC mode: 3 milliseconds

Low voltage transfer to battery

power (setpoint) 99

High voltage transfer to battery

power (setpoint) 139

SPECIAL FEATURES

Cold Start (startup in battery mode

during a power failure) Cold-start operation supported

Green & high efficiency features Greater than 95% efficiency - GREEN UPS; Power saving auto-shutoff ECO outlets

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B

(EMI); ROHS (Restriction of Hazardous Substances); TAA Compliant; ENERGY STAR Qualified

WARRANTY

Product Warranty Period (U.S. &

Canada) 3-year limited warranty

Product Warranty Period (Latin

America) 3-year limited warranty

Product Warranty Period

(International) 2-year limited warranty

Product Warranty Period (Mexico) 3-year limited warranty

Connected Equipment Insurance

(U.S., Canada & Puerto Rico) $100,000 Ultimate Lifetime Insurance
