Tripp Lite BCPRO1050 Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: BCPRO1050

BC Pro 1050VA Tower Standby 120V UPS with USB port

Highlights

1050VA / 1.05kVA tower 120V standby UPS

Maintains AC output during power failures

USB port, Front panel status LEDs, 97% efficient

NEMA 5-15P input plug and 6 NEMA 5-15R outlets

Description

Tripp Lite's BCPRO1050 standby UPS offers AC surge suppression and long lasting battery support for desktop PCs, network workstations and a

wide variety of consumer and professional electronics. Uninterruptible Power Supply / UPS circuits switch to battery backup mode within

milliseconds to keep connected equipment running without interruption or data loss during power failures, brownouts and overvoltages. AC surge

suppression prevents connected equipment damage. USB communications port supports full featured monitoring and data-saving auto-shutdown

options using Tripp Lite's free PowerAlert monitoring software.

Package Includes

BCPRO1050 UPS System

USB cable

Warranty information

Instruction manual

Features

BCPRO1050 tower 120V standby UPS offers AC power protection from blackouts, brownouts, overvoltages and transient surges

1050VA / 705 watt UPS output capacity

Uninterruptible Power Supply / UPS operation maintains battery-derived AC output during blackouts, brownouts and overvoltages to prevent

data loss and system downtime for connected equipment

Built-in USB port enables data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download

from www.tripplite.com

7 minutes runtime at 100% load (705 watts), 23 minutes runtime at 50% load (355 watts)

107 minutes runtime for a desktop computer system consuming 80 watts continuous

6 built-in NEMA 5-15R UPS supported outlets

NEMA 5-15P input connection with 6ft / 1.8m line cord

Network grade AC surge and lightning protection is available from all outlets

97% line mode efficiency rating uses less energy and BTU emissions

Front panel LEDs indicate line / battery mode, low battery, replace battery status; Audible alarm with alarm cancel / self-test button

Hot swappable user battery replacement

Tower housing supports desk or floor placement

Specifications

OUTPUT

Output Volt Amp Capacity

(VA)

1050

Output kVA capacity (kVA) 1

Output Watt Capacity

(watts)

705

Nominal Output Voltage(s)

Supported

115V; 120V

Frequency compatibility 60 Hz

Output voltage regulation

(Battery mode)

115V (+/- 5%)

Built-in UPS output

receptacles

6 5-15R outlet(s)

Basic PDU options PDU1215 (1U / 13 5-15R outlets); PDUNV (1U / 2 C19, 12 C13 outlets); PDU1415 (0U / 14 5-15R outlets);

PDUV15 (0U / 12 5-15R outlets)

Metered PDU options PDUMH15 (1U / 13 5-15R outlets); PDUMH15AT (1U / 8 5-15R outlets)*; PDUMV15 (0U / 16 5-15R outlets)

Switched PDU options PDUMH15ATNET (1U / 8 5-15R outlets)*; PDUMV15NET (0U / 16 5-15R outlets)

External PDU redundancy

options

*Auto Transfer Switch features utilizing the secondary PDU input cord are compatible with Smart Online UPS

models only

Output AC waveform (AC

mode)

Sine wave

Output AC waveform

(battery mode)

PWM sine wave

INPUT

Rated input current (at

maximum load)

6.4A

Nominal Input Voltage(s)

Supported

120V AC

UPS input connection type 5-15P

Input circuit breaker 15A

UPS Input cord length (ft.) 6

UPS Input cord length (m) 1.8

Recommended Electrical

Service

15A 120V

Input cord length (ft.) 6

Input cord length (m) 1.8

BATTERY

Full load runtime (minutes) 7 min. (705w)

Half load runtime

(minutes)

23 min. (355w)

DC system voltage (VDC) 18

Battery recharge rate

(included batteries)

Less than 4 hours from 10% to 90%

Replacement battery

cartridge (internal UPS

battery replacement)

RBC52 (quantity 3)

Battery Access Battery access door

Battery replacement

description

Hot-swappable, user replaceable batteries

LEDS ALARMS & SWITCHES

LED Indicators 5 LEDs indicate line power, battery power, battery low/replace and overload status

Alarms Audible alarm indicates power-failure and low-battery conditions

Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate

low-battery status

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation

SURGE / NOISE SUPPRESSION

UPS AC suppression

joule rating

510

UPS AC suppression

response time

Instantaneous

EMI / RFI AC noise

suppression

Yes

AC suppression joule

rating

510

AC suppression response

time

Instantaneous

PHYSICAL

Installation form factors

supported with included

accessories

Tower

Installation form factors

supported with optional

accessories

Wallmount (UPSWM - tower mounting kit)

Primary form factor Tower

UPS / Power Module

dimensions in primary

form factor (height x width

x depth / inches)

11.2 x 6.8 x 7

UPS / Power Module

dimensions in primary

form factor (height x width

x depth / cm)

28.6 x 17.1 x 17.8

UPS / Power Module

weight (lbs)

UPS / Power Module

weight (kg)

13.2

UPS Shipping dimensions

(height x width x depth /

inches)

15.2 x 10.8 x 11.5

UPS Shipping dimensions

(height x width x depth /

cm)

38.7 x 27.3 x 29.2

Shipping weight (lbs) 29

Shipping weight (kg) 13.2

UPS housing material Polycarbonate

ENVIRONMENTAL

Operating Temperature

Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature

Range

+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr. (full

load)

74.1

Battery mode BTU / hr.

(full load)

562.3

COMMUNICATIONS

Communications interface USB

PowerAlert software Free download from www.tripplite.com

Communications cable USB interface cable included

WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

LINE / BATTERY TRANSFER

Transfer time 2-4 milliseconds

Low voltage transfer to

battery power (setpoint)

High voltage transfer to

battery power (setpoint)

143

SPECIAL FEATURES

Cold Start (startup in

battery mode during a

power failure)

Cold-start operation supported

High availability UPS

features

Hot swappable batteries

Green & high efficiency

features

Greater than 95% efficiency - GREEN UPS

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B

(EMI)

WARRANTY

Product Warranty Period

(Worldwide)

2-year limited warranty

Connected Equipment

Insurance (U.S., Canada &

Puerto Rico)

$200,000 Ultimate Lifetime Insurance

Related Items

Optional Products

Product Type Related Model Description Qty.

Audio Cables CT120 Instant-Read- AC Outlet Circuit Tester 1

Extended Warranties WEXT3-BCPRO 3-Year Extended Warranty - For BC Pro Models 1

Extended Warranties WEXT5-BCPRO 5-Year Extended Warranty - For BC Pro Models 1

Software WATCHDOGSW WatchDog Service Monitoring / Reboot Software 1

Surge Protectors DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial

lines

Surge Protectors DNET1 Network Surge Suppressor - Essential protection for data and

communication lines

Surge Protectors DTEL2 Network Surge Suppressor - Essential protection for data and

communication lines

USB Hubs/Accessories U022-010 10-ft. USB2.0 A/B Gold Device Cable

(A Male to B Male)

Wallmount Bracket UPSWM Wallmount Bracket and installation accessories (4 washers, 4 screws,

1 Velcro safety strap)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=7.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
